シンセ・モジュール・アクセサリー

Notes: Replacement black panel for XAOC Devices Zadar 1973 quadruple envelope generator module.

No soldering required.

Width: 10HP

Notes: Replacement panel for the Xoac Devices Sofia module.

Notes: Optional accessory replacement panel.

Black anodised alu + heavy duty screen printing.

Notes: Optional accessory replacement panel.

Black anodised alu + heavy duty screen printing.

Notes: Optional accessory replacement panel.

Black anodised alu + heavy duty screen printing.

Notes: Optional accessory replacement panel.

Black anodised alu + heavy duty screen printing.

Notes: Optional accessory replacement panel.

Black anodised alu + heavy duty screen printing.

Notes: The tiny but mighty Eurorack power supply. Winterbloom's love letter to DIYers is perfect for custom cases.

Micronova is a miniature 100x30mm power supply with a big soul. It can provide up to 18W of power for your modules and multiple units can be easily daisy chained to power larger systems.

Despite being adorably small, Micronova provides lots of flexibility for custom case builds. It can be powered through an attached DC barrel jack, screw terminals, or through an optional front entry panel.

Micronova is equipped with two Eurorack power headers that can be expanded using a busboard or flying bus cable.

Micronova also has critical safety features including reverse polarity protection, a resettable polyfuse, and over-current shutdown.

A suitable AC-DC power adapter is required.

A tiny 100mm x 30mm board with M3 mounting holes
Provides +12V @ 1A, -12V @ 300mA, and +5V @ 500mA
Includes two 16-pin Eurorack power headers
Requires a 15V to 20V center positive DC power supply
Multiple units can be daisy chained
Reverse-polarity, over-current, and over-temperature protection

Notes: These Z-Ears are standard 3U rack ears. These parts are made of anodized aluminum and are custom made to work with Eurorack mounting rails like Z-Rails.

Notes: Polytip is Tiptop Audio's new type of modular synthesiser patch cable that can pass multiple audio channels using minimal panel space. This innovative design finally adds to modular the capability to patch more than one signal at a time and unleash the full potential of polyphonic patching between modules. Polytips uses the industry standard USB Type C connector although it is not a USB cable (and USB cables do not work with Polytip). Internally multiple lines of shielded analogue audio lines pass from end to end with excellent sound quality.

Notes: Polytip is Tiptop Audio's new type of modular synthesiser patch cable that can pass multiple audio channels using minimal panel space. This innovative design finally adds to modular the capability to patch more than one signal at a time and unleash the full potential of polyphonic patching between modules. Polytips uses the industry standard USB Type C connector although it is not a USB cable (and USB cables do not work with Polytip). Internally multiple lines of shielded analogue audio lines pass from end to end with excellent sound quality.

Notes: polytip is Tiptop Audio's new type of modular synthesiser patch cable that can pass multiple audio channels using minimal panel space. This innovative design finally adds to modular the capability to patch more than one signal at a time and unleash the full potential of polyphonic patching between modules. Polytips uses the industry standard USB Type C connector although it is not a USB cable (and USB cables do not work with Polytip). Internally multiple lines of shielded analog audio lines pass from end to end with excellent sound quality.

Notes: Polytip is Tiptop Audio's new type of modular synthesiser patch cable that can pass multiple audio channels using minimal panel space. This innovative design finally adds to modular the capability to patch more than one signal at a time and unleash the full potential of polyphonic patching between modules. Polytips uses the industry standard USB Type C connector although it is not a USB cable (and USB cables do not work with Polytip). Internally multiple lines of shielded analogue audio lines pass from end to end with excellent sound quality.

Notes: Polytip is Tiptop Audio's new type of modular synthesiser patch cable that can pass multiple audio channels using minimal panel space. This innovative design finally adds to modular the capability to patch more than one signal at a time and unleash the full potential of polyphonic patching between modules. Polytips uses the industry standard USB Type C connector although it is not a USB cable (and USB cables do not work with Polytip). Internally multiple lines of shielded analogue audio lines pass from end to end with excellent sound quality.

Notes: Mariana Trench is an FDN card for the Z-DSP. Feedback Delay Networks (FDNs) are built around multiple delays which are connected to their inputs thanks to a feedback matrix designed for its stability and lossless properties. FDN can mimic the recursive process of sound waves bouncing back and forth in an acoustic space. They were first suggested for artificial reverberation by Michael Gerzon (1971) and later John Stautner and Miller Puckette (1982) introduced four-channel FDN reverberator with general stability conditions.

FDN can also be used as a special case of digital waveguides, they can be tuned, or also used as complex delays. The Mariana Trench Z-DSP cartridge is designed to explore these more unusual sides of the FDN algorithms. Mariana Trench Z-DSP cartridge is designed by Christophe Duquesne Anckorage - Haken Audio developement team - La Voix du Luthier.

Notes: With Mantis, Tiptop took their years of experience with Eurorack to create a low-cost case that makes the Eurorack modular synthesizer look, work, and feel like a professional instrument. Mantis is an instrument that is at home on stage, touring, or in the center of the studio.

Mantis has two rows of 104HP for you to rack your modules. It comes fully powered and assembled, just drop in your modules and play.

Using its sophisticated leg mechanism, you can set it to three different positions: 0, 45, and 90 degrees.

Power Power and more Power! With Mantis, say bye-bye to the tedious, never-ending calculation of current consumption for the i12V power. Mantis comes with a juicy Zeus power supply that delivers plenty of power both now and for the future.

Mantis is beautiful and the color contrast between legs and body gives it its identity. Legs are offered in 4 different colors so anyone can find the right look.

Mantis comes with real Z-Rails made according to Eurorack enclosure standards. No sliding nuts or wrong spacing! It also has keyed power connectors to help protect your modules from damage from plugging the power in in reverse.

Using the optional bracket accessory Mantis can be doubled up to 416HP! Multiply your Mantis and watch your studio setup grow...

Weighing only 3kg/6.5lb, Mantis is so light, traveling has never been so relaxed.

The Dual Mantis Studio Brackets pair lets you connect two Mantis together in a robust and elegant solution. This setup is fixed and is recommend mainly for studio use. The brackets are cut precisely by laser from a sturdy metal and then coated twice for a nice smooth finish that matches the Mantis light gray color. They come with sixteen screws and special washers that help hold the screw in place during assembly and keep a tiny gap between the brackets and the Mantis. Installation is fairly simple and takes about 30 minutes to complete.

***UPDATE - MAY 2021 ***
As of May 2021, all Mantis cases shipped have a small update to the design. The connector for SyncBus is no longer included. This connector was never used as Tiptop didn't develop the cable for it, and the connector is no longer in production by the manufacturer so it was removed. The Mantis still has the same power supply and functions as before.

Notes: The Happy Ending Kit is an easy way to get everything needed to start a Eurorack modular system.

The Happy Ending Kit includes:
1 x Z-Rails set plus screws to attach to Z-Ears
1 x uZeus 4HP PSU with 2 x flying bus boards
1 x UK 3-pin mains adapter

Notes: The Dual Mantis Studio Brackets pair lets you connect two Mantis together in a robust and elegant solution. This setup is fixed and is recommend mainly for studio use. The brackets are cut precisely by laser from a sturdy metal and then coated twice for a nice smooth finish that matches the Mantis light gray color. They come with sixteen screws and special washers that help hold the screw in place during assembly and keep a tiny gap between the brackets and the Mantis. Installation is fairly simple and takes about 30 minutes to complete.

Using the optional bracket accessory Mantis can be doubled up to 416HP! Multiply your Mantis and watch your studio setup grow...

Before you begin:
Please get a Phillips head screw driver. It is also recommended to have eight eurorack modules available to help align the Z-Rails but this is not mandatory.

The kit contains:
2 x Brackets, left and right
2 x Adhesive foam strips
12 x Phillips pan head machine screws
12 x Nylon washers
1 x Allen Wrench 3mm

Notes: The 3-Tier Mantis Studio Brackets pair lets you connect three Mantis together in a robust and elegant solution. This setup is fixed and is recommended mainly for studio use. The brackets are cut precisely by laser from a sturdy metal and then coated twice for a nice smooth finish that matches the Mantis light gray color. They come with twenty screws and special washers that help hold the screw in place during assembly and keep a tiny gap between the brackets and the Mantis. Installation is fairly simple and takes about 30 minutes to complete.

Notes: The uBASE-QS 2 module is the carrier (or BASE) for four micro modules and explicitly designed for use in the QUICKSWAP CASEs. This carrier module can be plugged into the QS case as any other module; then, the uModules can be plugged in and removed itself into it, even with the AE system running, so you can reconfigure or add needed functions in form of micro modules "on the fly".

A number of sockets provide access to the bus signals, like CV, gate, cotroller, MIDI start/stop/clock.

Included is a small "key" to lift also modules without knobs in an easy way.

Notes: The 1-row QUICKSWAP CASE for AE modular is the high-end case for AE modular. It is based on a sturdy metal chassis with a beautiful matte black powder coating and - the key feature of this case - allows to plug in AE modules without any screws! The design makes sure that the modules sit really firm in the case and the bus connection is established automatically by the integrated bus board, so need for the separate bus cable known from the standard AE cases. This means, rearranging your modular system can't be easier!

This case is developed by Kyaa, a great 3rd party AE module developer; tangible waves is producing the case. We are happy about this great cooperation and this marvellous addition to our product range!

With a connector kit, another QUICKSWAP CASE of same width can be attached at certain angles, depending on the connector - and the power supply is linked between the cases also via the connector.

Other utilities, like a handle for carrying a folded case, are coming soon.


Please note: This rack does not include the Master or Power module. To connect the case to power you have the following options:
Install the Master Module
Install the Power Module
Connect to another, already powered QUICKSWAP CASE
Connect to another AE case via the RACKLINK module kit

Notes: The 1-row QUICKSWAP CASE for AE Modular is the high-end case for AE Modular. It is based on a sturdy metal chassis with a beautiful matte black powder coating and - allows to plug in AE modules without any screws, which is a key feature of this case! The design makes sure that the modules sit firmly inside the case and the bus connection is established automatically by the integrated bus board, so need for the separate bus cable known from the standard AE cases. Rearranging your modular system can't be easier!

This case is developed by Kyaa, a 3rd party AE module developer; Tangible Waves is producing the case.

With a connector kit, another QUICKSWAP CASE of same width can be attached at certain angles, depending on the connector - and the power supply is linked between the cases, also via the connector.

Other utilities, like a handle for carrying a folded case, are coming soon.

Please note: This rack does not include the Master or Power module.

To connect the case to power you have the following options:

Install the Master Module
Install the Power Module
Connect to another, already powered QUICKSWAP CASE
Connect to another AE case via the RACKLINK module kit

*** Please note: the modules are not included, they are shown for demonstration purposes only. ***

Notes: The 1-row QUICKSWAP CASE for AE modular is the high-end case for AE modular. It is based on a sturdy metal chassis with a beautiful matte black powder coating and - the key feature of this case - allows to plug in AE modules without any screws! The design makes sure that the modules sit really firm in the case and the bus connection is established automatically by the integrated bus board, so need for the separate bus cable known from the standard AE cases. This means, rearranging your modular system can't be easier!

This case is developed by Kyaa, a great 3rd party AE module developer; tangible waves is producing the case. We are happy about this great cooperation and this marvellous addition to our product range!

With a connector kit, another QUICKSWAP CASE of same width can be attached at certain angles, depending on the connector - and the power supply is linked between the cases also via the connector.

Other utilities, like a handle for carrying a folded case, are coming soon.

Please note: This rack does not include the Master or Power module.
To connect the case to power you have the following options:
install the Master Module
install the Power Module
connect to another, already powered QUICKSWAP CASE
connect to another AE case via the RACKLINK module kit

Notes: A set of 6 Patchwires for AE modular; with a length of 80 cm.

Cable has a soft, flexible silicone insulation, with a gold plated pin.

Notes: This is a variant of the standard red/black racks for AE modular with wooden front and sides.

Same as with the standard cases, via a joint kit (not included) another case of this width (either one-row or two-row, standard or wooden type) can be attached at a free angle; the bus is connected via a short connector cable between both cases.

The sides, front and back are made of real-wood veneer covered MDF.

Please note: This rack does not include the Master or Power module. To connect the case to power you have the following options:

Connect the case to your system via the Hinge Kit 1 or 2 (only for cases newer than 2019)
Connect the case to your system via the Racklink Module (works for all cases)
Install the Master Module
Install the Power Module

Whichever option you decide on, you will also need to order and install 2x Bus Cables, but be careful to order the correct size! Standard Bus Cable for Standard Case size, etc.

Notes: EcoSynth is a small, portable Eurorack modular case solution, designed for your desktop! It's a practical solution designed to save your hard-earned cash for modules. If you're looking for a small desktop solution to augment other desktop electronic hardware, this is for you. If you need a larger case, EcoSkiff passes on the savings for more traditional size racks like 84HP and 104HP.

Save on money and space: get just as much HP as you need!

Available in the following sizes:
24HP
44HP
64HP
84HP
104HP

Features and specifications:

Over-current protection: shuts off each power rail automatically if modules use too much current on that rail
The skiff goes together with just a Phillips head screwdriver!
Comes with 3mm slide nuts
Max module depth: 44mm
Max module depth above power supply: 33mm

Specifications, 24HP-44HP:
Power output:
+12V @ 1A
-12V @300mA
5V@ 150mA
Power connectors: 2 (plus optional flying bus cable)

Specifications, 64HP-104HP:
Power output:
+12V @ 2A
-12V @750mA
5V@ 1.5A
Power connectors: 15
Daisy chains to another EcoSkiff, Skiff Power, Five Amp Power, or Schottkey DC

Requires a 12V 5A center positive power brick with a 5.5mm x 2.1mm tip.
Assembly required, but no soldering needed.

Notes: EcoSynth is a small, portable Eurorack modular case solution, designed for your desktop! It's a practical solution designed to save your hard-earned cash for modules. If you're looking for a small desktop solution to augment other desktop electronic hardware, this is for you. If you need a larger case, EcoSkiff passes on the savings for more traditional size racks like 84HP and 104HP.

Save on money and space: get just as much HP as you need!

Available in the following sizes:
24HP
44HP
64HP
84HP
104HP

Features and specifications:

Over-current protection: shuts off each power rail automatically if modules use too much current on that rail
The skiff goes together with just a Phillips head screwdriver!
Comes with 3mm slide nuts
Max module depth: 44mm
Max module depth above power supply: 33mm

Specifications, 64HP-104HP:
Power output:
+12V @ 2A
-12V @750mA
5V@ 1.5A
Power connectors: 15
Daisy chains to another EcoSkiff, Skiff Power, Five Amp Power, or Schottkey DC

Requires a 12V 5A center positive power brick with a 5.5mm x 2.1mm tip.
Assembly required, but no soldering needed.

Notes: EcoSynth is a small, portable Eurorack modular case solution, designed for your desktop! It's a practical solution designed to save your hard-earned cash for modules. If you're looking for a small desktop solution to augment other desktop electronic hardware, this is for you. If you need a larger case, EcoSkiff passes on the savings for more traditional size racks like 84HP and 104HP.

Save on money and space: get just as much HP as you need!

Available in the following sizes:
24HP
44HP
64HP
84HP
104HP

Features and specifications:

Over-current protection: shuts off each power rail automatically if modules use too much current on that rail
The skiff goes together with just a Phillips head screwdriver!
Comes with 3mm slide nuts
Max module depth: 44mm
Max module depth above power supply: 33mm

Specifications, 24HP-44HP:
Power output:
+12V @ 1A
-12V @300mA
5V@ 150mA
Power connectors: 2 (plus optional flying bus cable)

Specifications, 64HP-104HP:
Power output:
+12V @ 2A
-12V @750mA
5V@ 1.5A
Power connectors: 15
Daisy chains to another EcoSkiff, Skiff Power, Five Amp Power, or Schottkey DC

Requires a 12V 5A center positive power brick with a 5.5mm x 2.1mm tip.
Assembly required, but no soldering needed.

Notes: ***B-STOCK: Box opened, product in perfect working order***


This AC Power Adapter comes with a locking DC extension cable. The connector of the DC extension cable screws down to the DC jack, preventing noise interference when the cable is bumped.

There are two voltage options:
12V: used with original 5A Power Supply and newer Five Amp Power.
19V: used with Deluxe Power, Super Power, Case Power Mini and Case Power.
Note: If you are replacing a power brick on a Synthrotek power supply, use the same voltage as was originally sent (unless the brick is 15V, then change to it to 19V).

AC input: 100-240V, 1.6A, 50-60Hz

DC output:
12V at 5A
19V at 4.74A

Center positive 2.1mm pin

Comes with a 3-prong power cable, which will work in the US and some other countries. If you are in Europe, etc. you can get a separate volex connector that will work in your country. We don't carry international connecting cables, but you can find them easily on the web.

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Colours may vary.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: These PVC patch cables feature multi strand, oxygen free copper wire with a custom compact barrel. Thicker than your average patch cable with extra shielding for less interference and clearer signals. A standard for all EuroRack systems.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Slim connector barrel
Reliable and robust, designed to be easy to patch
Cables built to high specification 28awg *1C
High density oxygen free spiral copper shielded wire for smoothest signal transfer
Planet friendly recyclable cable
Pack of 5 cables

Notes: Add a bit of fun to your EuroRack synth with these new glow in the dark patch cables. They work best when charged under a light source briefly.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Reliable and robust, designed to be easy to patch
Available in 15cm, 30 cm or 50cm
Cables built to high specification multi strand copper 26 awg *1C with foil shielding
Planet friendly and recyclable
Pack of 5 cables

These glow in the dark cables have not been anywhere near nuclear reactors or other sources of radiation!

Notes: Add a bit of fun to your EuroRack synth with these new glow in the dark patch cables. They work best when charged under a light source briefly.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Reliable and robust, designed to be easy to patch
Available in 15cm, 30 cm or 50cm
Cables built to high specification multi strand copper 26 awg *1C with foil shielding
Planet friendly and recyclable
Pack of 5 cables

These glow in the dark cables have not been anywhere near nuclear reactors or other sources of radiation!

Notes: Add a bit of fun to your EuroRack synth with these new glow in the dark patch cables. They work best when charged under a light source briefly.

Features:

Quality nickel plated 3.5mm Mono TS male connection
Reliable and robust, designed to be easy to patch
Available in 15cm, 30 cm or 50cm
Cables built to high specification multi strand copper 26 awg *1C with foil shielding
Planet friendly and recyclable
Pack of 5 cables

These glow in the dark cables have not been anywhere near nuclear reactors or other sources of radiation!

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features:

Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features:

Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features:

Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features:

Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features:

Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: These high quality braided cables feature multi strand, oxygen free copper wire with Synth Cables' custom space saving compact barrel.

Features
Pack of six cables
Premium stiff braided cable
Quality nickel plated 3.5mm Mono TS male connection
Custom Synth Cables slim connector barrel
Reliable and robust, designed to be easy to patch
Available in 15 cm, 30 cm, 60 cm and 90cm lengths
Cables built to high specification using high density oxygen free 28awg *1C copper wiring

Notes: ILLUMINATOR is an eight channel converter that turns Eurorack and analog CV signals into a voltage that drives LEDs and LED strips, creating a unique light show in sync with your live performance. CV signals coming from your music gear are already pulsating with the different parts and sounds of your track, so there is no need for any kind of programming or light operator.

You can focus on playing your set and let ILLUMINATOR take care of the rest, creating a dynamic visual show that follows your tracks down to every note and beat!

No presets, no memory- just your music driving the lights. Create intense strobe-like effects by connecting rapid hi-hats from your analogue drums, or use slow external LFOs for a moody ambience during your ambient sessions.

ILLUMINATOR is compatible with standard 12V LED strips that are affordable and widely available. LED strips are flexible and typically come with adhesive on the back, so it's easy to attach them to any objects and surfaces, including irregular and unusual ones. It can be your Eurorack case, synth stands, walls of the venue, furniture and even your body! This way you can create a unique light show that would otherwise require an expensive (and unwieldy!) lighting setup. Everything you need for your ILLUMINATOR show easily fits into a small backpack for just a couple hundred euros.

ILLUMINATOR can also run an art installation, as LED strips are far from its only application. It can drive anything that accepts DC 12V with a current up to 0.5A. You can hook up anything from motors, electromagnets to old-fashioned filament bulbs. It's the perfect beating heart for your weird mechanical steampunk orchestra. Your imagination is the limit!

ILLUMINATOR accepts all types of CV signals in the range from 3 to 20 volts. Each of the eight channels contains an individual trimmer pot that defines the sensitivity of the channel. It not only adjusts the optimal input range for connected CV sources, but it can also set the brightness of each LED strip. Default factory setting for all trimmer pots is made for the range of 5V, compatible with most gear out of the box.

Applying bipolar CV is also possible but the negative part of the signal will not light up the LEDs (everything below zero will be processed as zero).

CV signals can be connected to ILLUMINATOR using Eurorack mini-jacks or PULSAR-23-like pins and alligator clips. PSU DC IN and all outputs are standard DC sockets 5.5×2.1mm center plus.

Technical specs

Number of channels: 8
Supply voltage: DC 12V
Supply voltage socket: 5.5 × 2.1 mm (center plus)
Output voltage: DC 12V
Output LED socket: 5.5 × 2.1 mm (center plus)
Maximum total power of all channels: 48 watts
Maximum total current of all channels: 4A
Recommended maximum current for one channel: 0.5A
Absolute maximum current for one channel: 1.5A
Input voltage range: 3 - 20 Volts
Input impedance / with correct adjustment of the input sensitivity: > 5.7 kOm / 100 kOm
Input sockets: Eurorack mini-jacks and Pulsar-23 / Ornament-8 pins
Number of mini-jack sockets: 8 (1 for each channel)
Number of Pulsar-23 pins: 9 (1 for each channel + 1 common ground)
LED Items: 8
LED Color: 4000K x 2, Red x 2, Blue x 2, Green x 2
LED Length: 1.5 + 3 m cable
LED Power: 4.8 W/M
LED Voltage: DC 12V
LED IP Rate: IP65
Power supply Input: 100 - 240 VAC, 1.5 A, 50/60 Hz
Power supply Output: 12 DC, 5A
Dimensions: 275 x 70 x 40 mm
Weight: 300 g
Box size: 375 x 310 x 85 mm
Box weight: ~ 800 g

Product dimensions
Illuminator: 275 x 70 x 40 mm
Box: 375 x 310 x 85 mm
Net and gross weight
Illuminator net weight: 300 g
Gross weight: ~ 800 g

Notes: Qu-Splitter is a 1 input to 5 output cable hub for splitting signals. These are a great alternative to mult modules as they live outside of your case and take up 0HP. Very useful for common signals like master clock, modulation sources, or even to chain multiple cables together for long reach patching!

- 1 input to 5 outputs
- 0Passive mult
- Great for common signals like master clock, and modulation sources
- Connect two cables together for long reaches
- Color: Black with white artwork

Notes: Whether you need a replacement knob or want to transform your system into a cohesive piece, Qu Bit's soft touch Rogan knobs get the job done!

Soft Touch Rogan Knobs

Used by Qu-Bit Electronix, Mutable Instruments, Make Noise, and more

Available in multiple sizes and configurations

D Shaft Pot compliant

Notes: Whether you need a replacement knob or want to transform your system into a cohesive piece, Qu Bit's soft touch Rogan knobs get the job done!

Soft Touch Rogan Knobs

Used by Qu-Bit Electronix, Mutable Instruments, Make Noise, and more

Available in multiple sizes and configurations

D Shaft Pot compliant
