Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: Future Retro's unique modern take on vector synthesis takes full advantage of an impressive hybrid synth engine. Digital oscillators, ring modulation and complex envelopes meet a multi-mode analogue filter with paraphonic capabilities. Quirky and flexible.

Supplier's Notes:
The Vectra is a unique hybrid synthesizer with a flexible architecture that allows many different forms of synthesis to be realized. It's the best of both worlds... The Vectra utilizes digital oscillators, ring modulators, noise sources, vector mixer, LFO's, complex envelopes, and modulation routings providing many capabilities that would be very difficult to produce with analogue circuitry alone. This allows for accurate tuning, repeatability of complex patches, and patch storage. The Vectra also provides a multi-mode analogue filter, VCA, and final output, as these provide the best sonic qualities.

The Vectra includes a powerful and fun sequencer and arpeggiator, with many new capabilities. Although the Vectra is a self contained instrument, MIDI can be used to interface with other devices.

The Vectra provides four oscillators, white and pink noise sources, four ring modulators, a four-channel mixer, five LFO's, six morphing envelopes, six primary multimode analogue filter types, a main analogue VCA, and numerous internal modulation routings and VCA's controlling modulation amounts.

It really is like having a powerful self-contained semi-modular synthesizer with approximately 500 internal signal routings, and around 256 storable sound parameters.

The synthesizer architecture is designed to allow the greatest flexibility in recreating multiple synthesis techniques of the past while introducing several new innovations. The sound section has been inspired by features of the greatest synthesizers ever made, while not focusing specifically on recreating any instrument in particular. The Vectra is in fact it's own unique self-contained instrument.

The oscillators are digital as this provides the highest degree of tuning stability, while allowing both virtual analogue and digital waveform generations. With features like oscillator Sync, PWM, the new waveform Phase Slice, and Fade features, independent glide times per oscillator, constant beat detuning, and paraphonic voice modes, not to mention FM, AM, ring-modulation, and dedicated LFO's, envelopes, and VCA's per oscillator really make these oscillators a power house.

The four-channel mixer is unique in that it provides an even balance when mixing multiple sources, either manually with the joystick, or applying automated vector mixing, or mixer modulation.


OSCILLATORS (1-4)
Frequency Range: <0.01 Hz to 20.00 kHz
Analogue Modelled Waveforms: Sine, Triangle, Sawtooth, Square, Pulse Width Modulated
Pulse Width Range: 1% to 99%
Pulse Width Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Digital Waveforms: 500
Number of Digital Waveforms per Oscillator: 2
Waveform Modulation Types: PWM, Slice, Fade
Waveform Start: 0 to 255 samples
Waveform Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Waveform Modulation Amount: 0 to 100
Octave Range: -7 to +5
Pitch Tuning: Semitones
Fine Tuning: 128 steps per semitone
Constant Beat Detuning: -/+5.00Hz
Paraphonic Modes: 8 total
Sync: Off/On, 0-360 degrees
Glide Time per Oscillator: 0ms to 14.7 seconds
Key Tracking: On/Off

OSCILLATOR FREQUENCY MODULATION (1-4)
Modulation 1 Source: LFO
Modulation 1 Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO,
Envelope
Modulation 2 Source: Envelope
Modulation 2 Control: Off, Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO,
Envelope

Modulation 3: Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, Filter LFO, Filter Envelope, Amplifier Envelope

Total Modulation Range: 0.5 to 10 octaves
Individual Modulation Amounts: -99 to 100

LFO (1-4, Filter)
Analog Modelled Waveforms: Sine, Triangle, Ramp, Sawtooth, Square, Random
Digital Waveforms: 500
Waveform Start: 0 to 255 samples
Initial Frequency Range: 0.001 to 1001Hz (greater with key tracking and modulations)
Fine Tuning: 128 steps per semitone
Key Tracking: On/Off
Sync: Off/On, 0-360 degrees
Frequency Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope, Filter LFO
Total Modulation Range: 1 to 10 octaves
Modulation Amount: -99 to 100

41

ENVELOPES (1-4, Filter, Amplifier)
Initial Envelope Stages: Delay, Attack, Hold, Decay, Sustain, Release, Repeat/Loop
Modulated Envelope Stages: Delay, Attack, Hold, Decay, Sustain, Release, Repeat/Loop
Normal Envelope Contours: 5
One-Shot Envelope Contours: 4
Looping: On/Off with repeat time
Envelope Times per Stage: 0ms to 14.7 seconds
Sustain Level: 0 to 100%
Key Sync: on/off (retriggering)
Attack Reset: Off/On
Time Modulation Sources: Off, Random1, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y

MIXER
Channels: 4
Audio Sources:
Oscillator (1-4)
Oscillator (1-4) controlled by Envelope (1-4)
Oscillator (1-4) controlled by LFO (1-4)
Ring-Modulation of Osc 1&2, Osc 2&3, Osc 3&4, Osc 4&1
White-Noise
White-Noise controlled by Envelope (1-4)
Pink-Noise
Pink-Noise controlled by Envelope (1-4)
Mixer Types: Manual, Envelope, One-Shot, Key-Synced, Free-Running, Modulated
Automix X:Y Location Stages: 4
Automix Stage Times: 0ms to 14.7 seconds
Mod Mix X:Y Location Stages: 2
Mod Mix Control Sources: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Mod Mix Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO, Envelope,
Filter Envelope
Mod Mix Amount: 0 to 100
Output Gain: 1.00x to 5.00x

ANALOG FILTER
Primary Filter Types: 4p low-pass, 2p low-pass, 1p low-pass, 2p band-pass, 2p high-pass, 2p notch
Filter Frequency Range: approximately 20 Hz to 20 kHz
Resonance: 0 to 100
Key Tracking: Off/On
Modulation 1 Source: LFO
Modulation 1 Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO-4,
Filter Envelope
Modulation 2 Source: Envelope
Modulation 2 Control: Off, Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO-4,
Envelope-4
Modulation 3: Randon1/2, Key1, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, DC+, Mix-1, Mix-2,
Mix-3, Mix-4, LFO-1, Env-1, Amplifier Envelope
Individual Modulation Amounts: -99 to 100
42

ANALOGUE AMPLIFIER (see also Envelope parameters)
Additional Envelope Type: Drone

Envelope Amplitude Modulation Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-
Wheel, Stick X/Y, LFO-4, Envelope-4

KEYBOARD / SEQUENCER
Keys: 29
Scales: 29
Linear Transpose: -12 to +16
Scale Transpose: -12 to +16 notes
Octave Reiterations: -3 to +3
Tempo: 10 to 250 BPM
Swing: 50% to 75%
Sequencer Modes: Play, Arpeggiate, Fill, Edit, Real-time, Auto
Max Steps per Sequence: 16
Sequencer Parts: Pitch, Velocity, Rhythm (Note-On/Off, Glide, Sustain)
Time Signatures: 1-4, 2-4, 3-4, 4-4, 6-4, 8-4
Directions: Down, Up/Down, Up, Random, (plus 25 complex directions)
Loop Point: 1 to 16 steps

MEMORY
Max Number of Sounds and Sequences: 999
Global Parameters Saved: Output level, MIDI Channel, Fine Tuning, Screen Saver Time, Last File

MIDI
Channels: 1-16
MIDI Messages Supported: Note-Pitch, Note-On/Off, Velocity, Aftertouch, Pitch-Bend, Mod-Wheel,
MIDI Sync: Clock, Start, Stop

OTHER
Input/output: 15V DC input, MIDI (IN/THRU/OUT), 1/4" unbalanced Audio Out
Unit Dimensions: (width) 18.25" x (depth) 11.0" x (height) 3.5"
Unit Weight: 5.0 lbs
Power: 15V DC (centre-pin positive) rated at 1 Amp current.

Notes: TERRA is a new SOMA Labs synth.

TERRA is a highly conceptual device. The core idea is unity of nature and technology, and a perfect balance between simplicity and versatility. Behind the extremely simple interface hides a complex polyphonic, microtonal synthesizer with a broad and flexible sound palette that ranges from classical beautiful tones to complex atonal noise, and offers smooth and fast transitions between these extremes.

The innovative keyboard design invites new playing techniques and covers the full range of a grand piano with the possibility to tune each note with an accuracy of 125 steps per semitone. To achieve this range with such a simple keyboard we designed a unique system of pitch shifting using four additional sensors. Pressing different combinations of them will result in 16 variations of keyboard transposing, including up to 3 octaves up and down, fifth, fourth, third, tone etc.

Not only do you get the full range of a grand piano in a very compact design, TERRA also offers an entirely new and different approach to playing melodies and chords.

The keyboard consists of 12-note sensors with velocity and pressure sensitivity allowing for the manual creation of slow attack and vibrato, 4 dynamic sensors for timbre modification and control, 4 pitch-shifting sensors and 2 hold sensors for holding the state of the timbre and note sensors.

Inside TERRA there is a three-axis motion sensor for creating a variety of different modulations by simple intuitive movements of your hands and body.

TERRA is digital and contains 32 complex synthesis algorithms. Each algorithm has been carefully designed to be a complete and flexible musical instrument on its own, ready for learning and playing in its own unique way. The goal is to free the musician from long exhausting programming, setting hundreds of parameters for creating one timbre, and instead putting the focus directly on music and performance and following your imagination and inspiration.

TERRA offers the best of both worlds: the direct intuitive tactile connection from acoustic instruments and the flexibility and versatility of synthesizers. TERRA inherits design principles from LYRA-8 and also contains application of the new principles that were announced for ReFLEX, exploring the future of synthesis.

TERRA has an extremely simple interface that gives you instant access to all its functions in several touches, including saving and loading the 96 presets that are stored directly on the playing sensors. TERRA has no display. Instead it shows and lets you dial all necessary data on the 6 LED-sensor triangle in the centre.

TERRA has a built-in FX processor so the stereo output is ready to use, making it a perfect stand-alone performance instrument. While the sound generation is digital, TERRA has a unique custom-built and top quality analogue part that makes it sound rich, natural, clear and powerful at the same time.

The housing of TERRA comes from a solid piece of wood, making each instrument unique and slightly different. In the photo above and in the announcement demo video you can see the prototype of the synth. The final design is in development and we intend to make several different versions.

TERRA is a sanctuary for a natural soul right in the middle of the rumbling plastic world, a ground where you can breathe in and out slowly, and hold on to your roots.

TERRA is our dream about a bright future where we will be both technologically advanced and more connected to nature, where machines and technology are not a prison for our feelings and spirit but their extension.

Synthesis algorithms: 32
Polyphony: 1-12 voices (depending on the algorithm)
Presets: 96
Pitch Shifter presets: 24
Line out: L, R TS/TRS 1/4-inch jacks / 6.35 mm jacks
Maximum line output signal: 13 V peak-to-peak
Nominal line output signal: ~1.5 V (volume 100%)
Headphone output: TRS 1/4 inch jack / 6.35 mm jacks
Headphones impedance: 6-64 ohm
CV-clock input voltage: 3-15 V
Power supply voltage: DC 12 V *
Consumption current: 0.2 A
DC jack: 5.5 x 2.1 mm, "+" in center
Dimensions: 405 x 365 x 57 mm
Weight: 2.2 kg
* TERRA comes with a high quality power supply . If it gets lost, use a high-quality modern switched-mode power supply with 12 V output voltage, at least 0.4 A maximum current, 5.5 x 2.1 mm DC jack, center "+".

What's included:

TERRA - 1 pc.
Power supply - 1 pc.
CV clock adapter (DIN5 - 3.5 mm mini-jack) - 1pc.
Short interface reference manual - 1 pc.
On-table mounting pads - 4 pcs.

Notes: The kind of instrument Soma Labs do so well: weird but wonderful. Based around 32 complex digital synth algorithms and 12 note velocity- and pressure-sensitive sensors, transposition techniques allow you to play the full range of a grand piano.

Supplier's Notes:
TERRA is a new SOMA Labs synth.

TERRA is a highly conceptual device. The core idea is unity of nature and technology, and a perfect balance between simplicity and versatility. Behind the extremely simple interface hides a complex polyphonic, microtonal synthesizer with a broad and flexible sound palette that ranges from classical beautiful tones to complex atonal noise, and offers smooth and fast transitions between these extremes.

The innovative keyboard design invites new playing techniques and covers the full range of a grand piano with the possibility to tune each note with an accuracy of 125 steps per semitone. To achieve this range with such a simple keyboard we designed a unique system of pitch shifting using four additional sensors. Pressing different combinations of them will result in 16 variations of keyboard transposing, including up to 3 octaves up and down, fifth, fourth, third, tone etc.

Not only do you get the full range of a grand piano in a very compact design, TERRA also offers an entirely new and different approach to playing melodies and chords.

The keyboard consists of 12-note sensors with velocity and pressure sensitivity allowing for the manual creation of slow attack and vibrato, 4 dynamic sensors for timbre modification and control, 4 pitch-shifting sensors and 2 hold sensors for holding the state of the timbre and note sensors.

Inside TERRA there is a three-axis motion sensor for creating a variety of different modulations by simple intuitive movements of your hands and body.

TERRA is digital and contains 32 complex synthesis algorithms. Each algorithm has been carefully designed to be a complete and flexible musical instrument on its own, ready for learning and playing in its own unique way. The goal is to free the musician from long exhausting programming, setting hundreds of parameters for creating one timbre, and instead putting the focus directly on music and performance and following your imagination and inspiration.

TERRA offers the best of both worlds: the direct intuitive tactile connection from acoustic instruments and the flexibility and versatility of synthesizers. TERRA inherits design principles from LYRA-8 and also contains application of the new principles that were announced for ReFLEX, exploring the future of synthesis.

TERRA has an extremely simple interface that gives you instant access to all its functions in several touches, including saving and loading the 96 presets that are stored directly on the playing sensors. TERRA has no display. Instead it shows and lets you dial all necessary data on the 6 LED-sensor triangle in the centre.

TERRA has a built-in FX processor so the stereo output is ready to use, making it a perfect stand-alone performance instrument. While the sound generation is digital, TERRA has a unique custom-built and top quality analogue part that makes it sound rich, natural, clear and powerful at the same time.

The housing of TERRA comes from a solid piece of wood, making each instrument unique and slightly different. In the photo above and in the announcement demo video you can see the prototype of the synth. The final design is in development and we intend to make several different versions.

TERRA is a sanctuary for a natural soul right in the middle of the rumbling plastic world, a ground where you can breathe in and out slowly, and hold on to your roots.

TERRA is our dream about a bright future where we will be both technologically advanced and more connected to nature, where machines and technology are not a prison for our feelings and spirit but their extension.

Synthesis algorithms: 32
Polyphony: 1-12 voices (depending on the algorithm)
Presets: 96
Pitch Shifter presets: 24
Line out: L, R TS/TRS 1/4-inch jacks / 6.35 mm jacks
Maximum line output signal: 13 V peak-to-peak
Nominal line output signal: ~1.5 V (volume 100%)
Headphone output: TRS 1/4 inch jack / 6.35 mm jacks
Headphones impedance: 6-64 ohm
CV-clock input voltage: 3-15 V
Power supply voltage: DC 12 V *
Consumption current: 0.2 A
DC jack: 5.5 x 2.1 mm, "+" in center
Dimensions: 405 x 365 x 57 mm
Weight: 2.2 kg
* TERRA comes with a high quality power supply . If it gets lost, use a high-quality modern switched-mode power supply with 12 V output voltage, at least 0.4 A maximum current, 5.5 x 2.1 mm DC jack, center "+".

What's included:

TERRA - 1 pc.
Power supply - 1 pc.
CV clock adapter (DIN5 - 3.5 mm mini-jack) - 1pc.
Short interface reference manual - 1 pc.
On-table mounting pads - 4 pcs.

Notes: Keyboard version of Akai's iconic MPC workstation, combining the classic MPC sampling and sequencing approach with 16 pads and a 37-note synth keybed. A superb all-rounder for any production style.

*** Introducing MPC Stems- March 2024 ***

Akai Professional now introduces the next chapter of sampling innovation and production powered by the groundbreaking MPC Stems bringing sampling into a new chapter.

With MPC Stems, you can access the raw building blocks of any sample or vinyl record, isolating the DNA of any record. Producers can now manipulate the Drums, Bass, Music, and Vocals, opening new creative possibilities.

Akai Professional introduces the ultimate creative workflow with Stems Separation seamlessly integrated into the leading MPC series, powered by MPC 2 Desktop Software.

With MPC Stems, producers and beat-makers can now unlock unmatched sampling creativity by easily isolating drums, bass, music, and vocals from any audio, vinyl recording, or sample revolutionizing the art of sampling.
Experience lightning-fast workflow with superior sound quality, keeping you inspired throughout the creative process.

Slice and isolate samples while maintaining chop regions across each of the four stem layers.

Take complete control with direct manipulation of stem layers from the pads, adjusting volume, pitch, pan, start, and end points with instant responsiveness.

MPC Stems requires MPC 2 Desktop Software running 2.14 or higher, compatible with MPC Live, MPC Live 2, MPC One, MPC One +, MPC X, MPC XSE, MPC Key 37, MPC Key 61, MPC Studio Mk 2 in Controller Mode.


Supplier's Notes:
Introducing the Akai Professional MPC Key 37; a standalone keyboard workstation that has everything you need to produce music out of the box. The iconic MPC range has been the centrepiece of beatmakers' and producers' studios for over three decades, evolving into a production platform that combines sampling, sequencing and synthesis into a lightning-fast workflow that keeps you focused on your music. MPC Key 37 brings together the familiar 16 pad grid together with a synth-styled 37 note keybed; along with legendary MPC sounds and instruments, and all the connectivity you need to integrate with your outboard gear and computer - in a compact footprint.

Sound

MPC Key 37 ships with a core collection of sounds and samples from Akai MPC's industry standard plug-ins.

There are 8 plug-in instruments out of the box: including Hype, Odyssey, Mellotron and more; and over 10GB of production ready samples and drum kits. Together these offer over 1000 production-ready presets and if you want to dive deeper each plug-in instrument features advanced synthesis, deep parameter editing, and effects for programming in the exact sound you need. With 32GB of internal storage (plus removable media via SD Card and USB) there is enough space to expand your sample and instrument library in whatever direction you need to take it.

Effects

MPC Key 37 includes over 100 powerful studio-quality effects for creative production and mixing.

Insert lush Reverb & Delay effects into your tracks, add bounce and punch to your drums and mix using modern or vintage style compressors and limiters. MPC Key 37 also ships with cutting edge vocal FX plugins which can also be used for straight vocals or creative sound design.

Control surface

The MPC Key 37 features a synth action key-bed with aftertouch, alongside separate pitch and modulation wheels. The synth-style keyboard action has been designed with players and producers in mind; whether tracking basslines into your productions or jamming out synth leads on stage. The 16-velocity sensitive RGB pads are the same award-winning pads as the MPC One+, along with the renowned Time Correct, Swing, and Quantize features of MPC that continue to inspire producers at the top of the industry. Tweaking and editing take place on the 7' multi-touch display and 5 Q-link rotary encoders, giving you fine control as well as quick access to the parameters you need at your fingertips.

Connectivity

MPC Key 37 can also act as a hub for your outboard gear: Connect MIDI devices via USB or using the MIDI DIN In/Out ports; and integrate with modular rigs with the 8 CV/Gate outs. Onboard WiFi/Bluetooth allows for wireless synchronization with Ableton Link and MPC OS Updates, and the SD Card Reader allows for volumes of expandable sounds and tracks.

DAW Integration

MPC Key 37 features a built in 2-in 2-out USB audio/MIDI interface, so you can record audio and MIDI directly in and out of your computer. The included MPC software is a standalone DAW on your Mac or PC, so you get all the tactility and control of the hardware, but with as many tracks as your computer can handle. MPC software also comes as a VST/AU plug-in so you can open it in major DAWs such as FL Studio, Logic, Ableton, Pro Tools, Studio One and more, and combine your favourite workflows.

Notes: Xena is a rework of the legendary Mutable Instruments Ambika DIY synthesizer. Now fully machine assembled with an updated layout and an improved modern power supply.

Xena Features:

6 voices with individual outputs.
2 digital oscillators per voice, with 36 oscillator algorithms/wavetables.
1 sub-oscillator, also configurable as a transient generator.
Pre-filter overdrive and bit-crushing effect.
Analog 4-pole filter and VCA.
3 ADSR envelopes, 3 patch-level LFOs, 1 voice-level LFO.
Modulation matrix with 14 slots and 4 modulation modifiers.
1 arpeggiator, 1 note sequencer and 2 step sequencers per part.
Flexible mapping of the 6 voices. A single patch with 6 voice-polyphony, 6 independent mono parts, 2 layered patches with 3-voices polyphony, a 3-voice unison bass line on the lower half of the keyboard with a 3-voice unison lead on the upper half... all are possible!
MicroSD storage allows the storing of a life-long of patches, programs and multis, along with the history of editing operations for undo/redo.
Easy to change voice cards

Filter Options:

SMR Filter: This filter uses the same topology as the Shruthi SMR4mkII. It is a low pass 4 pole OTA-C filter. It is a smooth "Rolandish" type filter

Includes:

Xena Desktop Synth
12V DC universal (100-240V) Power Supply
Preformatted SD card

Notes: Combining analogue-style sound with digital convenience, the KingKorg Neo is a proper all-rounder for both recording and live performance. Features modelled emulations of classic Korg synth features.

Supplier's Notes:
The KingKORG NEO: a virtual analogue synthesiser that stands out with its analogue-like layout and intuitive, flexible editing. This compact powerhouse features 37 full-size keys and a versatile vocoder, making it perfect for both studio and stage. With our cutting-edge XMT sound engine, it delivers a wide range of classic and futuristic sounds. Designed for the contemporary musician, the KingKORG NEO is the ultimate tool for exploring new soundscapes and pushing musical expression.

KingKORG NEO features our XMT virtual analogue sound engine. XMT stands for eXpanded Modelling Technology and was created to offer an expansive array of sounds while ensuring simplicity in operation.

Gone are the days of laborious oscillator adjustments for sound crafting. The KingKORG NEO streamlines this process with pre-set algorithms. These carefully designed combinations of different oscillator types and quantities empower you to quickly shape rich, stage-ready tones with ease.

Embracing the demand for diverse tonal capabilities, the KingKORG NEO comes loaded with a wide range of oscillator algorithms. From the classic sawtooth and square waves to the more intricate noise patterns typical of analogue synthesizers, and extending to PCM/DWGS, this synthesiser is equipped to cater to an extensive variety of musical needs and preferences.

Crafting character with iconic modelled filters

In the heart of the KingKORG NEO lies its meticulously designed filter section, a cornerstone in defining the synthesiser's unique sonic character. Korg have infused KingKORG NEO with a diverse range of filters, each adding a distinct flavour to your sound creations, an aspect where analogue modelling truly shines.

The KingKORG NEO's filter collection is a treasure trove for sound designers. It encompasses a wide array of essential analogue modelling filter types, enabling you to sculpt sounds with precision and ease. But there's more. Korg have painstakingly modelled filters that echo the iconic analogue monophonic synths of the '70s - the go-to for punchy leads and deep basses. Korg have also captured the essence of polyphonic synths from the vibrant new wave era of the '80s, and the legendary filters from Korg's own MS-20 analogue synth.

One of the most captivating features of these filters is their ability to self-oscillate when you dial up the resonance - a hallmark of classic analogue synthesis. This capability opens up a world of sonic possibilities, from creating ethereal textures to crafting powerful, resonant tones.

Vocoder wizardry

KingKORG NEO synth comes equipped with a balanced XLR input on its front panel, and includes a rugged, high-quality microphone. This setup invites you to dive into the world of vocoding instantly.

At the core of the KingKORG NEO's vocoder is a sophisticated 16-band filter, rivalling dedicated vocoder machines. This powerful feature allows you to craft classic vocoder tones, but that's just the beginning. By shifting the filter frequency with the formant shift function and finely adjusting the level and pan of each band, you open the doors to an array of unique and original sounds. Whether you're aiming for vintage charm or contemporary edge, this vocoder adapts effortlessly to any genre or style.

But there's more - the KingKORG NEO redefines flexibility. Timbre B can ingeniously be used as a modulator, providing an alternative to the traditional microphone input. This allows the vocoder effect to be seamlessly blended with the synth sound, paving the way for limitless sonic exploration.

Moreover, each of the three oscillators, A and B timbres, can be individually selected as a source for the microphone input. This unique feature enables you to synthesize a rich mix of voice and instrument, creating a fusion of timbres that's both innovative and captivating.

Masterful effects

The KingKORG NEO elevates your sound with three master effect slots, each offering six distinct effect types.

The PRE FX slot brings the grit and edge of effects like distortion and amp simulator. MOD FX infuses your tracks with the classic charm of phaser, chorus, and tremolo. For creating expansive atmospheres, the REV/DELAY slot offers ambient effects including hall reverb and modulation delay. Adjusting and selecting these effects is straightforward, thanks to dedicated dials on the front panel for each slot, complemented by FX control knobs for detailed fine-tuning.

Virtual patching

Embrace the spirit of classic synthesisers like the MS-20 with the KingKORG NEO's innovative Virtual Patch system. This intuitive feature brings the flexibility of physically patching synthesizers into the digital age. With six Virtual Patch assignments available for each timbre, you can virtually connect control signals like EG, LFO, or joystick movements to key sound parameters, including pitch and cutoff. This seamless integration allows for intricate modulation and a deeper exploration into sound-shaping, giving your music a new dimension of sonic creativity.

A universe of inspiration

KingKORG NEO's extensive library of 200 stage-ready preset programs is created for the modern music maker. These presets span across eight categories like SYNTH, LEAD, and BASS and offer an intuitive gateway to finding the perfect sound for any scenario.

Step up with arpeggiation

The KingKORG NEO comes equipped with a versatile step arpeggiator, a tool that breathes life into your performances by automatically generating arpeggio phrases based on the chords you play. Tailor your sound even further by selecting from six different arpeggio types. You can specify the duration, interval, and on/off status of each step, opening up a vast array of rhythmic possibilities.

Specifications

Keyboard: 37 keys (velocity and release-velocity sensitive)
Sound generating system: XMT (eXpanded Modeling Technology)
Maximum Polyphony: 24 voices
Timbres: Max. 2 timbres (Layer / Split)

Oscillator
Structure: 3 oscillators (choose from analog, noise, DWGS, PCM, and MIC IN types)
Number of types: 138 types (32 analog and noise, 40 DWGS, 65 PCM, 1 MIC IN

Filter
Structure: 1 filter (choose from LPF, HPF, BPF)
Number of types: 18 types (7 LPF, 5 HPF, 6 BPF)

Modulation
Structure: EG 2 units, LFO 2 units
Routing: Virtual patches 6 set

Effect
Sections: Program effects x 3 (PRE FX, MOD FX, REV/DELAY) + EQ (2Band)

Types:
PRE FX: 6 types (DISTORTION, DECIMATOR, RING MOD, GT.AMP, EP.AMP, TONE)
MOD FX: 6 types (FLANGER, CHORUS, U-VIBE, TREMOLO, PHASER, ROTARY) REV/DELAY: 6 types (HALL, ROOM, PLATE, TAPE ECHO, MOD DELAY, BPM DELAY)

Vocoder: 16-band vocoder, formant shift function, formant hold function
Arpeggiator: Up to 8 steps (number of steps can be changed), 6 types (UP/DOWN/ALT1/ALT2/RANDOM/ TRIGGER)

Programs
Number of programs: 300 programs (200 preset / 100 user)
Number of categories: 8 categories

Displays
Main: 16 x 2 character OLED display
OSCILLATOR, FILTER: 128 x 64 pixel OLED display

Audio

Mic input
Connector: XLR type (balanced)
L/MONO,R output
Connectors: 6.3mm TS phone jacks (Unbalanced)

Headphone output
Connector: 6.3mm (1/4") stereo phone jack
DAMPER (half-damper not supported)
SWITCH/PEDAL
MIDI IN/OUT
USB B connector

Power Supply: AC adapter jack (DC12V)
Power consumption: 9W
Dimensions (W x D x H)@ 565 x 338 x 92 mm / 22.24" x 13.31 " x 3.62
Weight: 3.1kg / 6.83 lbs.
Included items: AC Adapter, Vocoder mic (+ windscreen)
Accessories (sold separately): XVP-20: Expression/volume pedal, EXP-2: Foot controller, DS-1H: Damper pedal, PS-1, PS-3: Pedal switch

Notes: Celebrating the 50th anniversary of this truly iconic synth, the 'modern' take on the classic Buchla Music Easel doesn't mess with a winning formula, paring the 208C sound source with 218e touch-sensitive keyboard.

Supplier's Notes:
The Buchla Music Easel was one of the first truly portable electronic music instruments. Fifty years ago, in 1973, only a few dozen were made. Unlike many iconic technologies, the influence was not grown through force of scale, but rather the force of the ideas. The Music Easel made available virtually every musical dimension: timbre, melody, rhythm, and time; how these dimensions intersected was no longer the court of acoustics and material, but signals and voltage. The 208 Stored Program Sound Source engendered "a new functional organization [with a] particularly rapid system of patching and program storage via plug-in cards."

Taking cues from the then-recent discipline of cybernetics, the 218 touch plate was for "real-time communication" to help realize the "potential vocabulary" of the Easel, rather than exploiting existing modes of musical virtuosity. The Stored Program Cards ensured rapid repeatability and repertoire on its own terms. The battery terminals made sure the music was as portable as any acoustic instrument. And the name let you know it was designed for art rather than science.

Buchla is ecstatic to revive the Music Easel for its third run in 50 years. Buchla first released the updated 208 Stored Program Sound Source, dubbed the Easel Command, with expanded MIDI and USB capability. Next came the update of the Easel Program Manager - a complete kit for storing and recalling sounds sources, even more rapidly than imagined in 1973. The new 218 Touch Activated Voltage Source provides the optimal input facility, as originally envisioned. It is now all together in a rugged case and the advanced EMBIO module that unifies all the audio and control inputs and outputs for integration with the rest of your musical world.

More than a retro novelty, the Music Easel still speaks to a future we strive for. A technology that invites conversation, not chats, and controls that engage expression, not work. There are many new worlds to explore in this instrument created at the crossroads of the jazz and computer ages. Designed as "an integrated assemblage of functions", rather than a collection of modules, the Music Easel's colour coding, comfortable access to controls, and solid patch connections allow for satisfying sessions of sonic discovery.

The Music Easel is available for pre-order starting June 16 at Buchla.com and your favourite Buchla Dealer. Delivery of the Music Easel (modern) is expected fall 2023.

Stored Program Sound Source Model 208C

The sound source of the Music Easel is the 208C, which includes a complex oscillator and a modulation oscillator (which can also serve as another voice), each with independent switchable waveforms, as well as a noise generator, allowing for rich and intricate sound design. The 208C also features a five-stage sequencer, envelope generator, pulser and modulation source - with switchable triggers - allowing for complex patterns and evolving textures. The dual low pass gate provides dynamic control over the tone and amplitude of the sound, as well as natural-sounding decay and sustain. The 208C has a number of modulation sources, including a random voltage generator, the envelope generator, modulation oscillator, and an envelope detector. These sources can be used to modulate various parameters via the extensive patchfield - creating movement, texture, and complexity. The 208C also includes a mixer section with spring reverb.

Touch Activated Voltage Source Model 218e (v3)

The first design appeared in the 1973 release of the Buchla Music Easel and named for the spacecraft that delivered astronauts to the moon. Providing the familiar piano key layout for this early mobile music machine, the additional controls and capabilities were an interface for exploring uncharted musical territory. With the new version 3, it's been elevated with a new foundation of stable, modern electronics with incredible sensitivity and accuracy - the lightest touch will produce triggers and control voltages. The adjustable sensor has the dynamic range and durability to handle your playing. The new texture not only improves the sensing, but provides a satisfying tactile experience. As always, pressure is an expressive output, adding an extra dimension to the control. MIDI outputs velocity and polyphony, as well as channel pressure, making the 218e a uniquely expressive controller. The 218e includes portamento and an arpeggiator, which can be driven by external inputs and are allowed to interact with the automated notes to make patterns more complex. Additional controls allow you to blend different patterns and randomness to easily change from the expected to the surprising. The classic preset voltage knobs offer several possible ways to shift your sounds into new territory. Not only can the knobs be used for quick access to voltages for your patch, they can control arpeggiation modes and octave shifting. Pads output pulses for additional control. The 218e also gives you a unique interface to playing your existing MIDI gear and soft synths. Each touch outputs note name, channel pressure, and velocity for every note, along with sustain controls from a pedal. Polyphonic MIDI mode lets you play chords. The touchstrip can act as a pitch bend control, or as a mod wheel for additional expressive control. Easily configured using the front panel controls, you can send notes and controls on any MIDI channel.

Electric Music Box Input/Output (EMBIO)

Maintaining the spirit, sound, and process from the original, the new Music Easel adds a variety of new features. Buchla's latest renditions of the Stored Program Sound Source and Touch Activated Voltage Source are tied together with the Electric Music Box Input/Output (EMBIO) module. This of course provides MIDI out (mini jack and USB) and CV out from the 218, MIDI in to the 208, and the audio out from the 208C. Additional creative control comes from the Audio Mixer, for integration with other Buchla modules and systems, and the CV conditioners and controls. The slew control can turn your sequencer into a wavy modulator, or soften up a square LFO. The attenuator and crossfader gives you the opportunity to find new levels and combinations of voltages from existing ones. The pulse converter offers new rhythms to trigger. And a simple LFO provides another valuable modulator when you just can't quite let yourself flip that Mod Osc switch from "high" to "low."

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: ***B-STOCK: Item refurbished, repaired and in perfect working order.***


Premium version of the excellent Opsix, Korg's contemporary take on FM synthesis. Full 61-note natural-touch keybed with aftertouch, 80-voice stereo polyphony and full metal construction.

Supplier's Notes:
The Ultimate Union of Power and Performance

opsix SE is a digital synth like no other. With a premium all-metal design, 61-keys, and aftertouch, it unlocks a new world of sonic capabilities. Building on the expansive sound engine in the original opsix, opsix SE enhances it with increased polyphony and voicing, resulting in a synthesizer created for superior performance and precise control.

The opsix Operator Mixer simplified FM synthesis for the first time, making it not just comprehensible but also controllable. With the addition of extra synthesis capabilities and programming, it offered a more efficient workflow and an even richer sound.

The opsix SE takes this even further. It is equipped with Korg's premium 61-key natural-touch keyboard, complete with aftertouch, delivering the exceptional tactile experience expected from Korg's flagship workstations. With a sleek, robust metal body, it's built for both the intensity of live gigs and the precision of studio sessions. The metallic knobs are optimally weighted for effortless adjustments. Underneath its exterior, the opsix SE boasts an incredible capacity of 80 stereo voices of polyphony.

The opsix SE arrives preloaded with hundreds of sounds enhanced for aftertouch control. Moreover, it is fully compatible with the sounds and samples from both the original opsix and the opsix Native software, including numerous high-quality libraries.

Build to play

opsix SE was born out of the desire to play this incredible synth with both hands. Equipped with KORG's premium 61-note natural-touch keyboard, the opsix SE offers the same outstanding tactile response as KORG's top-tier workstations. Aftertouch puts unparalleled control of all the exceptional opsix sounds at your fingertips. Of course, we've modernized the factory Performances for aftertouch and introduced some fresh ones to the mix as well. In fact, most of the opsix SE programs have been revised to make full use of aftertouch, extended keyboard, and polyphony.

Premium metal design

The opsix SE showcases a notable upgrade in aesthetics. A slim body, specifically designed for this instrument, features a striking brown painted aluminium control panel, paying homage to vintage machines. Together with the vivid, illuminating LEDs, it brings a vibrant energy to any stage performance. The side panels, painted in a sleek black metal, amplify the overall aesthetics for a luxurious finish.

Exclusive hard case included

The opsix SE ships in a dedicated hard case, including space for cables and a sustain pedal. Your instrument can travel protected, whether you're carrying it to a rehearsal downtown or packing it up for a tour.

Get Illuminated with the Operator Mixer

At the heart of every sound is opsix SE's Operator Mixer - a simple set of six faders and knobs that invite exploration. Each part lights up red to indicate carriers or blue for modulators. Manipulating them opens up new sound-shaping possibilities to breathe fresh life into your musical ideas. This straightforward, hands-on workflow is part of what makes opsix SE so unique, just like the sounds it offers.

Direct Hands-On Control

Whether you're tweaking a preset or building a patch from the ground up, the six data entry knobs on the right give you quick access to the parameters you need and seamlessly sync with the large OLED display, giving you a clear, focused direction to your workflow. Coupled with the mixer, it makes creating fresh sounds super easy and, most importantly, fun!

Select from a full range of analogue-style filters, from the radical Korg MS-20 low-pass/high-pass filter to the powerful yet smooth KORG Polysix low-pass filter that gives your sound a vintage feel. There are also two or four-pole low-pass, high-pass, band-pass, and band-reject filters with resonance.

There's even a built-in spectrum analyser and oscilloscope that gives you visual feedback via the screen on the music you're making.

Six in One Synthesis

The core of opsix is nothing short of exponential. Since waveforms can be arranged and modulated in nearly infinite ways, opsix can easily do the sonic work that is similar to numerous types of synthesis:

Subtractive

Removing parts of the sound to get the sound you want; the most widely-used synthesis. opsix uses up to six envelopes and multi-modeled filters to achieve many cutting-edge and classical analog synthesis tones.


Semi-Modular
Rerouting signal paths to change the sound. A spin through the Alogorithm section will dramatically reshape the sound by changing how the signal routing between the operators work together, and no patch cables are needed.


Analog (Modelling)
Analog-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.


Waveshaping

Adding intentional distortion to the waveforms to achieve aggressive overtones that are either harmonic or inharmonic. This will help you achieve gritty, bitey tones dripping with character.


Additive

Stacking waveforms and blending their harmonics is key to an expansive range of harmonious, dissonant, and tension-driven sounds. With six operators available, the complete FM experience is possible, including the ability to go back in time for classic sounds you have heard throughout recording history.


Classic FM

Last but certainly not least, opsix's highly flexible and powerful architecture starts with true six-Operator FM. As a result, it easily delivers signature sounds you have surely heard on thousands of hits from the '80s on through today, and with far more polyphony than other standalone FM synths available today.

With all of these ways to realize and explore sounds, opsix SE is uniquely suited as a "future-modern-classic" synth!

Altered Reality

opsix SE is FM-based, but the similarities to the classic synthesis end there. The Altered FM architecture delivers sounds across a vast spectrum, far wider than any single synthesis has been able to cover before, thanks to new sound components; new waveforms, filters, shaping, effects, LFOs, envelopes, modulations, and more, all translating to its broad assortment of sounds.

Powerful Effects Processing

opsix SE provides three blocks of 30 types of high-definition effects that you can use together to enhance your sounds even further. There's everything from a great mix of usable standard effects like chorus, phaser, delay, and compressor to some world-class shimmering reverbs that will elevate your sound to the next level.

Automatable 16-step sequencer

opsix SE features an incredible step sequencer that rivals groove boxes for flexibility and power. Press the PLAY button on any sound and experience the complexity of the sequences! Every Program has its unique sequence stored with it, or create your very own.

You can record up to six notes per step and edit each note's velocity, gate time, and playback timing. Create long phrases or make subtle shifts in timing to emulate strums or drum rolls, something that's not possible on a typical 16-step sequencer. The motion sequencer of the opsix SE also lets you record changes of up to six parameters, creating smooth motion changes in sound within a phrase or building rhythms that change dramatically with each step.

Notes: Red version of Cyclone's excellent bass synth, replicating the sound of the iconic Roland TB-303. Fully analogue synth with modernised sequencer and classic acid sound.

Supplier's Notes:
A full analogue synth clone of the famous TB303, coming with a lot of new features and improvements, from the sound point of view as well as the ergonomics of the machine and the sequencer.

A new design, new pots very smooth, new features for Live jam, 2 new sequencer modes for even more creativity, added CV / Gate (and even more) outputs to play your favourite synths!

The design of the analogue circuit (composed of 1 VCO) and the audio engine has been improved compared to the previous version, giving it a warm and groovy sound thanks to the addition of the Shuffle (not present on the original).

The very intuitive sequencer takes on the original spirit while bringing new and unique features such as Mute and Hammer, which gives it a great flexibility for live jam and more sound variations, as well as 2 new sequencer modes to create New patterns.

Specifications

Bass Bot TT-303

VCO

Monophonic
Waveforms: Sawtooth or Square
Frequency Range: 20Hz-850Hz

Main Controls

Tempo Knob
Volume Knob
Track/Pattern Bank Selector Knob
Mode Selector Knob
Power On/Off Switch

Audio Controls

Tuning Knob
Filter Cutoff Frequency Knob
Filter Resonance Knob
Filter Envelope Modulation Amount Knob
Filter Envelope Decay Knob
Accent Amount Knob
Waveform Selector Switch

Data Storage

User Patterns: 432 (9 banks of 48 patterns)
Pattern Lab Patterns: 108 (9 banks of 12 patterns)
Preset Patterns: 108 (9 banks of 12 patterns)
User Tracks: 9

Operating Modes

Pattern Write | Loop Edit |Pattern Lab | Arpeggiator
Pattern Play | Preset | Track Play | Track Write | MIDI

Per-step Modifiers

Down Octave | Up Octave | Accent | Slide
Mute | Hammer | Rest / Tie

Pattern Features

Pattern Length: 1-64 steps
Per-step modifier assignment
Time scales: 16th note, 32nd note, 8th note triplet,
16th note triplet
Assignable pattern LED color
Pattern Copy / Paste functions
Intelligent procedural pattern generator
Pattern-based Arpeggiator
Pattern Mutate function

Track Features

Visual track programming system
Maximum Length: 144 bars | Per-bar transpose option

Global Features

Shuffle Amount | Slide Time | Gate Length |
Illuminated buttons: 26
Tap Tempo Input | Automated VCO calibration |
System LED colour |
MIDI In / Out channels

Outputs

Main Mix (1/4" mono, +15dBu)
Headphone (1/4" stereo, +10dBu)
VCO Waveform (1/8", Sawtooth: 5Vp-p, Square: 3.7Vp-p)
Control Voltage (1/8", 1V/octave, range 1V 5V)
Gate (1/8", 0V 12V)
Accent On (1/8", 0V 5.5V)
Clock (1/8", DIN Sync compatible, 0V 5V)
Start/Stop (1/8", DIN Sync compatible, 0V 5V)
MIDI Out / Thru

Inputs

Filter In (+4dBu nominal, 100kO input impedance)
Power (9VDC, 300mA) | MIDI In

PC Functions

Cyclone Studio application for PC & Mac enables Bass Bot software update and user data backup & restore using MIDI/SysEx transfer.

Physical

Dimensions: L310mm x W130mm x H35mm
Weight: Unit 783g (Boxed with accessories) 1.332kg

Included Accessories: 100-240v Universal Power Adapter | Near Invisible Force Field | Case Transporter | Printed User Manual

Available Accessories: 7 Lines 1/8 to 1/4 output cable snake | Triple 100-240v Universal Power Adapter

Notes: Second-generation version of Korg's superb ModWave synth, building on the legacy of the iconic Wavestation with 60-voice polyphony, Kaoss Physics and Motion Sequencing 2.0.

Supplier's Notes:
Modwave is a synthesis powerhouse with distinctive wavetable timbres, Kaoss Physics, and Motion Sequencing 2.0. The new Modwave mkII provides an astonishing 60 voices of polyphony almost double that of the original Modwave. All LFOs have been updated with options for free running, delayed start, and retriggering, and a pre/post switch for reverb sends has been added, alongside new modulation sources, and more.

Modern monster synth

In 1985, Korg introduced the DW-8000 - a synth which combined digital wavetables with rich analogue filters to give users sounds which were impossible to create with analogue oscillators.

Modwave builds on the DW legacy, transforming it into a modern monster synth, featuring incredibly deep wavetable oscillators, gorgeous filters, wildly flexible modulation, unmatched polyphony, comprehensive pattern sequencing, and immediately satisfying hands-on control to deliver unique, powerful, and easily customizable sounds and phrases.

Over 200 factory wavetables each contain up to 64 waveforms. 30+ Modifiers can be used to change their basic character, and 13 Morph Types to process them in real-time. Using the unique, realtime A/B Blend, it's possible to create new hybrids from any two wavetables.

Expanded possibilities

Modwave can be expanded by importing new wavetables using the free Editor/Librarian software. There are many free and commercial wavetable libraries in the standard Serum format, or you can create your own using the free, cross-platform WaveEdit software (available in a custom version for the Modwave). Wavetables can be layered with samples from the built-in, multi-gigabyte PCM library, or import your own 4 GB of samples using the Sample Builder software.

Each Program has two full-featured wavetable oscillators, plus a sub oscillator/noise generator and any of a dozen stereo filter types, including the aggressive MS-20, sweet Polysix, and the newly enhanced Multi Filter. Animate almost any parameter using the massively flexible modulation system, with four triggerable envelopes, five LFOs, dual mod processors and two key-track generators-plus multi-lane Motion Sequencing and Kaoss Physics.

Even with all that synthesis power, playing up to four simultaneous wavetables per voice in a single Program, the Modwave mkII achieves 60-voice polyphony, incredible for a wavetable synth. Layer two Programs together for double the possibilities.

KAOSS in motion

Modwave introduced two unique new tools for creating dynamic motion: Kaoss Physics and Motion Sequencing 2.0. KaossPhysics combines an x/y Kaoss pad with modulatable game physics to create a responsive, interactive controller that is extraordinarily powerful.

Motion Sequencing 2.0 brings the organic, continuously evolving patterns of the Wavestate Wave Sequencing 2.0 into the world of motion sequencing, including multiple lanes and real-time recording to help you create complex and evolving phrases that other step sequencers cannot.

Modwave's evolved wavetable synthesis delivers its own brand of completely unique sounds and a knob-per-function layout that makes customizing those sounds fast and easy. There are hundreds of preset sounds empowered by this new architecture, organised by front-panel category buttons, and all instantly customizable via the four Mod Knobs. Modwave'sdistinctive wavetable timbres start with aggressive basses & leads, and lush ambient pads which will add a new dimension to your tracks. But that is just the beginning.

Those who want to dig deeper will find an endless source of discovery; with the Modwave's unique synth architecture, you'll be finding new things for a long, long time. Save as many of your sounds as you like; there's room for thousands more. You can also load your own samples, import wavetables in standard formats, and create your own wavetables using the free WaveEditsoftware.

KAOSS Physics

Kaoss Physics models a ball rolling on a surface and bouncing off walls. The surface can tilt in any direction, and a bump with variable height/depth and location attracts or repels the ball. Adjustable friction slows the ball's travel, and adjustable time controls the speed of the entire model. All of these characteristics are modulatable, so you can change them in real-time!

Start the ball by flicking a finger on the x/y pad, or launch the ball automatically using another modulation source. You can even directly control the ball by holding your finger on the pad. The position of the ball produces eight modulation signals, which can be used to control any modulation destination: the X and Y locations, the distance from the centre, the angle relative to the X axis, and separate signals for +/- X and +/- Y.

Walls can slow down the ball, as if they were padded, or accelerate the ball, like bumpers in a pinball machine. The walls can also be removed entirely, so that the surface wraps around to the opposite edges like a vintage arcade game.
The modelled environment can create specific modulation effects. For instance, use a centered bump with negative height so that the modulation values always eventually return to 0. Or, position a bump with positive height on a side or a corner, to push modulation values away from that zone.

The result is an interactive controller that amplifies your physical gestures, transforming them into complex musical results.

Motion Sequencing 2.0

Motion Sequencing 2.0 is evolved from the Wavestate's Wave Sequencing 2.0. Timing, Pitch, Shape, and four sets of Step Sequence values are separated into "Lanes," each with their own loop start and loop end, adding a deeper, more customizable level of phrase and modulation recording.

Every time the sequence moves forward, the individual Lanes are combined to create the output. For instance, a step sequence value may be matched with a different duration, pitch, and shape every time that it plays. You can modulate each Lane's loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different!

Lanes can also randomize the step order every time they play. Finally, individual steps can be randomly skipped, with a modulatable probability from 0 to 100%. The result is organic, ever-changing sounds that respond to your control. The dual onboard arpeggiators can interact with Motion Sequences for even more possibilities.

Wavetables

Wavetables are sets of single-cycle digital waveforms, arranged in a specific order. The wavetable's "position" determines which waveform is played. Moving the position with an envelope, LFO, or other modulation source creates subtle or dramatic changes in timbre. Some wavetable systems switch abruptly from one waveform to another; others crossfade smoothly between them. Modwave can do either one.

Modifers

Use over 30 Modifiers to alter the character of any wavetable at load time. For instance, isolate the odd or even harmonics, add weight through anti-aliased quantization or saturation, or revisit the gritty character of old-school wavetable synths with the Vintage 8 & 12 options.

Morph

The 13 Morph Types let you stretch, squeeze, reflect, and otherwise alter the wavetables in real-time, changing their timbre andiwhen modulatedicreating additional motion in the sound. Sync creates classic swept-sync timbres, using only a single oscillator. Three special Morph TypesiFM, AM, and Ring Modimodulate Osc 2 with Osc 1, and the last two even apply to samples.

A/B Blend

Using the unique A/B mode, oscillators can blend any two wavetables with phase-synchronous precisionidifferent from simply layering voicesiopening up a dimension of intermediate waveforms. Add body to otherwise "thin" waveforms, for instance, or a touch of sizzle to a mellow timbre. Even fade between two different "modifier" versions of the same wavetable. A/B Blend can be modulated in real-time, of course.

Or, step outside the box with Korg's unique Multi Filter, which creates modulatable blends of multiple modes simultaneously - now with presets on a front panel knob, for easier exploration of its many possibilities.

An arsenal of effects

Modwave's superb effects deliver production-ready sounds. Each Layer has three dedicated effects, plus a send to the Performance's master reverb, followed by a master parametric EQ. Along with standards such as compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb (from the OASYS and Kronos), plus modeled effects including VOX guitar amps, VOX wah, multi-head tape echo, and a collection of classic guitar pedals.

Notes: Serious synth options here, with a 24-voice polyphonic, four-part multi-timbral design based on the iconic PPG wavetable approach, updated and blended with analogue filters. An absolute powerhouse of an instrument.

Supplier's Notes:
The 3rd Wave desktop module a powerhouse wavetable synth with 24-voice polyphony and 4-part multi-timbral capability that's like having four independent synthesizers at your fingerprints.

It has all of the power, all of the polyphony, all of the multipart capability, all of the I/O, and all of the awesome sound quality of the full keyboard version.

Each of its 3 oscillators per voice can be any of these 3 choices:
A classic PPG 8-bit wavetable with all the original processing
A high-resolution anti-aliased 96KHz wavetable
Analogue modelled waveforms with spline interpolation

Create up to 64 custom wavetables of your own using the built-in Wavemaker. With the sample-to-wavetable capability, you can connect an audio source to the audio input and generate a wavetable at the touch of a button.

Classic legacy, modern sound

While the 3rd Wave has roots in the classic digital wavetable synths of the past, it takes that concept into the 21st century with a lush, expansive sound that's a product of its expanded wavetables and warm, organic-sounding analogue filters, 4 independent parts, and 24 voices.

It boasts not only a punchy, Dave Rossum-designed 2140 analogue low-pass filter with variable saturation, but a second, SEM-style state-variable filter (low-pass, high-pass, notch, and band-pass) for additional tone-sculpting. Run both filters in series for harmonically complex textures.

4-part multi-timbral

With 24-voices, the 3rd Wave has enough power for the most note-intensive performances.

And that polyphony really comes into play with its ability to layer up to 4 independent parts or split zones -- each with a completely different sound, sequence, and dual effects.

Each part has independent panning, volume, and a dedicated stereo physical output. Use the multiple outputs and part placement to create spatial audio mixes.

Modulation matrix

The secret weapon of any synth is its mod matrix, and the 3rd Wave doesn't disappoint.

With 16 assignable slots, 12 additional fixed-source slots, 27 sources, and 114 destinations, it has the flexibility of a modular.

And all of this power is per multipart. That means up to 4 independent layers of sound, each with its own mod matrix.

Sequence notes, songs and parameters

The 3rd Wave's sequencer is an inspiring tool for both composers and sound designers because it is pattern-based and can sequence notes, songs, and parameter changes.

For composing and performing, enter notes and chords in real time with or without quantization for maximum groove and arrange up to 24 patterns of up to 32 measures in length into songs just as easily.

Sound engine

3 High-resolution Digital Oscillators Per Voice

64 total user wavetable positions with 48 wavetables that contain 64 waveforms per table (32 legacy PPG waves with room for another 16 of this type)
32 original 8-bit wavetables from the PPG 2 series instruments with room for 16 more user created 8 bit wavetables
7 high-resolution modelled analogue waveforms (sine, saw, triangle, supersaw, pulse, white noise, pink noise)
VCO sync
Free-running oscillators
Linear FM
6-stage wave envelope per oscillator with variable time and position that can be looped
Optional wave flow section that allows for no wavetable as well as no waveform interpolation
Upper wavetable mode as with the original PPG 2 series
Unison, poly unison, and chord unison mode with variable voice count

Analog Low-pass Filter (per voice)

Dave Rossum designed, classic, 2140 low-pass resonant filter
24 dB per octave slope
variable saturation amount
optional resonance compensation

State-Variable Filter (per voice)
12 dB per octave slope
Continuously variable between low-pass, notch, and high-pass, operation with optional band-pass mode

4 ADSR+ Delay Envelopes
Filter, Amplifier, plus 2 additional envelopes switchable between exponential and vintage PPG-style response
Freely assignable to multiple modulation destinations

4 Low-Frequency Oscillators
Triangle, sawtooth, reverse sawtooth, square, pulse 1, pulse 2, pulse 3, and random (S&H)
Variable delay
Note reset
Syncable to master clock BPM

2 Digital Effects
BBD, stereo delay, tape delay, chorus, phaser, flanger, distortion pedal, rotating speaker, ring mod, room reverb, hall reverb, super plate reverb - most modelled on famous hardware devices
Syncable to master clock BPM
Parameters modulatable via mod matrix

Wave maker tool

Built-In Custom Wavetable Maker

"Sample-to-wave" functionality. Connect an audio source to the 3rd Wave's Audio In port, press "Make Waves" and the synth samples the audio to create a custom wavetable
Samples to convert can also be brought in as a 96 kHz wav file through USB
Store up to 32 custom wavetables
64 waveforms per wavetable
Accepts pitched or un-pitched material as input
96 kHz sampling rate
16-bit resolution
1024 cycles per waveform, converted automatically to cover entire keyboard range
Flexible wave-sampling length

Sequencer

Performs both Note and Parameter Sequencing
1 song per multi-part
24 sequences per song
32 measures per sequence
Variable quantization resolution per sequence (32nd, 16th, 8th, quarter, half, whole note, or quantization off)
Swing

Arepggiator

1 Arp per Multi-part
Up, down, up/down, and assign modes
Variable range (1, 2, or 3 octaves)

Mod matrix

16-slot Modulation Matrix Per Multi-Part

16 slot modulation matrix with 27 mod sources and 114 mod destinations
12 additional fixed-source mod paths
Modulation assignment buttons enable quick and easy modulation routing
Mod Matrix runs at audio rates
Sequencer can record and play mod parameter changes in real time

Controls

77 knobs and 39 buttons enable deep, comprehensive editing with minimal menu diving
Pitch and Mod Wheels
Full-sized, five-octave, semi-weighted, premium Fatar keyboard with velocity and aftertouch

Programs

500 factory programs. User rewritable

In/out

4 Stereo outputs (2x 1/4" phone jack per part)
Headphone out (stereo 1/4" phone jack)
MIDI In, MIDI Out, and MIDI Thru
USB port for bidirectional MIDI communication
Audio Input for creating user wavetables from external audio source (1/4" phone jack)
Sustain/footswitch input
Volume pedal input
Expression pedal input

Power

1 universal IEC AC power inlet for internal power supply

Notes: A collaborative effort between the techno icon and one of the best synth brands around, the Bullfrog is designed to encourage newcomers to analogue synths while secretly packing killer sound and some innovative features.

Supplier's Notes:
Introducing Erica Synths X Richie Hawtin Bullfrog

Learn. Produce. Perform

Created by Erica Synths & Richie Hawtin, Bullfrog is an educational electronic music instrument designed to captivate and inspire both youth and professionals alike. Bullfrog invites you to unlock musicality while combining the thrill of electronic music production with a comprehensive learning experience.
Bullfrog is a classical subtractive synthesiser - it consists of several "modules" for sound generation - VCO, NOISE GENERATOR - and treatment - VCF, VCA/DELAY, as well as "modules" that generate control and modulation signals to control them - ENVELOPE GENERATORS and SAMPLE & HOLD. The Bullfrog will not make the sound on its own unless it is patched - using eurorack patch cables to interconnect the "modules" or by inserting voice cards that create internal connections between the "modules" in a specific way and add extra functionality, like sampler/looper, sequencer, groovebox, etc. This approach better helps to understand functionality of a subtractive synthesizer and the principles of sound design with instruments like these.

In order to provide a well rounded understanding of the functionality of this synthesizer and sound synthesis in general, a comprehensive user manual is created to accompany the learning process.

Electronic music with its rich traditions and innate sense of exploration at core is ever popular, with artists and fans stretching around the globe. For me, one of the most exciting parts of creating electronic music is the playful exploration that leads one deep into their own imagination. Whether the intention to create completely imagined or real-life inspired sounds, the route one takes to create is always personal and often surprising. It is within these experiments where the beauty of synthesis really comes alive and which often unlocks a new sense of creativity and purpose.

Whether someone's experience with Bullfrog points them down a career in electronic music or not, the goal is to both nurture the love for electronically produced sounds and promote the accessibility of learning and understanding the basics of sound synthesis.

Erica Synths believe that the hands-on approach and problem solving that is innate to synthesis on a semi-modular synth like the Bullfrog, contains life lessons that go beyond what we can hear.

Bullfrog encapsulates the foundations of synthesis and is built with an immediate, intuitive design and a unique expandable architecture that grows and expands together with the user's imagination. This instrument feels at home anywhere - as an educational tool in music and physics classes, as an addition to your basement studio or even as a tool for performance on a stage.

What's included:

BULLFROG synthesizer
Universal 12VDC wall wart adapter
User manual
10 patch notes stencils
10 patch cables
3 pre-patched voice cards
3 DIY voice cards with adjustable offset
Delay effect with adjustable delay time and feedback amount
Two looping attack-sustain-release envelope generators (EG)
Sample & Hold circuit with an individual clock
Manual gate button
Voicecard slot
Built in speaker
DIN5 MIDI input
USB connector

What's included

BULLFROG synthesizer
Universal 12VDC wall wart adapter
User manual
10 patch notes stencils
10 patch cables
3 pre-patched voice cards
3 DIY voice cards

Notes: Updated version of Korg's excellent Wavestate, drawing on the iconic Wavestation synth to create a modern take on wavetable synthesis, now with added polyphony.

Supplier's Notes:
Wavestate mkII

Extended polyphony. Extended possibilities.

Korg's legendary Wavestation introduced the world to wave sequencing, and the 37-key Wavestate mkII builds on that legacy with a reimagined, compact synth designed to satisfy today's demanding musicians and producers. MkII expands polyphony to 96 stereo voices and adds a fresh look. It's completely compatible with sounds and samples for the original Wavestate.

Overview

Korg's legendary Wavestation introduced the world to Wave Sequencing, transforming raw samples into sounds that no-one had ever heard before. The flagship OASYS, Kronos and Nautilus keyboards developed Wave Sequencing even further, expanding on its unique palette of lush, evolving pads and driving rhythms.

Now, Korg is proud to present the new Wavestate mkII, with improved polyphony (96 stereo voices) and a fresh look. It's completely compatible with sounds and samples for both the original Wavestate, Wavestate SE and Wavestate Native software, including many excellent third-party libraries. Updated sounds and software keep it fresh and the compact form-factor, with 37 full-size keys, still transports easily and fits neatly into any stage, studio, or desktop setup.

Keyboard: 37-keys, velocity sensative
Sound generation: Wave Sequencing 2.0
Polyphony: 96 stereo voices
Configuration: Performance: 4 layers, reverb, EQ
Layers: Program, Arpeggiator, Key, and Velocity Zones
Programs: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Presets: 261 Performances,799 Programs, and 1042 Wave Sequences
Controllers: MOD wheel, PITCH wheel, Vector Joystick, 8 x program/Performance Mod knobs.
Effects: Pre FX x4, Mod FX x4, Delay x4, Reverb, Performance EQ

Inputs/outputs:

Audio Outputs L/MONO, R (6.3mm TRS phone jack, impedance balanced)
Headphones (6.3mm stereo phone jack)
Damper (6.3mm phone jack)
MIDI in,out
USB Type B

Power: AC adapter (DC12V, 2500mA)
Power consumption 5w
Dimensions: 565 W x 338 (D x 92 (H mm
Weight: 2.9kg

Notes: 12-voice version of Waldorf's Iridium Core, a compact synth from the same range as the Quantum. Running on the Waldorf OS, the Iridium features a versatile selection of Wavetable, Multi- & Granular-Sampling, Waveform, Kernel FM and Resonator synth engines.

Supplier's Notes:
The Core

Iridium Core provides the core synthesis engine of the Quantum / Iridium platform. It is the heart of Waldorf's most advanced hardware-based synthesis. The essence of forward-looking sound. The Core.

Sonic Explorer

Iridium Core contains 5 synthesis engines: Wavetable, Multi- & Granular-Sampling, Waveform, Kernel FM and Resonator. Combined with a broad selection of digital filter and processing options Iridium Core lets you explore a huge sonic universe of electronic sound. Iridium Core's intuitive and easy graphical interface helps you to keep your flow of creativity.

Wave Traveller

The compact form factor makes Iridium Core an ideal companion to travel with you to all your sonic explorations and performances. It fits well into laptop size bags and in carry on-baggage it leaves enough space to all your other devices you need for your performances.

Driven by Inspiration

Iridium Core comes with a huge collection of more than 1700 factory presets and samples to drive your sonic Wanderlust. Get inspired what the broad and diverse array of sound designers have created to fuel your musical endeavours.

Team Player

Iridium Core integrates into various live performance and studio setups. Its connects with your modular synths, drum machines, sequencers and computers. The compact form factor fits well into your tabletop or space limited setups.

Family Member

Iridium Core shares the same software platform like Quantum, Iridium Desktop & Iridium Keyboard. All instruments are powered by the Waldorf synthesiser OS and will receive joint updates. Thus, the whole family participates from future enhancements and developments.

Specifications

Compatible with the Waldorf Quantum synth engine
Software: Waldorf Synthesis Platform OS

Oscillators
3 Oscillators each capable of 5 synthesis modes:
Wavetable
Waveform (VA)
Particle (Sampling and Granular Sampling)
Resonator
Kernels (up to 6 sub-oscillators which can be interlinked through FM, AM or Wavetable-position at audio rate)

Dual Stereo Filters per voice
True stereo path Dual Digital Filter with independent modes:
12/24dB LP/HP/BP in all combinations
Nave, Largo, PPG, Quantum and StateVariable models
Analyzer displayed in Filter view
Filter curve animation when modulated (optional)
Sophisticated filter routing options with modulatable panning and levels

Digital Former
Filter models like State Variable, Waldorf Nave, Largo and PPG in HP/LP/BP/Notch
Comb filters, Bit-Crusher, various Drives, Ring-Modulation

Modulators
6 Envelopes
6 LFO
Komplex Modulator (LFO/Envelope combination with user-definable shape and morphing)

Mod Matrix
40 slots
Fast assign mode
One additional control amount per slot
Identical Sources and Destinations can be used multiple times until the matrix is full

Effects
5 slots per layer
Various parallel and sequential routing options
Reverb, Delay, Chorus, Phaser, Flanger, Drive, EQ, Compressor, Tremolo

Performance features
Advanced Arpeggiator
Step-sequencer with up to 64 steps for notes and parameters
2x4 button pads assignable to notes or chords
4 user-assignable potentiometers
6 user-configurable macro buttons
Favourites screen for quick patch recall
XY control on touchscreen
Wheels touchscreen for MIDI controls like mod wheel, pitch bend, aftertouch and velocity
MPE capable

Screen
Industrial-grade highly responsive touch screen with Brightness control
1024x600 pixels

Voices
12 voice polyphony
Duo-timbral
Mono, Legato and Unisono modes

Patches
Over 1700 factory patches
Capacity of 7000 patch memory slots (numbers 0000-9999 can be used)
Patches from Quantum and other Iridium variants can be loaded and vice-versa
Category filter for patch list
2.6 GB sample flash memory preloaded with 2 GB factory samples

Connections
Stereo Audio Out: 2x TS jacks
Stereo Audio In: 2x TS jacks
Headphones TRS output with level control
DIN MIDI IN & Out, mini-TRS Type A (two adapters to DIN MIDI sockets included)
USB Type B (device) for MIDI connection to computer
USB Type A (host) for storage media and MIDI devices
MicroSD slot
2 high-resolution CV Inputs which can be used as modulation sources in the Mod-Matrix
Analogue clock In & Out with clock divider settings

Overall
Sturdy metal case
Dimensions: 346 mm wide by 200 mm depth by 64 mm height (including controls)
Weight: 2.2 kg
External Power Supply: Input 100-240 V / AC 50-60 Hz, Output 12 V DC / 3 A

What's In the Box?
Iridium Core Synthesizer
Two MIDI adapters: mini TRS to DIN sockets
Power Supply
Printed Quick Start Guide

Notes: Like a greatest hits of recent Analogue Solutions synths, the Ample combines sound elements from the Fusebox with jack patch points, a patch pin matrix, plus sequencer and CV touch pads from the Generator, creating something new and unique.

Supplier's Notes:
Ample combines the best elements of several of Analogue Solutions' recent products.

The sound elements of Fusebox
Jack patch points of Concussor Eurorack
Patch pin matrix of Vostok
Echo from Dr Strangelove
Sequencer and CV touch pads of Generator

It shares all this yet still has its own sound!

Ample can be as complex or as simple as you want it to be

This synth has been given a large and diverse number of controls, that along side the patch sockets, will give even the best and experienced synthesist endless possibilities.

This synth presents the controls in a user friendly and familiar synth layout that, together with this manual and other resources, enable even the new guy to get great sounds.

Synth - Percussion - Audio Processor

Ample is a compact analogue synthesizer. Analogue - as in really analogue. Aside from the MIDI chip (which has to be digital), everything else is totally analogue using real transistors and op-amps. There are no CPU stabilised and quantised circuits, no DCOs, no digital LFOs and no digital EGs, as found on other so called analogue synths. The circuitry is based on designs dating back to the mid-1970s. So Ample has a genuine old sound.

Circuits included

3x Analogue Oscillators

There are three analogue VCOs - each providing a wealth of features and modulation choices. VCO3 can easily be utilised as a LFO.

2x Analogue Low Frequency Oscillator

LFO2(/Sync) has a triangle wave output. VCO3 can be used as an LFO and has Saw, Triangle and Square wave modulation signals.

Analogue Filter

Ample uses a four pole 24bB per octave low pass filter.

Analogue Amplifier

The VCA can be set to THRU so it is always 'open'. This allows Ample to be used as an effects processor.

2x Analogue Envelopes

There are two EGs - each having full control over ATTACK, DECAY, SUSTAIN, and RELEASE.

Modulation

Great thought has been placed into modulation route choices, allowing a wide range of sounds to be produced, including percussion and 'modular' sounds further extended by patching with the jack sockets and pin matrix.

MIDI

MIDI is intentionally kept simple - so you can concentrate on making new sounds and making music - not getting tied up with SYSEX programming.

You get the all important control over filter cut-off using MIDI Velocity.

Patchable External CV Control Sockets

Ample has many input and output audio and CV sockets - to allow the synth to be effectively re-wired to make new sounds.

The sockets also enable it to be easily used with Eurorack and other modular systems. They can be patched together.

Sequencer

Ample has a vintage style 16 step sequencer.

Touch Keys

There are 6 touch keys that each output a set voltage. Use this to play the pitch or as modulation signals. A great tool for inspiration!

Pin Matrix

A neat way to patch the synth.

Echo

Nice lo-fi echo / delay.

Notes: Premium version of the excellent Opsix, Korg's contemporary take on FM synthesis. Full 61-note natural-touch keybed with aftertouch, 80-voice stereo polyphony and full metal construction.

Supplier's Notes:
The Ultimate Union of Power and Performance

opsix SE is a digital synth like no other. With a premium all-metal design, 61-keys, and aftertouch, it unlocks a new world of sonic capabilities. Building on the expansive sound engine in the original opsix, opsix SE enhances it with increased polyphony and voicing, resulting in a synthesizer created for superior performance and precise control.

The opsix Operator Mixer simplified FM synthesis for the first time, making it not just comprehensible but also controllable. With the addition of extra synthesis capabilities and programming, it offered a more efficient workflow and an even richer sound.

The opsix SE takes this even further. It is equipped with Korg's premium 61-key natural-touch keyboard, complete with aftertouch, delivering the exceptional tactile experience expected from Korg's flagship workstations. With a sleek, robust metal body, it's built for both the intensity of live gigs and the precision of studio sessions. The metallic knobs are optimally weighted for effortless adjustments. Underneath its exterior, the opsix SE boasts an incredible capacity of 80 stereo voices of polyphony.

The opsix SE arrives preloaded with hundreds of sounds enhanced for aftertouch control. Moreover, it is fully compatible with the sounds and samples from both the original opsix and the opsix Native software, including numerous high-quality libraries.

Build to play

opsix SE was born out of the desire to play this incredible synth with both hands. Equipped with KORG's premium 61-note natural-touch keyboard, the opsix SE offers the same outstanding tactile response as KORG's top-tier workstations. Aftertouch puts unparalleled control of all the exceptional opsix sounds at your fingertips. Of course, we've modernized the factory Performances for aftertouch and introduced some fresh ones to the mix as well. In fact, most of the opsix SE programs have been revised to make full use of aftertouch, extended keyboard, and polyphony.

Premium metal design

The opsix SE showcases a notable upgrade in aesthetics. A slim body, specifically designed for this instrument, features a striking brown painted aluminium control panel, paying homage to vintage machines. Together with the vivid, illuminating LEDs, it brings a vibrant energy to any stage performance. The side panels, painted in a sleek black metal, amplify the overall aesthetics for a luxurious finish.

Exclusive hard case included

The opsix SE ships in a dedicated hard case, including space for cables and a sustain pedal. Your instrument can travel protected, whether you're carrying it to a rehearsal downtown or packing it up for a tour.

Get Illuminated with the Operator Mixer

At the heart of every sound is opsix SE's Operator Mixer - a simple set of six faders and knobs that invite exploration. Each part lights up red to indicate carriers or blue for modulators. Manipulating them opens up new sound-shaping possibilities to breathe fresh life into your musical ideas. This straightforward, hands-on workflow is part of what makes opsix SE so unique, just like the sounds it offers.

Direct Hands-On Control

Whether you're tweaking a preset or building a patch from the ground up, the six data entry knobs on the right give you quick access to the parameters you need and seamlessly sync with the large OLED display, giving you a clear, focused direction to your workflow. Coupled with the mixer, it makes creating fresh sounds super easy and, most importantly, fun!

Select from a full range of analogue-style filters, from the radical Korg MS-20 low-pass/high-pass filter to the powerful yet smooth KORG Polysix low-pass filter that gives your sound a vintage feel. There are also two or four-pole low-pass, high-pass, band-pass, and band-reject filters with resonance.

There's even a built-in spectrum analyser and oscilloscope that gives you visual feedback via the screen on the music you're making.

Six in One Synthesis

The core of opsix is nothing short of exponential. Since waveforms can be arranged and modulated in nearly infinite ways, opsix can easily do the sonic work that is similar to numerous types of synthesis:

Subtractive

Removing parts of the sound to get the sound you want; the most widely-used synthesis. opsix uses up to six envelopes and multi-modeled filters to achieve many cutting-edge and classical analog synthesis tones.


Semi-Modular
Rerouting signal paths to change the sound. A spin through the Alogorithm section will dramatically reshape the sound by changing how the signal routing between the operators work together, and no patch cables are needed.


Analog (Modelling)
Analog-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.


Waveshaping

Adding intentional distortion to the waveforms to achieve aggressive overtones that are either harmonic or inharmonic. This will help you achieve gritty, bitey tones dripping with character.


Additive

Stacking waveforms and blending their harmonics is key to an expansive range of harmonious, dissonant, and tension-driven sounds. With six operators available, the complete FM experience is possible, including the ability to go back in time for classic sounds you have heard throughout recording history.


Classic FM

Last but certainly not least, opsix's highly flexible and powerful architecture starts with true six-Operator FM. As a result, it easily delivers signature sounds you have surely heard on thousands of hits from the '80s on through today, and with far more polyphony than other standalone FM synths available today.

With all of these ways to realize and explore sounds, opsix SE is uniquely suited as a "future-modern-classic" synth!

Altered Reality

opsix SE is FM-based, but the similarities to the classic synthesis end there. The Altered FM architecture delivers sounds across a vast spectrum, far wider than any single synthesis has been able to cover before, thanks to new sound components; new waveforms, filters, shaping, effects, LFOs, envelopes, modulations, and more, all translating to its broad assortment of sounds.

Powerful Effects Processing

opsix SE provides three blocks of 30 types of high-definition effects that you can use together to enhance your sounds even further. There's everything from a great mix of usable standard effects like chorus, phaser, delay, and compressor to some world-class shimmering reverbs that will elevate your sound to the next level.

Automatable 16-step sequencer

opsix SE features an incredible step sequencer that rivals groove boxes for flexibility and power. Press the PLAY button on any sound and experience the complexity of the sequences! Every Program has its unique sequence stored with it, or create your very own.

You can record up to six notes per step and edit each note's velocity, gate time, and playback timing. Create long phrases or make subtle shifts in timing to emulate strums or drum rolls, something that's not possible on a typical 16-step sequencer. The motion sequencer of the opsix SE also lets you record changes of up to six parameters, creating smooth motion changes in sound within a phrase or building rhythms that change dramatically with each step.

Notes: The premium version of Korg's excellent Wavestate gets the Platinum look in this limited-edition model. 61-note keyboard, metal chassis and limited-edition Platinum finish.

Supplier's Notes:
Wavestate SE Platinum

The ultimate Wavestate, the limited edition Wavestate SE Platinum features a stunning premium silver aluminium panel and stainless steel side panels.

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis.

Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes of stereo polyphony to inspire new levels of creativity.

A sonic evolution

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis. Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes (stereo) of polyphony to inspire new levels of creativity.

Premium, expressive touch

Featuring a 61-key natural-touch keyboard, Wavestate SE feels incredible to play. The inclusion of aftertouch gives fingertip control of the unique constantly changing sound. All factory presets have been meticulously programmed to take full advantage of this expressive control.

Beauty meets brawn

Wavestate SE's all-metal design is as hard-wearing as it is beautiful - with a matte-black aluminium panel complimented perfectly by glossblack stainless-steel sides. The premium finish continues to the controls themselves, where metal-plated knobs are perfectly weighted and add a luxurious touch.

Easily expressive. Exceptionally deep.

The Wavestate SE puts filters, envelopes, LFOs, effects and more at your fingertips with dedicated front-panel controls. Eight programmable Mod knobs are customised to bring out the most in every sound, for real-time performance and also when saving results as new patches. Pitch bend and modulation wheels, and the unique Vector Joystick, give you instant access to multiple dimensions of real-time expression. Digging deeper, almost all front-panel knobs, and most on-screen parameters, can be modulated. You can even modulate settings for individual Wave Sequence steps! Mod Processors let you transform modulation signals using quantization, smoothing, curvature, and more.

Gigabytes of samples

Totalling in the gigabytes, Wavestate SE's sample library is vast. At a thousand times larger than that of the original Wavestation, the amount of great-sounding raw material for Wave Sequences is astounding.

Three of the key sound designers from the original Wavestation, John Bowen, John "Skippy" Lehmkuhl (Plugin Guru), and Peter "Ski" Schwartz, joined Belgian artist Airwave and the renowned Korg voicing team to create the incredible Wavestate SE sound library.

Powerful effects

An arsenal of superb effects ensures Wavestate SE delivers production-ready sounds. Each performance has a master reverb and parametric EQ while each layer has three dedicated effects. Alongside compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb, plus modelled effects including Vox guitar amps and wah pedal, multi-head tape echo, and a collection of other classic guitar pedals.

Multiply by four

Take all that power, and quadruple it! You can layer up to four Programs together in a Performance-each with their own effects and arpeggiator. The Vector Envelope and Joystick mix the individual voices of the four layers, and can also modulate any other parameters. This sheer sonic power is further enhanced with 120 notes (stereo) of polyphony. Set Lists offer effortless organisation of your Performances, and deliver instant access at the gig or in rehearsal. And thanks to Smooth Sound Transitions, previously-played voices and effects continue to ring out naturally, even when a new sound has been selected.

Deep connectivity

Connect to recording or monitoring systems with balanced stereo outputs, and a stereo headphone output is provided for private playing or onstage cueing. Din-style MIDI jacks ensure connection to other MIDI-equipped instruments and audio gear. The Wavestate SE supports class-compliant USB MIDI connections to Windows and Mac computers, and the Wavestate SE Editor/Librarian and Sample Builder programs are available as free downloads from Korg.

Wave Sequencing 2.0

The original Wavestation gave each step of a wave sequence a duration, a sample and a pitch. This created ear-catching repetitive patterns, giving rise to entirely new approaches to sound design. But what if the sounds could evolve in organic and unexpected ways, instead of just repeating? Wave Sequencing 2.0 separates the timing, the sequence of samples, and the melody, so that each can be manipulated independently. It also adds new characteristics, including shapes, gate times, and step sequencer values. Each of these is a "Lane", and each Lane can have a different number of steps, start, end and loop points. Every time the sequence moves forward, the individual Lanes combine to create the output. For instance, a sample may be matched with a different duration, pitch, shape, gate length, and step sequence value every time that it plays. You can modulate each Lane's start, end, and loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different! Lanes can also randomise the step order every time they play, with real-time control over the range of included steps, and individual steps can be randomly skipped (with a modulatable probability from 0 to 100%). The result is organic, ever-changing sounds that respond to your control. The four onboard arpeggiators can interact with Wave Sequences for even more possibilities.

Specifications

Keyboard: 61 keys (Natural touch keyboard with velocity and release-velocity
sensitive, aftertouch)
Sound generation: Wave Sequencing 2.0
Polyphony: 120 stereo voices
Sounds: 261 Performances, 799 Programs, and 1,042 Wave Sequences. Storage for tens of thousands of user Performances
Performance: 4 Layers, Reverb, EQ; all edits are stored in the Performance, DAW-style (saving as separate Programs, Wave Sequences etc. is supported but not required)
Layer: Program, Arpeggiator, Key and Velocity Zones
Program: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Filters: 2-pole LPF, 2-pole HPF, 2-pole BPF, 2-pole Band Reject, 4-pole LPF, 4-pole HPF, 4-pole BPF, 4-pole Band Reject, Multi Filter, MS-20 LPF, MS-20 HPF, Polysix
Controllers: Mod Wheel, Pitch Wheel, Vector Joystick X/Y, 8x
Program/Performance Mod Knobs

Inputs/outputs: Headphone (6.3 mm stereo phone jack) OUTPUT L/MONO and R (impedance balanced 6.3 mm TRS phone jacks)
DAMPER (6.3 mm phone jack)
MIDI IN and OUT connectors
USB B port

Power supply: AC adapter (DC12V, 2500mA)
Consumption: 5W
Dimensions: 1,014 x 344 x 108 mm
Weight: 8.6 kg

Included items

AC adapter, hard case, t-shirt, stickers

Notes: Top-of-the-range take on the powerful Wavestate synth concept, based on wave sequencing with 120-note stereo polyphony, natural-touch 61-note keybed and aftertouch.

Supplier's Notes:
Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis.

Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes of stereo polyphony to inspire new levels of creativity.

A sonic evolution

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis. Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes (stereo) of polyphony to inspire new levels of creativity.

Premium, expressive touch

Featuring a 61-key natural-touch keyboard, Wavestate SE feels incredible to play. The inclusion of aftertouch gives fingertip control of the unique constantly changing sound. All factory presets have been meticulously programmed to take full advantage of this expressive control.

Beauty meets brawn

Wavestate SE's all-metal design is as hard-wearing as it is beautiful - with a matte-black aluminium panel complimented perfectly by glossblack stainless-steel sides. The premium finish continues to the controls themselves, where metal-plated knobs are perfectly weighted and add a luxurious touch.

Easily expressive. Exceptionally deep.

The Wavestate SE puts filters, envelopes, LFOs, effects and more at your fingertips with dedicated front-panel controls. Eight programmable Mod knobs are customised to bring out the most in every sound, for real-time performance and also when saving results as new patches. Pitch bend and modulation wheels, and the unique Vector Joystick, give you instant access to multiple dimensions of real-time expression. Digging deeper, almost all front-panel knobs, and most on-screen parameters, can be modulated. You can even modulate settings for individual Wave Sequence steps! Mod Processors let you transform modulation signals using quantization, smoothing, curvature, and more.

Gigabytes of samples

Totalling in the gigabytes, Wavestate SE's sample library is vast. At a thousand times larger than that of the original Wavestation, the amount of great-sounding raw material for Wave Sequences is astounding.

Three of the key sound designers from the original Wavestation, John Bowen, John "Skippy" Lehmkuhl (Plugin Guru), and Peter "Ski" Schwartz, joined Belgian artist Airwave and the renowned Korg voicing team to create the incredible Wavestate SE sound library.

Powerful effects

An arsenal of superb effects ensures Wavestate SE delivers production-ready sounds. Each performance has a master reverb and parametric EQ while each layer has three dedicated effects. Alongside compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb, plus modelled effects including Vox guitar amps and wah pedal, multi-head tape echo, and a collection of other classic guitar pedals.

Multiply by four

Take all that power, and quadruple it! You can layer up to four Programs together in a Performance-each with their own effects and arpeggiator. The Vector Envelope and Joystick mix the individual voices of the four layers, and can also modulate any other parameters. This sheer sonic power is further enhanced with 120 notes (stereo) of polyphony. Set Lists offer effortless organisation of your Performances, and deliver instant access at the gig or in rehearsal. And thanks to Smooth Sound Transitions, previously-played voices and effects continue to ring out naturally, even when a new sound has been selected.

Deep connectivity

Connect to recording or monitoring systems with balanced stereo outputs, and a stereo headphone output is provided for private playing or onstage cueing. Din-style MIDI jacks ensure connection to other MIDI-equipped instruments and audio gear. The Wavestate SE supports class-compliant USB MIDI connections to Windows and Mac computers, and the Wavestate SE Editor/Librarian and Sample Builder programs are available as free downloads from Korg.

Wave Sequencing 2.0

The original Wavestation gave each step of a wave sequence a duration, a sample and a pitch. This created ear-catching repetitive patterns, giving rise to entirely new approaches to sound design. But what if the sounds could evolve in organic and unexpected ways, instead of just repeating? Wave Sequencing 2.0 separates the timing, the sequence of samples, and the melody, so that each can be manipulated independently. It also adds new characteristics, including shapes, gate times, and step sequencer values. Each of these is a "Lane", and each Lane can have a different number of steps, start, end and loop points. Every time the sequence moves forward, the individual Lanes combine to create the output. For instance, a sample may be matched with a different duration, pitch, shape, gate length, and step sequence value every time that it plays. You can modulate each Lane's start, end, and loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different! Lanes can also randomise the step order every time they play, with real-time control over the range of included steps, and individual steps can be randomly skipped (with a modulatable probability from 0 to 100%). The result is organic, ever-changing sounds that respond to your control. The four onboard arpeggiators can interact with Wave Sequences for even more possibilities.

Ultimate protection

Whether travelling to a studio or setting out on a world tour, ensure your Wavestate SE arrives safely with the included hard case. The custom design even provides space for cables and pedals.

Specifications

Keyboard: 61 keys (Natural touch keyboard with velocity and release-velocity
sensitive, aftertouch)
Sound generation: Wave Sequencing 2.0
Polyphony: 120 stereo voices
Sounds: 261 Performances, 799 Programs, and 1,042 Wave Sequences. Storage for tens of thousands of user Performances
Performance: 4 Layers, Reverb, EQ; all edits are stored in the Performance, DAW-style (saving as separate Programs, Wave Sequences etc. is supported but not required)
Layer: Program, Arpeggiator, Key and Velocity Zones
Program: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Filters: 2-pole LPF, 2-pole HPF, 2-pole BPF, 2-pole Band Reject, 4-pole LPF, 4-pole HPF, 4-pole BPF, 4-pole Band Reject, Multi Filter, MS-20 LPF, MS-20 HPF, Polysix
Controllers: Mod Wheel, Pitch Wheel, Vector Joystick X/Y, 8x
Program/Performance Mod Knobs

Inputs/outputs: Headphone (6.3 mm stereo phone jack) OUTPUT L/MONO and R (impedance balanced 6.3 mm TRS phone jacks)
DAMPER (6.3 mm phone jack)
MIDI IN and OUT connectors
USB B port

Power supply: AC adapter (DC12V, 2500mA)
Consumption: 5W
Dimensions: 1,014 x 344 x 108 mm
Weight: 8.6 kg

Included items

AC adapter, hard case

Notes: Special edition Platinum version of the excellent Opsix SE. Metallic finish, aluminium front panel, stainless steel sides and the same powerful FM synth engine as the standard Opsix SE.

Supplier's Notes:
Special limited edition of opsix SE.

Celebrating the release of the long awaited opsix SE, a stunning Platinum model (*) will be available in very limited quantities. While this model shares the same features as the standard model, it boasts a high-end metallic finish with an aluminum front panel and stainless steel side panels. This magnificent instrument is bound to command attention, whether on stage or in the studio.

(*) Differences are only cosmetic, specifications are exactly the same as the standard model. opsix SE Platinum also includes an exclusive set of stickers.

The Ultimate Union of Power and Performance

opsix SE is a digital synth like no other. With a premium all-metal design, 61-keys, and aftertouch, it unlocks a new world of sonic capabilities. Building on the expansive sound engine in the original opsix, opsix SE enhances it with increased polyphony and voicing, resulting in a synthesizer created for superior performance and precise control.

The opsix Operator Mixer simplified FM synthesis for the first time, making it not just comprehensible but also controllable. With the addition of extra synthesis capabilities and programming, it offered a more efficient workflow and an even richer sound.

The opsix SE takes this even further. It is equipped with Korg's premium 61-key natural-touch keyboard, complete with aftertouch, delivering the exceptional tactile experience expected from Korg's flagship workstations. With a sleek, robust metal body, it's built for both the intensity of live gigs and the precision of studio sessions. The metallic knobs are optimally weighted for effortless adjustments. Underneath its exterior, the opsix SE boasts an incredible capacity of 80 stereo voices of polyphony.

The opsix SE arrives preloaded with hundreds of sounds enhanced for aftertouch control. Moreover, it is fully compatible with the sounds and samples from both the original opsix and the opsix Native software, including numerous high-quality libraries.

Build to play

opsix SE was born out of the desire to play this incredible synth with both hands. Equipped with KORG's premium 61-note natural-touch keyboard, the opsix SE offers the same outstanding tactile response as KORG's top-tier workstations. Aftertouch puts unparalleled control of all the exceptional opsix sounds at your fingertips. Of course, we've modernized the factory Performances for aftertouch and introduced some fresh ones to the mix as well. In fact, most of the opsix SE programs have been revised to make full use of aftertouch, extended keyboard, and polyphony.

Premium metal design

The opsix SE showcases a notable upgrade in aesthetics. A slim body, specifically designed for this instrument, features a striking brown painted aluminium control panel, paying homage to vintage machines. Together with the vivid, illuminating LEDs, it brings a vibrant energy to any stage performance. The side panels, painted in a sleek black metal, amplify the overall aesthetics for a luxurious finish.

Exclusive hard case included

The opsix SE ships in a dedicated hard case, including space for cables and a sustain pedal. Your instrument can travel protected, whether you're carrying it to a rehearsal downtown or packing it up for a tour.

Get Illuminated with the Operator Mixer

At the heart of every sound is opsix SE's Operator Mixer - a simple set of six faders and knobs that invite exploration. Each part lights up red to indicate carriers or blue for modulators. Manipulating them opens up new sound-shaping possibilities to breathe fresh life into your musical ideas. This straightforward, hands-on workflow is part of what makes opsix SE so unique, just like the sounds it offers.

Direct Hands-On Control

Whether you're tweaking a preset or building a patch from the ground up, the six data entry knobs on the right give you quick access to the parameters you need and seamlessly sync with the large OLED display, giving you a clear, focused direction to your workflow. Coupled with the mixer, it makes creating fresh sounds super easy and, most importantly, fun!

Select from a full range of analogue-style filters, from the radical Korg MS-20 low-pass/high-pass filter to the powerful yet smooth KORG Polysix low-pass filter that gives your sound a vintage feel. There are also two or four-pole low-pass, high-pass, band-pass, and band-reject filters with resonance.

There's even a built-in spectrum analyser and oscilloscope that gives you visual feedback via the screen on the music you're making.

Six in One Synthesis

The core of opsix is nothing short of exponential. Since waveforms can be arranged and modulated in nearly infinite ways, opsix can easily do the sonic work that is similar to numerous types of synthesis:

Subtractive

Removing parts of the sound to get the sound you want; the most widely-used synthesis. opsix uses up to six envelopes and multi-modeled filters to achieve many cutting-edge and classical analog synthesis tones.


Semi-Modular
Rerouting signal paths to change the sound. A spin through the Alogorithm section will dramatically reshape the sound by changing how the signal routing between the operators work together, and no patch cables are needed.


Analog (Modelling)
Analog-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.


Waveshaping

Adding intentional distortion to the waveforms to achieve aggressive overtones that are either harmonic or inharmonic. This will help you achieve gritty, bitey tones dripping with character.


Additive

Stacking waveforms and blending their harmonics is key to an expansive range of harmonious, dissonant, and tension-driven sounds. With six operators available, the complete FM experience is possible, including the ability to go back in time for classic sounds you have heard throughout recording history.


Classic FM

Last but certainly not least, opsix's highly flexible and powerful architecture starts with true six-Operator FM. As a result, it easily delivers signature sounds you have surely heard on thousands of hits from the '80s on through today, and with far more polyphony than other standalone FM synths available today.

With all of these ways to realize and explore sounds, opsix SE is uniquely suited as a "future-modern-classic" synth!

Altered Reality

opsix SE is FM-based, but the similarities to the classic synthesis end there. The Altered FM architecture delivers sounds across a vast spectrum, far wider than any single synthesis has been able to cover before, thanks to new sound components; new waveforms, filters, shaping, effects, LFOs, envelopes, modulations, and more, all translating to its broad assortment of sounds.

Powerful Effects Processing

opsix SE provides three blocks of 30 types of high-definition effects that you can use together to enhance your sounds even further. There's everything from a great mix of usable standard effects like chorus, phaser, delay, and compressor to some world-class shimmering reverbs that will elevate your sound to the next level.

Automatable 16-step sequencer

opsix SE features an incredible step sequencer that rivals groove boxes for flexibility and power. Press the PLAY button on any sound and experience the complexity of the sequences! Every Program has its unique sequence stored with it, or create your very own.

You can record up to six notes per step and edit each note's velocity, gate time, and playback timing. Create long phrases or make subtle shifts in timing to emulate strums or drum rolls, something that's not possible on a typical 16-step sequencer. The motion sequencer of the opsix SE also lets you record changes of up to six parameters, creating smooth motion changes in sound within a phrase or building rhythms that change dramatically with each step.

Notes: *** Osmose 2.0 Firmware Update- August 2024 ***

What's New in Osmose 2.0?

Here's a quick overview of the new features:

Press Glide in External MIDI Mode
MPE Arpeggiator in External MIDI Mode
Preset Favourites & Playlists
2048 Preset Slots
Preset & Playlist Changes via Program Changes
New Soundbank Management System
and more!


Next-gen standalone expressive synthesizer. Add emotion & movement to your music with a simple touch.

Osmose is the new standard for musical expressivity. Use intuitive gestures to control this standalone synthesizer and upgrade your playing & production skills. Press, bend, shake, strum & more to interact with keyboards & electronic sounds in a new organic way. Whether you're a veteran keyboardist, a workflow-oriented producer, a daring sound designer, or anything in between, Osmose will take your musical journey to uncharted places.

Explore new ways to play

Behind the expressivity of Osmose lies a few natural gestures you already know well. Discover how they interact with Osmose and enhance your musicianship from the very first touch.

Design & build quality

Designed in France to stand the test of time and touring with style, Osmose is made of quality components and boasts a high repairability index.

A sound engine by Haken Audio

Made for expressivity by Haken Audio, the EaganMatrix sound engine is at home with FM, virtual analogue, and physical modeling synthesis, as well as everything in-between.

Fun to play

Easy-to-tweak presets, a playful interface, and an innovative keybed make for a fun & refreshing playing experience, for players of all levels.

Osmose's browser has been tailored to make it a hassle-free experience. It offers various filters and sub-filters based on both sound types and colours so you can find the sounds in your head quickly.

Main features:

49 Key MPE keyboard with polyphonic aftertouch
Full-size keys with 3-dimension MPE control
EaganMatrix sound engine by Haken Audio: a digital modular sandbox allowing subtractive, FM and different physical modeling synthesis
24 voices of polyphony
Assignable mod and pitch sliders
500 factory presets
128 user presets
Configuration modes: standalone synthesizer, MPE MIDI Controller, and classic MIDI Controller
Filters and sub-filters for browsing
Customisable sensitivity and velocity curves
Multi-mode MPE arpeggiator and innovative pressure glide feature
Digital stereo effects: select between reverb , mod delay, swept echo,analog echo or LPF and HPF delay
Large colour display
9 push encoders
2 Line outputs: Two 14" TS pseudo balanced line outputs
MIDI input, output, and MIDI-thru
USB MIDI
Separated 1/4" TRS headphone output on the front panel (with its dedicated volume knob)
2 continuous pedal inputs assignable to macro or sustain: 6.35 mm Jack
Power: External PSU with lockable connector, 12V, 1.5A, center positive
Dimensions (W x H x D): 894 x 316 x 87.5 mm / 35.2" x 12.4" x 3.4"
Weight: 8.3 kg / 18.4 lbs
Includes a software updater for new firmware and library versions
Includes a Mac/PC editor to create and edit sound

Notes: The Skorn da Bask table top module is the same module as the eurorack version but in a hammond 1590BB enclosure and aluminium panel, it can be powered thru a 2,1mm negative pin power jack, compatible with Boss and Ibanez standard power supplies.

Thanks to their routing options, the VCOs can not only be used to generate audio signals, but for modulating the VCF's cutoff frequency as well. Besides processing internally produced saw tooth waves, the filter is also usable for editing sound coming from other modules. Typical Touell Skouarn, the Skorn da Bask distorts like hell. Primary application: The creation of dirty, experimental sound structures and abstract rhythms.

The front panel of Skorn da Bask shows three areas highlighted in red. These zones contain the connectors and control elements for the oscillators. Each VCO comes equipped with a pitch CV input, a tune potentiometer and two switches for defining the routing as well as the frequency range used. In detail, the oscillators can be connected to the audio or CV input of the filter. Thanks to their range switches, each VCO is able to work with audio or low frequency rates. The pitch input does not follow the standard 1v per octave.

After all, Skorn da Bask is not an ordinary oscillator module, but an experimental sound generator.

The low pass filter features a slope of 24 dB per octave. A potentiometer named FreqaNs regulates the circuit's cutoff parameter, Dasson sets the resonance. For processing external signals, there is an audio input. As long as a cable is plugged into this socket, the VCOs are disconnected from the filter's audio path. Third-company modules, like an envelope or LFO, can influence the VCF's frequency via a CV input. For damping modulation signals coming from the oscillators, there is an attenuator knob. The audio output is equipped with a level potentiometer. High settings lead to juicy overdrive effects.

Notes: Typically experimental stuff from Soma, the Enner is a five-voice synth with an array of filters, electro-acoustic noise options, analogue effects and huge creative potential.

Supplier's Notes:
ENNER is a very expressive sound tool that can generate bits, pads, FX, noises, clicks, glitches, but also function as a cool vocal mic with built-in analogue FX and much more! A musician with a rich imagination and who's experienced in playing ENNER can perform an entire exciting gig using just this synth.

As an instrument, ENNER is a unique analogue synthesizer with the key principle being that all signals that make sound pass through and are managed by your body. Your hands become the central part of the circuitry. Touching different contact pads with different parts of your fingers and palms with different amounts of pressure, letting signals pass through your body defines the mixing, volume, timbre, feedback and other parameters of synthesis. Human skin has much more complex electric properties than we think. The skin provides not just resistance but also some capacitive properties and even nonlinear dependence of conductivity from current, its direction and time during which the current was applied. All of this affects the sound, making you the key part of the synthesis process.

All pots of ENNER are metallic and also function as inputs or outputs. Touching a pot can change not only the parameters but also patch the audio signals.

ENNER consists of:

The array of filters with fixed frequency properties (the triangle in the centre): the stereo high pass filter (HPF), the stereo bandpass filter (high mid - BPFH), the stereo bandpass filter (low mid - BPFL), the stereo lowpass filter (LPF). Stereo means that the filters have separate inputs for left and right channels as well as separate outputs. Sliding on the filters' pads with your fingers you can create a rich stereo image where each channel may have not only individual volume properties but also timbral ones. The outputs of the filters are mixed together and connected to the main output. Also in the triangle, you have a stereo direct input (DIR) that lets you bypass the filters.

The modulated stereo delay. The input of the delay is the two pads on the top of the triangle (DLY blue). The output of the delay is mixed with filter output and connected to the main output. Also, you have delay output connected to the pads placed on the left and right sides from the top of the triangle (DLY orange) that lets you create feedback and other interesting effects. The delay has two separate lines (left and right) with individual TIME controls (BPEMR pots), common FEEDBACK and the common pot that defines the amount of self-modulation (BIZZARE). The BPEMR pots are also touch inputs for delay time modulation.

On the right side of ENNER, there is a five-voice synthesizer with individual adjustment of frequency for each voice (TUNE knobs) with the possibility to change the pitch of all voices simultaneously (PITCH knob). TUNE knobs are also the outputs of the voices, so by touching them you can patch the voices to the filter's inputs. The synthesizer has separate output pads for each voice (pads OUT 1-5), individual modulation inputs (MOD 1-5) and ring modulation outputs (the RING 12, 23, 34 numbers indicate which voices are sources for the ring modulation). Connecting MOD and OUT pads of one voice with your fingers will pitch it up. The fifth voice has an additional modulation pad MOD 5- which can shift the pitch of the fifth voice down (connect it to +12 pad or any pad that has some positive signal including the output of the fifth voice).

On the left side of ENNER, there is the second synth that has one master generator, the output of which is divided six times by two with individual outputs for each stage of division (PULSE 1-6). This synth is aimed at creating rhythmical clicks, basses and octave tones. The frequency of the master generator is defined by the TEMPO knob. The output pads &1,2,3 are logical multiplications of different PULSE outputs giving additional and more complex rhythm combinations.

ENNER is also an electro-acoustic noise instrument. It has a piezo pickup attached to the front panel that captures sound from the casing itself. There is metallic spring and you can attach rubber bands to the panel to create various acoustic sounds. The piezo mic can capture clicks and scratches you make with your fingers, and it also allows you to create filtered feedback. Not only that, it can even capture your voice singing over the panel! To get sound from the piezo you have to connect the PIEZO OUT pad with some filters or delay inputs. Applying filters and delay on the piezo out while the panel works as a mic, catching the audio signal from the speakers connected to the ENNER output lets you create very cool acoustic feedback-based effects. PIEZO GAIN adjusts the piezo sensitivity.

The bottom of the triangle (NOISE pad) is the output of static pink noise.

External in (EXT socket and EXT pad) lets you send an external audio signal to ENNER and process it through the array of filters, delay and other ENNER stuff.

All of these features make ENNER a simple yet powerful kit of sound sources and FX that give you a rich and diverse sound palette with many possible playing techniques that you can change very fast as there is no other control over the sound other than your touches.

Specs

Array of filters

Pads DIR - direct input (no filters)
Pads HPF - highpass filter in
Pads BPFH - bandpass filter high mid in
Pads BPFL - bandpass filter low mid in
Pads LPF - lowpass filter in
(L - left channel, R - right channel)

Pink noise generator

NOISE - noise output

Delay

Pads DLY(blue) - delay in
Pads DLY(orange) - delay out
(L - left channel, R - right channel)
Pots BPEMR - delay time (L and R) also time modulation inputs
The UROBOROS pot - feedback (both channels)
Pot BIZZARE - delay self-modulation

Piezo

Pad PIEZO OUT - the output
Pot PIEZO GAIN - piezo amplification (also piezo output)

The five-voice synth

Pads OUT 1-5 - outputs of the voices
Pads MOD 1-5 - modulation inputs of the voices (try to connect them with OUT)
Pads RING 12, 23, 34 - outputs of ring modulators that multiply outputs of different voices
Pad MOD 5- - an additional modulation input for the fifth voice (try to connect it with +12)
Pots TUNE 1-5 - frequency of the voices (also voices outputs)
Pot PITCH - transposing all voices at once.

Rhythm\Bass synth

Pads PULSE 1-6 - output of binary dividers
Pads &1, 2, 3 - additional outputs that are logical AND of different PULSE outputs.
Pot TEMPO - the frequency of the source generator

External

Socket EXT - external in
Pad EXT - connected to EXT socket tip

Power

+12V center + 0.2A. ENNER requires a good stabilized and filtered PSU. We recommend contemporary switching mode PSUs with a wide input range. The PSU is included.

Grounding

In order that when playing on ENNER there would be no hum from the electricity grid interferences, the device must be properly grounded! A normal grounding connection at the electric socket, which is carried through the power cord to your audio equipment to which the ENNER is connected, is sufficient.

What's in the kit:

ENNER
12V center plus PSU
Several rubber bands

Notes: A serious, serious synth. PPG-esque wavetable synthesis with huge 24-voice polyphony, dual analogue filters and four-part multitimbrality. Incredible sound, incredible versatility.

Supplier's Notes:
The 3rd Wave is a powerhouse wavetable synth with 24-voice polyphony and 4-part multi-timbral capability that's like having four independent synthesizers at your fingerprints.

Each of its 3 oscillators per voice can be:

A classic PPG-era wavetable
A high-resolution complex wavetable
An analogue-modelled waveform
Create up to 64 custom wavetables of your own using the built-in Wavemaker. With sample-to-wavetable capability, you can connect an audio source to the audio input and generate a wavetable at the touch of a button.

Classic legacy; modern sound

While the 3rd Wave has roots in the classic digital wavetable synths of the past, it takes that concept into the 21st century with a lush, expansive sound that's a product of its expanded wavetables and warm, organic-sounding analogue filters

It boasts not only a punchy, Dave Rossum-designed 2140 analogue low-pass filter with variable saturation, but a second, SEM-style state-variable filter (low-pass, high-pass, notch, and band-pass) for additional tone-sculpting. Run both filters in series for harmonically complex textures.

4-part; multi-timbral

With 24-voices, the 3rd Wave has enough power for the most note-intensive performances.

And that polyphony really comes into play with its ability to layer up to 4 independent parts or split zones - each with a completely different sound, sequence, and dual effect.

Each stereo part has independent panning, volume, and a dedicated stereo physical output.

Modulation Matrix

The secret weapon of any synth is its mod matrix, and the 3rd Wave doesn't disappoint.

With 16 assignable slots, 12 additional fixed-source slots, 27 sources, and 114 destinations, it has the flexibility of a modular.

And all of this power is per multipart. That means up to 4 independent layers of sound, each with its own mod matrix.

Sequence notes; songs & params

The 3rd Wave's sequencer is an inspiring tool for both composers and sound designers because it is pattern-based and can sequence notes, songs, and parameter changes.

For composing and performing, enter notes and chords in real time with or without quantization for maximum groove and arrange up to 24 patterns of up to 32 measures in length into songs just as easily.

Specs

Sound Engine

3 High-resolution Digital Oscillators Per Voice
64 total user wavetable positions with 48 wavetables that contain 64 waveforms per table (32 legacy PPG waves with room for another 16 of this type)
32 original 8 bit wavetables from the PPG 2 series instruments with room for 16 more user created 8 bit wavetables
7 high-resolution modelled analogue waveforms (sine, saw, triangle, supersaw, pulse, white noise, pink noise)

VCO sync

Linear FM
6-stage wave envelope per oscillator with variable time and position that can be looped
Optional wave flow section that allows for no wavetable as well as no waveform interpolation
Upper wavetable mode as with the original PPG 2 series
Unison mode and chord mode with variable voice count

1 Analogue Low-pass Filter

Dave Rossum designed, classic, 2140 low-pass resonant filter
24 db per octave slope
variable saturation amount
optional resonance compensation

1 State-Variable Filter

12 db per octave slope
Continuously variable between low-pass, notch, and high-pass, operation with optional band-pass mode

4 ADSR+ Delay Envelopes

Filter, Amplifier, plus 2 additional envelopes switchable between exponential and vintage PPG-style response
Freely assignable to multiple modulation destinations

4 Low-Frequency Oscillators

Triangle, sawtooth, reverse sawtooth, square, pulse 1, pulse 2, pulse 3, and random (S&H)
Variable delay
Note reset
Syncable to master clock BPM

2 Digital Effects

BBD, stereo delay, tape delay, chorus, phaser, flanger, distortion pedal, rotating speaker, ring mod, room reverb, hall reverb, super plate reverb - most modelled on famous hardware devices
Syncable to master clock BPM
Parameters modulatable via mod matrix

Wavemaker Tool: Built-In Custom Wavetable Maker

"Sample-to-wave" functionality. Connect an audio source to the 3rd Wave's Audio In port, press "Make Waves" and the synth samples the audio to create a custom wavetable
Samples to convert can also be brought in as a 96 kHz wav file through USB
Store up to 32 custom wavetables
64 waveforms per wavetable
Accepts pitched or un-pitched material as input
96 kHz sampling rate
16-bit resolution
1024 cycles per waveform, converted automatically to cover entire keyboard range
Flexible wave-sampling length
Imports Serum wavetables

Sequencer: Performs both Note and Parameter Sequencing

4 parts per sequence
24 sequences per preset
Up to 32 measures per sequence
Variable quantization resolution per sequence (32nd, 16th, 8th, quarter, half, whole note, or quantization off), that is settable in real time
Variable swing

Arpeggiator: 1 Arp per Multi-part
Up, down, up/down, and assign modes
Variable range (1, 2, or 3 octaves)

Mod Matrix: 16-slot Modulation Matrix Per Multi-Part

16 slot modulation matrix with 27 mod sources and 114 mod destinations
12 additional fixed-source mod paths
Modulation assignment buttons enable quick and easy modulation routing
Mod Matrix runs at audio rates
Sequencer can record and play mod parameter changes in real time

Controls

77 knobs and 39 buttons enable deep, comprehensive editing with minimal menu diving
Pitch and Mod Wheels
Full-sized, five-octave, semi-weighted, premium Fatar keyboard with velocity and aftertouch

Programs

500 factory programs. User rewritable

In/out

4 Stereo outputs (2x 1/4" phone jack per part)
Headphone out (stereo 1/4" phone jack)
MIDI In, MIDI Out, and MIDI Thru
USB port for bidirectional MIDI communication
Audio Input for creating user wavetables from external audio source (1/4" phone jack)
Audio Input can also route audio through the filters, output chain, and effects
Sustain/footswitch input
Volume pedal input
Expression pedal input

Power

1 universal IEC AC power inlet for internal power supply
Operates worldwide on voltages between 100-240v, 50-60 Hz, 65 watts maximum power consumption

Dimensions

Shipping Box Dimensions: 44 x 20 x 13 inches, 35 lbs
Synth Dimensions: 38.5 x 14.25 x 5 inches, 27 lbs

Notes: Part of Sonicware's Liven groovebox series, this time focussing on granular synthesis and effects processing. 128-step sequencer and shimmer reverb allow you to create grooves.

Supplier's Notes:
Sample, slice, transform and reconstruct audio to synthesize completely new sounds

The LIVEN Texture Lab offers a wide variety of sound textures ranging from beautifully lush ambient pads to chaotically aggressive experimental noise that will take you to new sonic frontiers.

The Texture Lab uses a granular processor that slices sounds into grains ranging from 2 ms to 1 second in length, then transforms and reconstructs them in a variety of ways, including manipulating grain shape, density, time warp, spatial position, and playback method to create entirely new sounds.

Granular synthesis parameters are easily accessed from 10 knobs and are designed for intuitive control

Granular synthesizer with granular effects processor mode

The LIVEN Texture Lab is a 4-voice polyphonic synthesizer that can record 32 samples of up to 6 seconds, generate grains from any part of a sample, and synthesize them using two modulations sources, an envelope generator, and process the sound through different filter types.

The Texture Lab can also be used as an effects processor for real-time granular processing of stereo signals from the line input. It is also possible to freeze the flowing sounds for 6 seconds to add granulated sound effects.

Shimmer reverb for fantastical and majestic sounding spaces

The LIVEN Texture Lab features six high-quality stereo reverb types. All reverb types have a shimmer parameter that allows you to layer reverb on top of reverb in octaves to create fantastical and majestic sounding spaces.

128-step sequencer with parameter locking

The LIVEN Texture Lab is equipped with a high-performance 128-step sequencer that has earned the LIVEN series a solid reputation. In addition to recording notes, it can also record changes in granular processing parameters over time.

You can record knob operations in real time or directly record parameters to specific steps allowing for more complex sound textures.

Specifications

[Granular processor]

Synthesizer mode
- Sampling up to 6 seconds per sample (16bit - 32kHz mono, Start/end point adjustment)
- Auto start sampling function with the input level (input level can be set)
- Internal resampling function
- 32 sample memory slots

Effects processor mode
- Real-time processing of stereo signals from the line inputs
- Freeze function


- Pitch: Pitch of the sample (i2 octaves)
- Position, Length/FB: The sample range for generating grains (with random position function)
- Speed, Direction: Playback speed, scan direction, and playback direction of the grains.
- Size, Shape: Size and shape of the grains (with random function)
- Timing, Jitter: Interval of generating grains (with our original LUSH setting)
- Density: Number of the grains (up to 64 grains in legato mode)
- Diffusion: Diffusion width of the grains
- Blend: Balance between the sample and the granular sound mix
- Modulation 1: LFO assignable to various parameters (with wave shape selection, start fade-in time, retrigger, and tempo sync)
- Modulation 2: LFO assignable to various parameters (with wave shape selection, retrigger, and tempo sync)


- Attack
- Release


- Low Pass
- High Pass
- Band Pass

Reverb effects
6 high-quality reverbs with Shimmer reverb parameters
- Hall
- Room
- Arena
- Plate
- Tunnel
- Infinity


- 4-note polyphonic mode (Up to 16 grains per voice, internal sequencer records up to 3 voices of polyphony)
- Mono mode (Up to 32 grains, adjustable glide time)
- Legato mode (Up to 64 grains, adjustable glide time)
- Arpeggiator modes (Up, Down, UpDown, DownUp, Up&Down, Down&Up, Up+1, Up+2, Down-1, Down-2, Random, Play Order)

[Sequencer]
- 1 track
- Up to 128 steps per pattern
- 128 patterns
- Step length can be set from 1/1 to 1/32
- Real-time recording
- Directly enter notes for each step when sequencer is on or off
- Enter longer notes (Tied notes)
- Metronome and pre-count function
- Undo/Redo function
- Transpose function
- Swing function
- Pattern BPM / Global BPM can be set
- Pattern chain function
- Parameter Lock function to record parameter settings for each step
- RANDOM function to play back steps in random order
- STUTTER function to play back only the step being pressed

[MIDI]
- Notes, control changes, clock input/output
- IMPORT/EXPORT of user data (Including samples) via Sysex
- Firmware update via Sysex

[Unit]

27 keys (with a hold function)


- 15 physical control knobs
- Optional LATCH function prevents jumps in value when knob position and parameter values do not match.
- One physical encoder for fine adjustments.
- LCD dot indicates when a parameter value matches the saved value, or when the value has been changed.

Notes: A massive semi-modular system in a small case with the footprint of a laptop. Cascadia has MIDI in/out/thru/USB, Eurorack compatible signal levels and pro-level audio I/O to interface with the rest of your studio or get your studio started.

Modern Analogue Architecture

Cascadia is packed with a mix of classic East and West Coast synthesizer blocks. Normalized connections let you get straight to the sounds inside. Or, let your imagination run wild and patch any of the modules together however you choose. Make small tweaks to the architecture, or re-route the entire synth to your liking- the choice is yours!

Summary:
Cascadia semi-modular synthesizer.
101 patch points, 34 sliders, 16 knobs, 28 switches, 5 push buttons, and 36 leds.
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm.
USB-C to A cable.
International AC Adaptor.
Intellijel cable tie.

Two Precision Analogue VCOs
VCO A is Thru-zero FM-ready with a dedicated Index VCA, Sub Oscillator, PWM and Soft/hard sync.
VCO B is a combo VCO/LFO with 4 simultaneous outputs
Six Channel Waveform Mixer
Two patchable (normalled) inputs
Noise generator with multiple algorithms.
Optional asymmetric soft clipping on the mix output.
Liquid-Sounding, Cascaded 4-Pole Multimode Filter
Eight Modes: LP1, LP2, LP4, BP2, BP4, HP4, NT2, Phazor.
Additional dedicated outputs for LP4 and HP4.
Input Level Knob for fine control of filter input and resonance balance and added drive.
Multiple FM inputs and a QM input, all with attenuators.
Wavefolder Circuit
West Coast-style parallel wavefolder.
Normalled into the auxiliary input on the VCA in parallel with the filter.
Dual Digital Envelopes
ENV A is a versatile east coast style ADSR / AHDSR envelope generator with a hold function and dynamic level/time control. Normalled to the VCA to instantly shape your sound.
ENV B is a complex, multimode function generator with a West Coast style AR/ASR/Cycling AR, a beat syncable LFO, Burst generator modes, and the Entropic Sequence Generator (added in 1.3). Normalled to the filter for instant FM without patching.
VCA A and Output Path
VCA A is a linear VCA with auxiliary input.
Global Output Mixer with overdrive circuit and bypassable asymmetric soft clipping.

Expansive Utilities Sections
Cascadia also features a whole host of utilities for getting the most out of your patches.

The Utility Row
Sample and hold circuit with white noise normalled to the input.
Slew/Envelope follower.
Attenuverter/Mixer with multiple outputs.
Triple triangle LFO with rate control, rate input and divided outputs.
Triple buffered multiple.
Precision adder.
Signal inverter.
Bi-polar > Unity level shifter.
Expression level control for modulation the TRS expression input on an FX pedal.
Ring Modulator.
VCA B / LPF (LPG) - Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics.
The Top Row
Easy to access Pitch, Gate, and Velocity CV inputs.
Pedal Send and Return FX loop with Wet/Dry control, phase inverter and Line/Pedal level switches.
Output Mixer with Overdrive.
Eurorack Level Main output with level control for interfacing with other modular gear.

The Outside world - MIDI, Pedal and Audio I/O
Cascadia is equipped with a ton of I/O to get it connected to the rest of your gear.

Rear Panel

1/4" Stereo Headphone jack.
1/4" Balanced Output Jack.
1/4" Balanced Input routed to a slider and output on the main panel for patching anywhere into Cascadia.
1/4" TS Pedal FX Send Return and 14" TRS Expression Out.
MIDI DIN In/Out/Thru and USB-MIDI all routed to the MIDI > CV Interface on the top panel.
MIDI > CV Interface
Deeper MIDI configuration is available with the Intelljel Config App (link below). MPE Support has been added in v1.4 and supports the Ableton Live 12 Tuning systems. Dual Mono mode (added in 1.3) allows an additional channel to send its own Pitch/Gate signal on the CC/MOD outputs. All modes support MIDI Portamento.

MIDI Pitch / Velocity Outputs and Learn Button
MIDI Gate / Trig Outputs
MIDI CC / Mod - Learnable and assignable to any CC or Channel Pressure
MIDI LFO - Multimode LFO synced with MIDI or Tap Clock
MIDI CLK - Dividable MIDI clock with alternate Tap Clock functionality.
Cascadia comes ready to play.

The normalization behind the panel allows for a ton of exploration without ever adding a patch cable; there is years of material to explore in Cascadia and years more when you start patching. There is everything you need to get started: 14 assorted patch cables, USB-A to USB-C cable, and an international power supply.

Expand and Customize

In addition to additional patch cables, there are additional options for swapping the wooden cheeks for metal side cheeks or a rackmount kit with a storage tray - great for an effects pedal or patch cables.

Specs

In the Box: Cascadia Semi-modular Synthesizer
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm
USB-C to A cable
Intellijel cable tie
15V/1.2A AC Adaptor (Euro/American prongs included)

Height: 66mm (from rubber foot to top of knobs)
Width: 348mm (including wood end cheeks)
Depth: 246mm (front to rear jacks).
Power: 15V DC/1.0 A (minimum), centre-pin-positive.

Notes: A beautifully realised instrument drawing on West coast and East coast synthesis concepts to create something new and beguiling. Three oscillators, smooth filter and Buchla-style dynamics controller.

Supplier's Notes:
Taiga Paraphonic Modular Synthesizer

Taiga is a complete, modern, modular instrument that allows us to explore beyond the boundaries of a traditional analog synthesizer. The sound of Taiga can be attributed to three uniquely Pittsburgh innovations. A trio of huge analog oscillators, the unmistakably smooth sound of the Pittsburgh Filter, and the warmth of the unique Dynamics Controller. These enable you to not only create sounds that would be traditionally expected from an analog synthesizer, but also to explore new sonic textures and performance possibilities.

Taiga oscillators

Waveforms generated by the three Taiga oscillators stretch beyond the basic geometric shapes and sounds associated with analog synthesis. Taiga waveforms pass through up to three proprietary, cascading waveshapers designed to precisely manipulate their symmetry and harmonic content. In addition, each oscillator includes a robust six-stage wave folder to add even more complexity and depth to the diverse sonic palate of Taiga.

The Pittsburgh Filter

The Pittsburgh filter has defined the sound of Pittsburgh Modular from the moment it was introduced. A signature gummy and relaxed sound with no dead spots that has been tweaked to perfection. It offers a warm, smooth sweep through the full frequency range and a sweet resonance that does not roll off the low end. This generation of the Pittsburgh filter is specifically designed to ensure a remarkable interplay with Taiga's oscillators.

Pittsburgh Dynamics Controller

Pittsburgh's new Dynamics technology imparts Taiga with a uniquely organic depth and presence. By simultaneously managing both amplitude and harmonic content, the Pittsburgh Dynamics Controller expands beyond the one-dimensional VCA found in other synthesizers. It does this by utilizing new advancements from traditional low pass gates to add additional definition and dimension to the voice of Taiga.

When used in low pass gate mode, sounds shed harmonic content and become warmer as they decrease in volume. This mimics how sound waves react to their environment. Because of this connection, the Taiga sounds more natural or complex compared to other instruments.

Analogue Echoes

Echos is a beautifully dark analog delay tuned to enhance the source material by repeating it over and over. Echos utilize a pair of bucket brigade delay chips to produce a classic voltage-controllable analog delay effect that helps to place the sounds of Taiga in a simulated environment.

Open Architecture

Taiga has an internally defined signal path. Patch cables are not necessary to begin exploring. Attach a midi keyboard and plug the output into a speaker or DAW and Taiga is ready to go with a robust but familiar workflow. When your ideas grow beyond the pre-defined signal path, a 60 point patch bay opens up a fully modular instrument with access to an even deeper set of features and tools.

Complete Set of Modular Tools

Taiga includes a host of fully modular, analog, and digital synthesis tools to support and enhance its core functionality. Analog tools include a flexible dual mixer, a pair of plucky four-stage envelope generators, noise, and sample and hold. Digital tools cover external MIDI, arpeggiator, clock sync'd modulation tools, and a robust collection of random generators. The Taiga toolset is deep enough for any type of sonic exploration.

Taiga features and other info:

Paraphonic synthesizer with unique additive elements

Fully patchable - use Taiga's components as separate modules with external devices or reroute its internal patching.
Controllable via MIDI, CV, and integrated pseudo random sequencing mode
Clock-synced arpeggiator
3x Pittsburgh Modular Synthesizer developed 100% analog oscillators
Oscillator waveforms - sine, triangle, and saw - Waveforms can be combined
3x Pittsburgh Modular Synthesizer 6 stage wave folder/shaper circuit - folds inputted waves back onto themselves to increase harmonic content
Oscillators include frequency modulation (FM)
Noise generator - pitched somewhere between pure white and pink noise. Perfect for percussion or adding a bit of edge to a sound.
Variable state, multi-mode "Pittsburgh No-Dead-Spots" filter (lowpass, bandpass, highpass, modes can be combined)
Sample & Hold circuit
2x Analog ADSR / envelope generators
Pittsburgh dynamics section - an alternative to an envelope generator and a VCA, the dynamics controller is a Pittsburgh Modular invention that adds a dimension of control over a vactrol-less lowpass gate circuit, adding release time. (read more on this in the user guide)
Dual range analog LFO with square and triangle wave outputs.
LFO Range High: 2 Hz to 500 Hz Low: 41 seconds to 5 Hz
Dual Channel Mixer - 2 channel mixer and a 3 channel mixer joined together, capable of mixing both audio or control voltages.

Notes: Part of Sonicware's excellent Liven groovebox series, the XFM is a modern take on classic digital FM sounds, offering a choice of intuitive and quick sounds or logical and deep programming.

Supplier's Notes:
Classic FM sounds, effortlessly merged with FM FUSION.

Using the 4-track sequencer and presets, you can construct an entire song.

Three Fusion FM Engines X-LAB Engine
Merge two FM sounds with a single knob to create a completely new sound.

XFORM Engine
Transform one FM sound into another over a specific period of time.

X-LFO Engine
Continuously transform between two FM sounds using an LFO.

Over 300 Inspiring Preset Sounds
Ready-to-use presets including, leads, keyboards, strings, winds, basses, pads, chords, drums, and sound effects.

Two approaches to FM sound design

Intuitive and Quick
Merge and sculpt FM sounds with a single, intuitive, knob turn.

The X-Lab engine merges two FM sounds by smoothly blending their envelopes, modulation routing, and feedback. The X-Lab algorithm can merge sounds with radically different FM structures and overtones, all without losing the fundamental tuning of the sound. Pitch locking can also be turned off to create brilliant atonal transitions between FM sounds.

Merged sound can then be saved, recalled, and merged with additional FM sounds. This is called merging process FUSION FM.

Logical and Deep

For those who want to dive into the FM Engine, the EDIT mode and included overlay provide full access to the innovative 4-OP XFM engine.

15 knobs and 30 buttons provide quick and intuitive access to all FM parameters.

Explore FM synthesis without the conventional menu diving and head scratching.

4-Track Step Sequencer

Perfect for song production and live performance

Manage lead, bass, rhythm, and more, each on separate tracks.

Sequence up to 64 steps per pattern.

Save up to 128 patterns.

The parameter locking function allows you to record knob changes into your patterns. This automation function can be recorded live, or programmed in step by step.

Sub-divide the tempo down to 32nd notes for higher resolution sequencing.

Sequence longer notes across several steps, AKA Tied Notes.

Specifications:

Size
297mm (W) x 176mm (D) x 48mm (H)
11.7 in (W) x 6.92 in (D) x 1.89 in (H)

Weight:
790g/1.74lb.

Keyboard:
27 keys (with a hold function)

Knob:
15 physical control knobs
Optional LATCH function prevents jumps in value when knob position and parameter values do not match. LCD dot indicates when a parameter value matches the saved value, or when the value has been changed.
One physical encoder

Audio output:
Stereo line out (stereo 3.5mm mini jack)
Headphone out (stereo 3.5mm mini jack)
Compatible with Teenage Engineering Pocket Operator2 Series SYNC OUT
Speaker

Audio in:
LINE IN (stereo 3.5mm mini-jack)
Compatible with Teenage Engineering Pocket Operator 2 Series SYNC IN

Interfaces:
MIDI IN connector (5-Pin DIN type)
MIDI OUT connector (5-Pin DIN type)
SYNC IN jack (monaural 3.5mm mini jack)
SYNC OUT jack (monaural 3.5mm mini jack)

Power supply:
9V DC output AC adapter
Current: 1A or greater
Plug Type: EIAJ3 Standard
Inner Diameter: 1.7mm
Outer Diameter: 4.75mm,
Polarity: Center +
Compatible with power supplies designed for the Korg Volca 1 .
6 AA batteries

Synth Engine:
Four FM synth engines, X-LAB, XFORM, X-LFO, and LIBRARY

Voice mode:
6-note polyphonic mode
Mono mode
Legato mode with adjustable glide time
Arpeggiator modes (Up, Down, UpDown, DownUp, Up&Down, Down&Up, Up+1, Up+2, Down-1, Down-
2, Random, Play Order)

Sweep:
Sweep with adjustable speed, range, and curve

Filter
Low Pass
High Pass
Band Pass
Each track has its own filter envelope.

Effects:
Chorus
Flanger
Send Delay
Insert Delay
Bit Crusher
Reverb
Distortion
Low Pass
High Pass
Isolator

LFO:
Each track has one LFO which can affect both pitch and filter cutoff.
Adjustable LFO Shapes.
Adjustable start time delay for each LFO.

Sound memory:
512 FM sound memory slots (16 x 32 banks)

Sequencer:
4 tracks
Up to 64 steps per pattern
128 patterns
Step length can be set from 1/1 to 1/32
Enter longer notes (Tie)
Track level and pan can be set independently
FX send amount can be set independently for each track
Pattern BPM / Global BPM can be set
Step copy and paste function
Track copy and paste function
Transpose function
Real-time recording
Directly enter notes for each step when sequencer is on or off
Parameter lock function
Random playback function (Playback step size can be set)
Stutter function
Note Trigger probability can be set between 25% and 100%
Pattern chain function
Metronome and pre-count function
Swing function

MIDI:
Notes, control changes, clock input/output
IMPORT/EXPORT of user data
Firmware update via Sysex

Accessories:
FM sound editing overlay
Warranty

The AC adapter is not included.
Please use 9V DC output AC adapter (1A or higher, EIAJ3 standard inner diameter 1.7mm outer diameter 4.75mm, center +).
Compatible with power supplies designed for the Korg Volca 1.

Notes: Part of Sonicware's Liven groovebox series, the 8bit Warps draws on retro 80s chiptune vibes to create a mini instrument with huge character and surprising range.

*** Update: New features of the version 3.0 firmware September 2023 ***

Added 6 effect types:
- Distortion
- Phaser
- Tremolo
- Ring Modulator
- Auto Wah
- Reverse Delay

Added the Sound Locking features

A sequence can be duplicated to double the length

Looping of chain playback is now possible

New preset 29 drum sounds that can be easily made drum patterns with the sound locking feature

And several bug fixes and improvements

Supplier's Notes:
The LIVEN 8bit warps combines an 8-bit waveform memory synthesizer with a step sequencer.

Carefully selected preset waveforms and editable user waveforms along with high-quality filters and effects can be used freely to create a wide spectrum of sounds. The LIVEN 8bit warps can generate classic retro game sounds of course, but its unique 8-bit sound can also be used in a range of music genres, including EDM, hip-hop, techno and rock.

Powerful functions for live electronic music performance include 16 physical control knobs, parameter locking for each sequencer step, a looper, and SYNC IN/OUT and MIDI IN/OUT connectors to make synchronized performance with other equipment easy.

All these powerful functions are in a device that weighs only 790 g. Play it anywhere at any time.

Size : 11.7 inch (W) x 6.92 inch (D) x 1.89 inch (H), 297mm (W) x 176mm (D) x 48mm (H)

Weight : 1.74lb., 790g

Accessories: Warranty

Power supply: AA batteries x 6, or 9V DC output AC adapter (1A or higher, EIAJ3 standard inner diameter 1.7mm outer diameter 4.75mm, center +)

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Signal path

The signal path is completely analog, featuring two VCO per voice, a white noise source, a mixer, a 4-pole low pass VCF and a VCA. The control voltages are digitally generated, including 3 LFO, 2 ADSR-type envelope generators. Finally, it has a stereo digital effects processor with Delay and Chorus. LFO 1, LFO2 and the delay can be synced with the MIDI clock using a user selectable subdivision.

Oscillators

It features two VCO plus sub oscillator per voice. Each oscillator has 3 different waveforms: triangle, sawtooth and saw-tri (triangle+sawtooth). There is a fine-tuning adjustment and a transpose option, allowing tune adjustment up to +/- 2 octaves. Tuning can also be modulated with any of the three LFOs and EG1

Furthermore, each oscillator has a pulse wave that can be turned on or off, which is mixed with the other waveforms. Its pulse width can be modulated with LFO1 and/or EG1.

Oscillators can be hard synced, with oscillator 1 being the master and oscillator 2 the slave.

The autotuning algorithm takes about 2 seconds to complete. All the voices are tuned in parallel, making a lot faster than usual.

Mixer

The mixer can control the levels and mix the two oscillators, the suboscillators and the white noise or the external input (when the external input is connected, the white noise is disabled).

Filter

The filter is a 4-pole ladder-type low-pass filter with resonance control. It can be modulated with EG1, this modulation an also be affected by velocity. It can also be modulated with any of the 3 LFOs. On the other hand, it features keyboard tracking and it can be controlled by the modulation wheel or aftertouch.

Chorus

There are two types of chorus available: basic and ensemble. The Basic algorithm is subtle and allows you to add some spatiality tothe resulting sound, while the Ensemble algorithm adds a different dimension to the sound, simulating a string or vocal ensemble. The Basic algorithm uses two delay lines, while the Ensemble uses 4 delay lines. Each delay line has its own internal LFO. There are controls for rate, depth and mix.

Delay

The delay can be a stereo delay or a ping pong delay, with its maximum delay time being as long as 1.35s. It is possible to sync the delay to the MIDI clock too. If the delay is synced, the delay time knob controls the time division instead of the delay time. There are controls for the feedback and mix too.

LFOs

There are three LFOs available. LFO 1 and 2 have 5 waveshapes: triangle, ramp up, ramp down, square and random with sample and hold. LFO 3 has the first 4 waveforms and is activated with the modulation wheel and/or aftertouch.
LFO frequencies go from 0.1Hz to 100Hz. Additionally, LFO 1 and 2 have different modes:

Monophonic: The LFO is in phase for all of the voices.

Polyphonic: The LFO is generated to a slightly different frequency for all of the keys pressed. This allows an interaction of the phases, generating more complex modulations.

Keyboard Tracking (KB Tracking): The LFO frequency varies according to the note played following the chromatic scale.

Keyboard Sync (KB Sync): The LFO is restarted when a key is pressed. Each voice has its independent LFO.

Clock Sync: The frequency of the LFO is synced to the MIDI clock signal. The e7 automatically detects the BPM of the clock signal. It can be configured to generate different rhythmic figures.

Keyboard + Clock Sync: The LFO frequency will be a sub-division of the MIDI clock signal. Also, the LFO will be restarted each time a key is pressed.

Envelope generators

There are two ADSR-type envelope generators. There are controls for attack, decay, sustain and release. Attack and release can be modified by velocity and the envelope times have keyboard tracking.

Stereo

By default, the voices have a stereo panning from left to right. By adjusting the stereo spread, it is possible to set all voices to the center or set them from right to left. There is also a stereo motion option that allows this stereo spread to be adjusted by an LFO.

Presets

The synth can store up to 640 presets, 128 of them being multitimbral presets.

Multitimbral

The synth can have up to 4 multitimbral parts. Each part has its complete sound configuration, assignable MIDI channel, keyboard zone, velocity zone, transpose setting and MIDI filter. Additionally, each part can have different voice assignments and/or share some voices.
MIDI Polyphonic expression

MIDI Polyphonic expression is supported by the GS-e7. It was tested using GeoShred, allowing independent pitch control and cutoff for each voice.


Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: Originally released in 1970, Minimoog Model D was the world's first portable synthesizer and served as the archetype for all electronic keyboards that followed. The all-analog instrument gained acclaim for combining the colossal sound of the 1960s Moog modular synthesizers with the accessibility of pre-wired modulesimeaning that it could be played instantly and intuitively with no patch cables required. It was quickly embraced by a diverse roster of performers, with artists like Herbie Hancock, Kraftwerk, Rick Wakeman, Sun Ra, Piero Umiliani, Giorgio Moroder, Bernie Worrell, and Gary Numan all shaping unique sounds and forging new musical genres using the instrument.

More than a half-century since its invention, Minimoog Model D is back in production at the Moog factory in Asheville, North Carolina. An exceptional sonic tool and one of the most beloved and iconic synthesizers ever designed, it returns to the hands of synthesists of all kinds and serves as inspiration for the next generation of electronic musicians.

The three-oscillator, monophonic, analog synthesizer is securely housed in a locally sourced Appalachian cherry cabinet and hand-finished aluminum chassis. Sounding as vibrant and deep as ever, its legendary low-pass ladder filter, powerful oscillators, and rich saturating mixer retain the exact component placement and through-hole design of a 1970s-era Minimoog Model D.

While no changes have been made to the original sound engine or audio signal path, the 2022 Minimoog Model D includes a series of popular functional modifications that expand this legendary instrument's sonic capabilities. These modifications include a dedicated analog LFO with triangle and square waveshapes, a premium Fatar keybed with velocity and after pressure available via top panel CV jacks with onboard trimpots, MIDI integration, and a mixer feedback modification which allows the Minimoog Model D to overdrive and scream with the turn of a knob. And, for the first time in its history, the Minimoog Model D now features a spring-loaded pitch wheel with center deadband, allowing for improved playability and wild performance flourishes. This newest edition also includes updates to the MIDI functionality, allowing for improved modern studio integration.

SPECS
NUMBER OF KEYS
44
KEYBOARD RANGE
F0 to C4
KEYBOARD ACTION
Synthesizer (Spring)
NOTE PRIORITY
(Low, High, Last): User Selectable
SOUND SOURCES
3x Oscillators, Noise Generator and External Audio Input
OSCILLATOR FREQUENCY RANGE
0.1 to 20 kHz (In Six Overlapping Ranges)
OSCILLATOR STABILITY
(short term) > 0.25 %
OSCILLATOR WAVEFORMS
Triangle, Triangle-Sawtooth (Oscillator-1, Oscillator-2), Reverse Sawtooth (Oscillator-3), Sawtooth, Rectangle, Wide Pulse and Narrow Pulse.

Notes: Reissued version of one of Dreadbox's back catalogue synths, the Erebus is a paraphonic design with two VCOs, a characterful low-pass filter, built-in delay and updated snappy envelopes.

Supplier's Notes:
Dreadbox's most unique sounding analogue synthesizer is finally back, warmer and snappier than ever!

All you synth lovers, the time has come to dive into the Erebus...

All Analogue Paraphonic Synthesizer
Faithful Reproduction of the Erebus V1
2 Oscillators with 2 Waveforms each
Separate Glide controls and Hard Sync function
2-pole Low Pass pre-fed Filter
1 ADSR envelope and a AR Amp Envelope
Snappier than the V1

OTA VCA
Lo-Fi Delay effect
Wide Range LFO
15 patch points for an astonishing and spectacular modular experience
Compact, USB powered, Eurorack Format (42HP)

Ethereal & Dreamy

Warm sounding Oscillators
Classic Dreadbox Filter
Snappy Envelope Generators
Lo-Fi Delay effect to expand your sound
CV outputs: Envelope, LFO, Mod Wheel, Gate, CV1, CV2
CV inputs: Osc1, Osc2, Echo, Cutoff, CV, Gate, LFO Rate, PW, VCA

Specifications & Connections

USB powered (1.5 Watts)
50 Playing hours with 20,000mA portable power bank
MIDI IN via DIN5
14 MONO TS Jack Out

Dimensions: 21.5 x 13 x 6.5 cm
Weight: 1 kg

Requirements:

USB-A Adapter (5v) with 1000mA or more
MIDI device or keyboard that is equipped with DIN5 midi output
Monitor, Amp or Headphones

Included in the box:

Erebus Eurorack module
42 HP case
1x DIN5 to 3.5mm adapter
1x Ribbon cable

Notes: Dreadbox go back to their roots with this reissued analogue beast. Simple but effective single-oscillator monophonic design with a three-pole resonant filter and analogue distortion.

Supplier's Notes:
Dreadbox's highly anticipated Bass Synthesizer is finally back.

Its Deep and Dark sound is here to haunt you ...

All Analogue Bass Synthesizer
Faithful Reproduction of the 2016 Hades
1 Oscillators with 2 Sub Octaves and 2 Waveforms with PW control
3-pole Resonating Low Pass Filter
1 AD/RS envelope and a AR Amp Envelope

OTA VCA
OTA Distortion
Wide Range Triangle LFO
11 patch points for an astonishing spectacular modular experience
Compact, USB powered, Eurorack Format (42HP)

Monophonic Epicness
Super Fat Oscillator
2x Sub Octaves for extra headroom
Special Internal Bass Boost Circuit
Warm Filter
Drive effect for aggressive sounds
CV outputs: Envelope, LFO, Mod Wheel, 1v/oct
CV inputs: PW, Cutoff, VCA, CV, Gate

Specifications & Connections

USB powered (1.5 Watts)
50 Playing hours with 20,000mA portable power bank
MIDI IN via DIN5
14 MONO TS Jack Out

Dimensions: 21.5 x 13 x 6.5 cm
Weight: 0.9 kg

Requirements

USB-A Adapter (5v) with 1000mA or more
MIDI device or keyboard that is equipped with DIN5 midi output
Monitor, Amp or Headphones

Included in the box

Hades Eurorack module
42 HP case
1x DIN5 to 3.5mm adapter (specs as found at midi.org)
1x Ribbon cable

Notes: Big brother to the excellent MicroFreak, the MiniFreak is a hugely impressive hybrid synth, teaming dual digital sound engines with analogue filters for creative approaches to polyphonic sound.

Supplier notes:
MiniFreak is a 6-voice polyphonic hybrid keyboard that fuses two digital sound engines with analog filters, outside-the-box sequencing, and instant-access modulation in a playful, curious, and sometimes unpredictable way. MiniFreak encourages users to escape the ordinary and explore the unconventional with a 37-note velocity-sensitive keybed with aftertouch, weave intricate evolving performances with multiple modulation lanes, and discover endless sweet spots with a built-in digital FX engine - a wildly creative experience.

Unprecedented hybrid polyphony

With over 20 modes to choose from including Virtual Analog, FM, and Additive, the interplay between MiniFreak's two oscillators can result in truly unique compound sonic behavior. With 6-voice polyphony, analog filters, and the ability to process engine 1 through engine 2, MiniFreak puts premium polyphonic synthesis exploration into a compact & tactile instrument that's as addictive as it is powerful.

Customizable & experimental sound design

Embellishing the popular Freak modulation matrix, MiniFreak gives users even more control over shaping, transforming, and evolving their sound, with features like polyphonic ADSR envelopes, customizable multi-segment LFO shapes, FM & Ring Modulation, and the familiar Spice & Dice randomization.

Mix-ready stereo sound

MiniFreak comes with stereo outputs and 3 digital FX slots with 10 FX types to choose from. From stereo-enhancing chorus, to surgical 3-band EQ, to gritty 6-mode distortion, users will have everything they need to push their sound over the edge while keeping it mix-ready.

Expression, meet chaos

Despite its penchant for wild & exploratory sound design, MiniFreak is also built as a responsive instrument of expression. Its velocity-sensitive 37-note keybed with aftertouch and spontaneous Seq/Arp functionality makes it a dream to perform with, while its randomization features and modulation lanes put playfulness and sonic momentum immediately at users' fingertips.MiniFreak VMiniFreak comes with a dedicated VST counterpart, letting users totally integrate its unique hybrid sound into their DAW productions and vice versa. Using identical sound engines and architecture, it offers a like-for-like virtual experience of the synth itself, at no extra cost.

What's in the box:

Box content
MiniFreak Unit
Universal PSU - 12V 1A
USB A to USB 2.0
Registration card

Instrument dimensions
Size : 22.75 x 9.09 x 1.57 inches (578 x 231 x 55mm)
Weight : 6.48 lbs. (2.94 Kg)

Notes: Unique touch-activated instrument with built-in speaker, allowing you to trigger notes with one hand and modulate the timbre via touch pads. Unorthodox tones, unorthodox interface. Lots of fun.

Supplier's Notes:
Touch Tones is a touch activated auto harmonic synthesizer, with a 3 octave tuning range, XOR logic modulator, Harmonicon auto harmony generator, and two onboard bandpass filters. The left side of the Touch Tones holds three capacitive touch pads for playing notes, while the right side contains a set of 7 touch pads to modulate the different parameters sequencing the synthesizer.

Three octave range plus XOR modulator.
Harmonicon automatic harmony keys play a perfect 5th of each tuned ROOT note.
Dual Luma filters for active timbral shaping via light control.
Wear the Touch Tones for Function or Fashion with the included chain lanyard.

Notes: Still based on 80s games console circuits, this second-generation model of the unique Twisted Electrons FM synth gives more freedom to try out different chips. Same gritty sound and hands-on control.

Supplier's Notes:
This updated version is identical in appearance and functionality but will include a pair of YM3438 chips instead of the YM2612. The YM3438 is a variant of the YM2612 that is identical in functionality and was featured in the Sega Megadrive II. The circuit layout has also been updated to grant access to the FM chips with minimal disassembly.

Indeed the chips are now socketed (removable) and accessible by removing the bottom panel.

This allows you to install alternate FM chips (like the YM2612, modern alternatives or even custom sound chips).

You can also mix different versions of FM chip as there are 2 slots that can be configured individually.

MEGAfm MKII features the same audio circuitry and analog distortion as the MKI, as a result both chips sound very similar inside of MEGAfm.

The firmware will work identically on both versions.

Beautiful dirt

Unlike most FM synthesizers that are very clean and digital, the vintage FM chips within MEGAfm have very characterful tone allowing a broad sound palette ranging from beautiful plucked strings to growly distorted bass lines.

Tactile operators

Hardware FM synthesizers are infamous for their reduced controls and complexity to program, with tiny LCD screens and only a couple of buttons to operate a load of menus...
With its 32 operators faders, 14 knobs and 15 buttons MEGAfm offers unprecedented hands-on FM control!

Every knob and fader can easily be modulated by the easy to use LFOs.

Make it a double!
The vintage FM chips from the 90s each offer 6 voices of crispy FM, 4 operators per voice and 8 algorithms.


MegaFM features 2 chips for a total of 12 voices spread across two outputs (or summed to one)

Features:

12 Voice Polyphony
Dual vintage FM chips (included)
8 Algorithms
600 preset memory (saving to any slot) arranged in 6 banks. Easy upload/download of banks to and from computer vis SYSEX.
Preset randomiser
4 Voicing modes (Poly12, stereo/wide6, special CH3 mode, 12 voice unison with detune/fat knob
Stereo or Mono output (1 chip per channel or both chips summed)
32 Sliders for total control of all 4 operators
14 knobs
15 buttons
23 LEDS, LED numeric display.
3 LFOs to modulate any parameter
7-mode arpeggiator with transposable Sh-style step sequencer
Vibrato with depth and rate
MIDI clock on all LFOs, ARP and Vibrato
All faders/knobs send MIDI (use MegaFM to control your favourite modern FM synth!)
Full MIDI automation
Dual 6.35mm TS output and 6.35mm Stereo Headphones output
Brushed/Anodized Aluminum Case
Sturdy metal panel bolted potentiometers
Dimensions: 30CM x 13CM x 5CM
DIN5 MIDI input with MIDI channel learn and thru/out

Notes: Updated take on Artiphon's unique instrument, now with built-in sample engine. Loop, manipulate and create all in the unit, with built-in speaker and expressive motion sensor options.

Supplier's Notes:
Hold out your hands and meet Orba 2, the follow-up to Artiphon's award-winning synth, looper, and controller. Orba 2 has everything you loved about the original with multiple ground-breaking upgrades. Now, you can play any sound imaginable with its unique sample engine. Listen through the built-in speaker, or plug in and get loud. Customize your instrument with the Orba App and share your creations with friends. Take your creativity to new heights as you take Orba 2 anywhere you go.

Play any sound in the world
Orba 2 features a brand new sound engine that includes sampled audio recordings. This means you can now play instruments like electric guitars and upright pianos, as well as more adventurous sounds like vocals, found sounds, and custom artist songs. Imagine conducting an orchestra in the park with no strings attached and no screens required.

Create your own instruments
Orba 2 players can also capture or import their own sounds to create completely unique instruments. With the press of a button in the Orba App, everything around you can be turned into an Orba preset. A bicycle bell, a bird singing, or your roommate's amazing voice can all be played, looped, and shared as a musical melody. Sample recording requires a cabled USB connection.

Loop songs in seconds
Orba 2 allows you to record loops right on the device itself. Using Drum, Bass, Chord, and Lead, you'll be able to layer sounds to create songs that are uniquely yours. Orba 2 also has a quantize feature that snaps your musical phrases to the beat so that every moment fits perfectly into the groove. And since Orba 2 has far more memory than its predecessor, you'll be able to make way longer songs: up to 128 bars!

Play with gestures
Orba 2's touch and motion sensors combine to capture even the most subtle micro - movements. Its improved ceramic - like playing surface simultaneously reacts to the nine simple gestures: Tap, Press, Radiate, Tilt, Shake, Spin, Vibrato, Move, and Bump. Each gesture can control the onboard synth engine or your MIDI music software of choice. With unprecedented express ive potential, you'll never play the same note twice.

MIDI control
Use Orba to control your MIDI - based software and hardware instruments (via USB - C or wirelessly via Bluetooth MIDI). Orba works with GarageBand, Ableton Live, Logic Pro, Pro Tools, Cubase , FL Studio, as well as any MIDI - compatible mobile app. In addition, Orba is fully compliant with the new standard for MIDI Polyphonic Expression (MPE), making it capable of multiple independent note expressions.

What's in the box?

Orba
USB Cable
Quickstart Guide

Dimensions

3.14" (diameter) x 2" (height)

I/O
USB-C (USB 2.0 Class Compliant Audio/MIDI)
3.5mm (1/8") TRS Analog Headphone Stereo Out


Bluetooth
Bluetooth LE MIDI (MIDI only)
Note: Windows 10 does not currently support Bluetooth LE MIDI
Speaker System
3W built-in active speaker system

Compatibility

iOS 11 and newer
Android 9 and newer
macOS 10.12 and newer
Windows 10 (64 bit)

Note: Firmware updating requires a cabled USB connection and can only be done from a desktop computer.

Note: Transferring a sample from your device to Orba 2 requires a cabled USB connection.

Notes: Updated take on Nomono's mini synth. Virtual analogue and granular synthesis with effects, sequencer, looping and performance functions. An affordable but flexible instrument.

Supplier's Notes:
The Qun mk2 is a powerful and unique pocket synthesizer with sequencer and looper.

Normally, cheap synthesizers don't have full flexibility because of hardware limitations.

Nunomo had in mind a small synth that has full flexibility of the real synth with an affordable price tag- and Qun mk1 was the synth.

The Mk2 receives a big improvement from the mk1 by adding LED buttons and external processor for UI processing- SD card support is added.

Once you get used to it, it will be so powerful and it will provide tons of flexibility. It is a real synth, not a preset machine.

If you are looking for a pocket music sketch tool, this is it.

Connectivity: Standard MIDI (TRS Type A, comes with the synth), UART MIDI(Supports MAC OS X and Windows through the Nunomo SerialMIDI https://github.com/raspy135/serialmidi .

Analogue Modelling engine

The analogue modelling engine is made from scratch.
All analogue modelling engine parameters can be configured through MIDI.
2 Oscillators, 2 voices. It can be used as Quad tone (4 voices) or Dual Mono.
Flexible MOD (CV) routing. The signal routing is very flexible, close to modular synthesizer experience. You can route signals as normal, or totally radical.
AUX input can be used for external audio signal, or for modulation.
4 Envelope Generators
FM (4 Operators x 2)
1 LFO, rate can be controlled by MIDI notes
1 Organic sounding VCF
2/4 Poles, Low-pass, Band-pass, High-pass, Notch)
Keysync
1 Effect (Delay, Chorus, Flanger)
MIDI clock sync and beat clock sync
Wavefolding.
Granular synthesis
Oscillators can be used as a granular synthesis engine.
Player / Sequencer

Player (Piano mode)
Mind inspiring 64 step sequencer will generate beats for you
Note On/Off/Double/Triple
Transpose / Note width(Length)
Randomness control
Pattern shuffler
Scale quantize
Arpeggiate steps
Looper
Looper can record the sound up to 24 sec per recording, synchronized with the sequencer.

3 tracks
5 Scenes (3x5 = 15 recordings per session)
Play / Rec / Overdub

Preset bucket
Preset bucket is made for quick preset recall
It has 8 bucket per session, each bucket has 8 presets and 64 sequencer pattern
Mixer
3 tracks, stereo panning
Mute buttons
Extra processing mode allows to use the sound engine as a stereo effector.
Integrated compressor
SD card
Saving recording sessions
Saving preset data with sequencer patterns
All recorded data is saved to SD card, you can import the data to your DAW
You can import WAV files to Looper granular
Firmware update via SD card
For the completed manual and other resources, please visit https://github.com/raspy135/Qun-mk2 .

Notes: Updated version of the ground-breaking synth, sampler and sequencer. Better than ever, with legendary sound quality and portability.

Supplier's Notes:
The beauty of evolution.

Louder, thinner and 100 times better.

Introducing the all new OP-1 field. Injected with more than a decade of ideas, refinements and improvements. Just to mention a few: stereo throughout the whole signal chain, Bluetooth MIDI, USB type-C, a new speaker system with a passive driver for detailed, fat and loud sound, a massive 24 hour battery life, multiple tapes and recording formats, new great sounding reverb and the 'dimension' synth engine, an all glass, flush, high resolution display. The graphics have also been meticulously reworked, screen by screen.

Reworked, refined, reborn.

Think of OP-1 field as the natural continuation of its predecessor. Updated with the latest technology, improved design and finely tuned with professional musicians, recording artists and sound designers in mind. Higher quality in all aspects, from its circuitry to connectivity and flexibility, it's tailor made for professionals in the field.

The new stereo sample engine is just one of the features that takes the OP-1 field to a higher level. With increased sampling time up to 20 seconds and dual layer mode for instant mixing of the a and b channels or via an assigned LFO.

Four new recording formats: Studio 4-track, vintage 4-track, porta and disc mini.
All with their own unique characteristics and graphics. Now with multiple tapes or discs, up to 8 in total.

If it feels thinner, it is.

By lowering the aluminium body around the keyboard, the new OP-1 field feels lighter, thinner and more precise. with 2k moulding Teenage Engineering have also managed to fit a dual 2.4 GHz antenna system inside the aluminium body.

The back is warm, velcro and bass.

Two soft velcro rings have been added on the back for fastening covers and accessories. Perhaps you want to stick your op-1 field on top of your full size keyboard, or slap it on a guitar? Use the included adhesive looped back and start experimenting. On the right you'll find an additional passive loudspeaker for hugely improved bass. And for a 'no-more-cold-metal-on-your-lap' experience, the aluminium body has been folded in a warm, soft touch, hard cover.

The first accessory out using the velcro rings is the Bill Amberg leather wrap that attaches to the back and wraps around the op-1 field and locks around the encoders.

Dimensions: 28.8 cm x 10.2 cm x 2.9 cm

Notes: Cracking value in this brutalist beauty manufactured by Bristol's Future Sound Systems. Interesting features like wave-shaping VCOs and Sallen-Key filter make it the ideal starting point for a bigger modular setup.

Supplier's Notes:
Malevolent has been designed by Paul Whittington in collaboration with Bristol based synth manufacturer Future Sound Systems who have provided the analogue circuitry, and Ben Supper who developed the control interface:

Paul has a had a long career in developing products for some of the biggest names in the industry and is now using his expertise to build instruments, bringing in talents from friends he's made during his tenure in development.

Future Sound Systems are a renowned Bristol based synthesizer manufacturer, who are responsible for some of most forward-thinking designs on the market, they specialize in modular and semi-modular synthesizers & their design prowess is very apparent in Malevolent.

Despite its diminutive size, Malevolent sounds big, aggressive and is capable of everything from soaring leads, huge bass sounds, percussive phrases, weird sound FX and more.

It's form factor, user interface and price point make it a great option for those taking their first step in the modular domain, but it's unique sound, extensive modulation capabilities and the options for integrating seamlessly with other synthesizers, makes it a great option for experienced user who's looking for something a little different.

Modular Pure Analogue Synthesiser

Pure Analogue signal path designed by Future Sound Systems
Pure VCOs

19 Outputs and 19 Inputs for 3.5mm mono jack cable patching
Normalised signal path for immediate sound Malevolence
Additional rear panel line out
Additional headphone out


2 Voltage Controlled Oscillators
Saw / Triangle / Pulse outputs plus Mix for each oscillator
1V/Oct pitch control input
Shape control / pulse width modulation input
2x Frequency Modulation inputs
Coarse / Fine tune control
Shape mod amount control
FM1 and 2 mod amount controls
Shape control
Selectable waveforms for the mix output
Individual osc level control


LFO (Low Frequency Oscillator)
Triangle / Square wave outputs
Rate control

2x Envelopes
Individual ADSR controls for each envelope
Individual gate inputs
Individual envelope outputs


Multi-mode 2 pole VCF (Voltage Controlled Filter)
Low pass / Band pass / High Pass individual inputs
2x Frequency Modulation inputs with amount controls
Filter cutoff
Filter resonance


Mixer
Noise w/level control
Aux input w/level control


VCA (Voltage Controlled Amplifier) with overdrive control
Compatible with Eurorack standard 1V/Oct gear
Monophonic and patchable allowing individual pitch control of each VCO and gate control of each envelope
USB bus-powered
MIDI In / Out
Headphone out
Line out
Analogue clock in & out


USB-MIDI to 1V/Oct CV & gate conversion
All pitch and gate control is fully analogue
Analogue clock In / Out


Multi-function Joystick control
Left / right for pitch bend
Performable portamento
Performable vibrato
This is in addition to the analogue LFO
Latching hold mode


Arpeggiator
6 arpeggiator types
Up, Down, Up/Down 1, Up/Down 2, Played & Random
Auto clock sync
Detects analogue / MIDI or USB-MIDI clock and synchronises the arpeggiator automatically
Selectable sync rates when clock detected
Rate / sync control
Latch
6 Octave range
Analogue / MIDI / USB-MIDI Clock output when arpeggiator is running


Keyboard Control
32 Velocity-sensitive mini-keys
Octave shift +/- 4 octaves
Pitch output
Velocity output
Gate output
Local Off mode for DAW use


Includes:
5 Patch cables

Power Supply (9V 600mA)
USB C lead

Getting Started Guide


Weights and Dimensions:

Product (unboxed):
490 x 250 x 80 mm
2.61 kg

Product (boxed with contents):
690 x 320 x 160 mm
3.70 kg

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: Another intriguing experimental offering from Soma Labs. ROaT is a digital synth inspired by 80s video games. Four oscillators combine with a sequencer to create drones, soundscapes and glitchy loops.

Supplier's Notes:
Rumble of Ancient Times (RoAT) is an 8-bit noise synthesizer and sequencer inspired by the clever programming of the early PC era when an entire video game would fit on a floppy disk. RoAT is capable of a wide variety of sounds ranging from dense noise scapes to diverse glitching rhythmic patterns. The compact and portable instrument contains many elements that can be combined into surprising musical results.

The "heart" of the synthesizer contains 4 sound oscillators, each with a tunable waveform and an individual LFO, which can modulate the tone or volume of the oscillator. The modulated signal of each oscillator is mixed with other signals using 1,536 variations of complex summing algorithms that contain FM, ring modulation, bitwise logical operations and more.

The synth contains an 8-bit resonant lowpass filter with a distinct Lo-Fi character.
The built-in sequencer can be synced to an external device and also send clock out.
RoAT is battery powered and can work up to 130 hours on one set of AAA batteries.

Rumble of Ancient Times is built on a very simple 8-bit microcontroller similar to the ones used in the "brains" of old refrigerators and other simple electronic devices. Thanks to some very clever programming, it's also able to drive a very capable synth with many features!

In stark contrast to modern consumer electronics, this synth celebrates and emphasizes what can be achieved with efficiency of code and using chips considered obsolete by industry leaders. We live in an age where text editors can be 1GB or more and simple things like checking email require the latest OS and powerful processing, despite the core tasks being no different than 15 years ago with a fraction of the computational power.

So RoAT proposes a new kind of ecological thinking with the innovative use of chips that were developed and produced decades ago, instead of turning them into millions of tons of trash. We can still use technology that the industry forced us to consider obsolete, with the added benefit here of extremely low power consumption. It's an environmentally friendlier approach than galloping in the rush of planned obsolescence that damages our planet and wastes precious resources.

Rumble of Ancient Times was designed and programmed by Kakos Nonos, a new creative mind who joined the SOMA development team. His very unique style of building electronic musical instruments combines quality craftsmanship, advanced programming and a love for medieval acoustic instruments such as gusli, wheeled lyre and bagpipes.

Specifications:

Sync out voltage: 5 V
Minimum syn in voltage: 0.2 V
Current input: 20 mA
Maximum output voltage: 5 V
Audio output:3.5 mm jack
Sync out: 3.5 mm jack
Power Supply: 4*AAA battaries
Size: 122 x 136 x 40 mm
Weight (without batteries): 145 g

Notes: Amazing value from this little Eurorack-compatible analogue synth. Loosely Moog-inspired semi-modular East Coast subtractive design with MIDI control and great sound.

Supplier's Notes:
East Beast

Fully analogue East Coast style semi-modular synthesizer

What's the first thing you think of when you hear the word "synthesiser"? Close your eyes and think about.

Anyway, for a lot of people, the word synthesiser invokes visions of big filter cutoff knobs, envelope generators, and importantly, big fat-sounding voltage-controlled oscillators. These are the hallmarks of East Coast-style synthesis.

East Beast is a fresh take on these old-school concepts with a few beastly twists thrown in here and there.

Furthermore, you can pop East Beast out of its included enclosure and it transforms right into a 40HP eurorack module
East Beast's oscillator, designed in partnership with Pittsburgh Modular Synthesizers, is a part of their 5th generation of analogue oscillators stemming from a super-serious 10 years of continued research into analogue oscillator development.

Its circuitry is not a clone or based on any outside designs. It is made with 100% modern components. This keeps it very stable, and giving it a super rich, and unique sound.

Most of the filters you are used to hearing are transistor ladder filters or copies of transistor ladder filters. East Beast's filter is not one of those. Pittsburgh's whole goal of making this filter for East Beast was to create a filter that's creamy smooth with no dead spots, a very common phenomenon in all filters, but check it out. This one's got no dead spots. From nasally to biting and elsewhere, it's all one large sweet spot.

East Beast's filter is a multi-mode filter, meaning it can be used as a low pass filter, high pass filter, bandpass filter, or a combination of the three for an even wider sonic palate.
Shape the beast in your own image
To further sculpt the sounds Cre8audio has included an envelope generator & LFO. The custom envelope circuit creates a snappy, percussive attack for expressive performance. The dual range LFO opens up a wide range of LFO and audio rate modulation possibilities.

Get patched.
Semi-modular means that the East Beast will work without any patch cables or anything. But what fun is that? Who doesn't want to have their own personal spaghetti mess of cables sticking out of their synthesizer to get wacky with?
East Beast has basically 9 different patchable modules (Oscillator, filter, envelope, VCA, LFO, multi-mod tool, sequencer, MIDI to CV converter, and button keyboard) with a whopping 18 Eurorack compatible patch points to plug into itself and your other gear. All for your patching pleasure.

As well as this, East Beast has MIDI in and a fancy MIDI thru so you can chain multiple MIDI monstrosities together- you can plug in a MIDI controller into East Beast and do as you wish.

But wait, there's more! East Beast includes quite a few additional performance features. You can dive in and dive in with its built-in tap tempo clock, arpeggiator, and sequencer. There's a lot of opportunities to inject in some randomness too.

Specifications for when used as a eurorack module

Width when used as a module = 40hp
Depth when used as a module = 25mm
213mA power draw when running +12V rail
151mA power draw when running -12V

Input voltage range of oscillator = 0-10V

Included in the box - 1x East Beast, 1x East Beast wall-wart power supply, 5x Amazing Nazca Noodles Patch Cables, 1x 3.5mm to 5 pin MIDI Din pigtail, and love (love's presence likely, but not guaranteed)

Notes: As a stand-alone instrument, Mavis is a straightforward analogue synthesizer with patchable modular utilities and the unmistakable Moog sound and quality. Easily remove Mavis from its case and it becomes a 24-point CV controllable module (44hp) ready to be installed into your Eurorack system or alongside Moog's other semi-modular instruments.

Mixing the familiar with the exotic, Mavis features Moog's legendary oscillator and filter circuits alongside a diode wavefolder - the first analogue wavefolder to appear on a Moog instrument. Combining traditional subtractive synthesis with additive wavefolding and oozing with personality, Mavis' clever presentation of synthesis modules and utilities ensure deep creative synergy and musical connection.

Mavis is a powerful, fun, and low-cost Moog that makes learning synthesis or expanding an already-advanced studio setup approachable for anyone looking to explore classic analogue sound in a new way.

Get closer to the circuits at the heart of Mavis and come away with a Moog analogue synthesizer that is uniquely "yours". No soldering is required and can be completed by any skill level in an afternoon.

A powerhouse on its own, Mavis was also designed to enhance any interconnected Moog semi-modular setup or Eurorack system. In 44HP, the synthesizer offers incredible value with two oscillators, full ADSR, ladder filter, sample and hold, wavefolding, attenuators, mixer, mults, and much more for more complex musical arrangements.

Mavis is eager to play along with other voltage-controlled devices (especially with Moog's other semi-modular instruments), and its useful collection of utilities and flexible control voltage routing allows for intricate dialogue between them.

Built-in keyboard with Glide and KB scaling

As a standalone instrument or as a 44HP Eurorack module, Mavis adds an expressive 1 v/o controller to any setup with the flexibility to dial in experimental new pitch relationships via the KB scale knob and explore musical intervals that go beyond the established standards.

Full Range Analog Oscillator

A Voltage Controllable Oscillator with PWM (Pulse Width Modulation), Waveform mixing, and Mod Source mixing, delivers rich harmonic character and motion.

Voltage Controlled Filter

Sculpt your sound with the -24-dB Moog Low Pass Ladder Filter, delivering the sonic power behind the distinct sounds of Moog basslines and leads.

Audio Rate LFO and 4-Stage Envelope Generator

Mavis uses crossfaders in its modulation routing instead of switches, allowing you to blend between a variable shape LFO and four stage envelope generators for interesting and unusual modulation contours.

Wavefolding and Modular Utilities

Mavis features Moog's first-ever wavefolding circuit, allowing for additive synthesis to sit alongside traditional subtractive synthesis, unlocking sounds not heard from a Moog before. Mavis also features a broad modular utility section complete with attenuators, offsets, mults, and a flexible DC-coupled mixer providing the tools needed for creative patching and sound design.

Patchable Sample and Hold (S+H) circuit:

Generates a random CV pattern that can be patched to modulate other parameters, including setting Mavis into a "random sequencing" mode of performance.

24-Point Patch Bay

Mavis is eager to play along with other voltage-controlled devices (especially with Moog's other semi-modular instruments), and its useful collection of utilities and flexible control voltage routing allow for intricate dialogue between them.

Protective Cover

Mavis includes a fitted protective cover for use during studio downtime or taking your instrument on the go.

Specs

Type: Semi Modular Analog Synthesizer - Operate standalone or as 44hp Eurorack module
Polyphony: Monophonic
Keypad: 1 Octave Keypad w/ Glide and Scaling
Sound sources: Analogue Voltage Controlled Oscillator (Mixable Saw/Square)
Filter: Analogue -24dB Moog Low Pass Ladder Filter
Envelope: 4-stage Analog EG (Envelope Generator)
Wavefolder: Diode Wavefolder
LFO: Analogue LFO (Mixable Triangle / Square)
Modular utilities: Sample and Hold, Attenuators, Offsets, Mults, and a flexible DC-Coupled Mixer
Patch bay: 24-Point Patch Bay (3.5 mm)
Accessories: Protective Cover, Patch Cables, Calibration Tool, and Nut Driver Included

Notes: A true powerhouse of a synth, packaging the Quantum synth engine into a more manageable four-octave design. Five synthesis modes, powerful stereo filters, performance features and outstanding playability.

Supplier's Notes:
Waldorf Iridium has made the impossible possible. The mighty synth engine from Quantum is now available in a compact form. Tracing the footsteps of its bigger brother, Iridium features all the synthesis elements of Quantum as well in a rack-compatible format. The combination of the powerful engine, incredible flexibility and detailed sound shaping facilities creates sheer endless possibilities of sound. Yet, the comprehensive layout and easy-to-understand structure lets you design your own sounds in no time. Sporting a solid metal casing and the same high level of craftsmanship like Quantum, Iridium is now ready to take over studios and stages throughout the world.

Contributing another entry in Waldorf's rich history, Iridium joins the family as a direct descendant of the PPG Wave. Though, Iridium offers much more than its ancestor. Five different synthesis models are provided by Iridium for each of the three oscillators:

Wavetable
Waveform (Virtual Analog)
Particle (Sampling and Granular Sampling)
Resonator
Kernels

Kernel mode has been introduced with the OS 2.0 of Quantum. This huge upgrade allows one oscillator to be turned into up to six sub oscillators. These can be interlinked through FM at audio rate and arranged in user-definable constellations. Just this upgrade alone would have provided enough additional features to create a synthesizer on its own. Now, all those functions have been integrated into Iridium as well.

Up to 7000 patches can be saved in Iridium. Patches from Quantum can be loaded in Iridium and vice-versa.

Iridium features three digital filters per voice. Two in the Dual Filter section and another one in the Digital Former. Several types are available to choose from:
12 or 24dB and Lowpass/Highpass/Bandpass with optional saturation or dirtiness.
Various filter models are available including those from Waldorf Nave, Largo and PPG 3V.
The Dual Filter section can be controlled independently or together in several different link modes.

The Digital Former offers all the filter types and models from the Dual Filter plus unusual models like Comb, Drive, Bitcrusher and more in addition.

All filters retain a true stereo signal throughout the entire structure of the instrument.

Specifications
16-voice polyphony, duo-timbral
Compatible with the Waldorf Quantum synth engine

3 Oscillators
Oscillator Modes:
Wavetable
Waveform (VA)
Particle (Sampling and Granular Sampling)
Resonator
Kernels (up to 6 sub-oscillators which can be interlinked through FM at audio rate)

3 Stereo Filters per voice
True stereo path
Dual Digital Filter:
Two filters with independable modes
12/24dB LP/HP/BP in all combinations
Nave, Largo, PPG, Quantum and StateVariable models
Digital Former:
Filter models from Waldorf Nave, Largo and PPG in HP/LP/BP/Notch
Comb filter
Bitcrusher
Drive
RingMod
StateVariable mode
Analyzer displayed in Filter view
Filter curve moves when modulated (optional)
Sophisticated filter routing options with modulatable panning and levels

Modulators:
6 Envelopes
6 LFOs
Komplex Modulator (LFO/Envelope combination with user-definable shape)

Mod Matrix:
40 slots
Fast assign mode
One additional control amount per slot
Identical Sources and Destinations can be used multiple times until the matrix is full

Pads:
4x4 silicon pad matrix with RGB backlights
Pads can play notes, chords, arpeggios and sequences
Latch mode

Performance features:
Arpeggiator
Step sequencer with up to 32 steps for notes and parameters
Favourites screen for quick patch recall
Onscreen Mod Wheel, Pitch Bend and Aftertouch

Screen:
Industrial-grade highly responsive touch screen

Patches:
Over 1000 factory sounds
Capacity of 7000 patch memory slots (numbers 0000-9999 can be used)
Patches from Quantum can be loaded and vice-versa
Category filter for patch list
2GB user sample flash memory

Connections:
2x TS output
2x TS input
Headphones output with Gain control
DIN MIDI In/Out/Thru
USB MIDI
USB host for storage and MIDI devices
MicroSD slot
Kensingtonr lock

CV connections:
4 CV inputs plus Gate In, Trigger In, Clock In, Clock Out
Inputs can be used as modulation sources in the Mod Matrix

Overall:
Sturdy metal case with aluminium knobs

Dimensions: 440mm wide by 305mm depth by 85mm height (including controls)
Weight: 5.4kg
19" rack assembly parts available

Notes: Synth meets sequencer in this limited-edition Noir version of Arturia's excellent MiniBrute. Semi-modular design and extensive patch bay offer a wide variety of sound design options.

Supplier's Notes:
The MiniBrute 2S Noir Edition is a thrilling hybrid synthesizer enhanced for the modern musician. Combining raw analog power, an intuitive triple-layered step sequencer, a modular-worthy patch bay, and a stealthy black exterior, MiniBrute 2S Noir delivers the Brute Factor, and then some.

Pure synth power

A powerful standalone instrument, MiniBrute 2S Noir has massive synth potential that's intuitive, accessible, and fun to use. Whether you're a seasoned pro or new to the world of synthesis, you'll find its layout easy to understand, quick to master, and hugely inspiring. Thanks to its analog semi-modular architecture, you have hands-on control of every parameter, so you can sculpt your oscillators, sweep your filters, sync your LFOs, and control your envelopes on the fly to create a sound that's uniquely yours, bound only by your imagination.

Discover the modular world

Open up exciting new possibilities by rerouting MiniBrute 2S' signal with the modular patch bay. Better still, patch it to your existing Eurorack system and explore new connections, then sequence and shape with MiniBrute 2S' myriad of controls. With this synth at your command, your creative workspace will become a experimental sound laboratory.

Step in line

Featuring an awesomely powerful, triple layered step-sequencer, multi-mode arpeggiator, and high-quality performance pads, MiniBrute 2S Noir perfectly suits adventurous electronic musicians who want to take their creations further than ever before.

The Brute Noir Editions

Unique analog instruments, where vintage synthesis and cutting-edge technology collides in the name of creative freedom and controlled sonic chaos, decorated with stealthy black exteriors. These are the Brute Noir Editions, the darker side of analog.

Included Software:
Arturia MIDI Control Center

Notes: The top dog of the Hydrasynth range, featuring a dual synth engine offering 16 voices (double the standard model) and a larger six-octave keyboard. Serious synth power with great wavetable sound.

*** New 2.0 Firmware update for all Hydrasynth models - March 2023 ***

This is a free of charge update for all current and new users of Hydrasynth. The biggest news in this update includes:
Expanded memory to 8 banks (Keyboard, Desktop, and Explorer only)
NEW modulation source: VOICE MODULATOR
OSC Bit reducer
LFO quantizer
ENV quantizer
LFO Step Advance
Global FX bypass
Increased Vibrato resolution
New Sustain pedal options including Sostenuto
More LED options
Glissando in glide options
Arp Range goes to 6 octaves
Arp Step Offset parameter
More Rand/Init shortcuts (all STEP LFO steps, Wavescan waves, Voice mod offsets)
Local On/Off saved
......And more!
This is the first major update to the Hydrasynth family in a little, which adds a tonne of new features.


Supplier's Notes:
The ASM Hydrasynth Deluxe is the new flagship Hydrasynth. Offering a dual-engine setup with a total of 16 voices plus an all new 73-note keybed featuring ASM's much sought after PolyTouchr polyphonic aftertouch functionality, clearly in a class of its own. With essentially two Hydrasynths in one instrument, KeySplit and Dual voice mode patches with 8 independent voices each are possible. You also have separate balanced stereo audio outputs for each of the two parts. The easily accessible 4 octave ribbon controller adds for truly expressive playing. The Hydrasynth Deluxe of course offers CV/GATE I/O for interfacing to modular and other voltage controlled synths. There's a ton of potential for sound creation, using ASM's WaveScan oscillators together with the Mutator waveshaping section and user configurable filters. A plethora of LFO's and Envelope's plus Insert and Master Effects makes this a dream sound creation tool and quite possibly the ultimate synthesizer and controller combo for your rig.

Tech Specs

Type: Polyphonic Wave Morphing Synthesizer
Sound Engine Type(s): Wavescan
Analog/Digital: Digital
Number of Keys: 73
Type of Keys: ASM POLYTOUCH Polyphonic Aftertouch Keyboard, On/Off Velocity-sensitive
Other Controllers: Ribbon Controller, Pitch Bend, Mod Wheel
Polyphony: 16 voices (Full/Layer/Split)
Number of Presets: 1024 Single Programs, 1280 Programs in Multi (Upper/Lower)
Number of Multis: 640 Programs
Oscillators: 3 x Wavescan oscillators (219 Waveforms), 4 x Mutator wave shapers (8 Types), Noise (7 Types)
Mutators: 8 Types (FM-Lin, WaveStack, PW-Orig, PW-Squeeze, PW-ASM, Harmonic Sweep, Hard Sync, PhazDiff)
Noise: 7 Types (White, Pink, Brown, Red, Blue, Violet, Grey)
LFO: 5 per Voice (Sine, Triangle, Saw Up, Saw Down, Square, Pulse27%, Pulse13%, S&H, Noise, Random, Step), Tempo syncable, Semitone Lock
Envelopes: 5 per voice, Tempo syncable, Variable trigger sources
Filter Types: 1 Multimode Filter (16 types) and 1 Variable LP-BP/Notch-HP filter, series or parallel routing
Filters: Filter 1 (LP Ldr12, LP Ldr24, LP Fat12, LP Fat24, LP Gate, LP MS20, HP MS20, LP 3-Ler, BP 3-Ler, HP 3-Ler, LP Stn12, BP Stn12, HP Stn12, LP 1 Pole, LP 8 Pole, Vowel), Filter 2 (LP-BP-HP, LP-Notch-HP)
Effects: 9 Insert Effects, 5 Delays, 4 Reverbs
Effects Types: Chorus, Flanger, Rotary, Phaser, Lo-Fi, Tremolo, EQ, Compressor, Distortion, Delay, Reverb
Arpeggiator: 8 types (Up, Down, Up&Down, Up/Down, Order, Random, Chord, Phrase)
Other: Mod Matrix (32 slots), Macro Controllers (8), Favorites (32), Randomizer (Patch and Module), MPE Compatibility, Warm Mode, Microtuning
Audio Outputs: 4 x 1/4" Balanced (L/Mono Upper, R Upper, L Lower, R Lower)
Headphones: 1 x 1/4", 1 x 1/8", Separate volume control
USB: 1 x Type B
MIDI I/O: In/Out/Thru
Pedal Inputs: 2 x 1/4" (expression, sustain)
Other I/O: 2 x 1/8" Inputs (Mod 1, Mod2), 5 x 1/8" Outputs (CV, Gate, Mod1, Mod2, Clock)
Power Supply: 12V DC switchable power supply
Additional: Utility shelf
Height: 3.62" / 9.2cm
Width: 44.45" / 112.9cm
Depth: 13.62" / 34.6cm
Weight: 29.33lbs / 13.3kg
MPN: HSLX

Notes: A smaller, more affordable version of the excellent Hydrasynth Keyboard. Advanced wavetable synthesis with 8-voice polyphony, hands-on control and an excellent keybed with polyphonic aftertouch.

*** New 2.0 Firmware update for all Hydrasynth models - March 2023 ***

This is a free of charge update for all current and new users of Hydrasynth. The biggest news in this update includes:
Expanded memory to 8 banks (Keyboard, Desktop, and Explorer only)
NEW modulation source: VOICE MODULATOR
OSC Bit reducer
LFO quantizer
ENV quantizer
LFO Step Advance
Global FX bypass
Increased Vibrato resolution
New Sustain pedal options including Sostenuto
More LED options
Glissando in glide options
Arp Range goes to 6 octaves
Arp Step Offset parameter
More Rand/Init shortcuts (all STEP LFO steps, Wavescan waves, Voice mod offsets)
Local On/Off saved
......And more!
This is the first major update to the Hydrasynth family in a little, which adds a tonne of new features.


Supplier's Notes:
The ASM Hydrasynth Explorer takes the now legendary Hydrasynth into new territories. The Hydrasynth Explorer offers the same 8-voice sound engine as the Hydrasynth Keyboard and Desktop, but in a compact and portable battery powered form factor. The 37-note mid-sized PolyTouchr keybed features polyphonic aftertouch, offering great playability and expression but in a reduced footprint. The extremely deep yet easy to use sound engine features the famous WaveScan oscillators, Mutator waveshaping, flexible dual Filter section, 32-slot modulation matrix, and dual Insert and dual Master effects allowing a lifetime of sonic explorations. The CV/GATE outputs provides for easy integration with equipment such as modular synthesizers and the USB MIDI and full-sized MIDI DIN connectors takes care of standard connectivity without the need for special cables. The ASM Hydrasynth Explorer can also be powered by 8xAA batteries for true on-the-go mobile operation. Simply put, this is one very powerful compact-sized synthesizer and controller all-in-one for the modern musician.

Tech Specs

Type: Polyphonic Wave Morphing Synthesizer
Sound Engine Type(s): Wavescan
Analog/Digital: Digital
Number of Keys: 37 mid-sized keys
Type of Keys:ASM POLYTOUCH Polyphonic Aftertouch Keyboard, On/Off Velocity-sensitive
Other Controllers: Pitch Bend, Mod Wheel
Polyphony: 8 voices
Number of Presets: 640
Oscillators: 3 x Wavescan oscillators (219 Waveforms), 4 x Mutator wave shapers (8 Types), Noise (7 Types)
Mutators: 8 Types (FM-Lin, WaveStack, PW-Orig, PW-Squeeze, PW-ASM, Harmonic Sweep, Hard Sync, PhazDiff)
Noise: 7 Types (White, Pink, Brown, Red, Blue, Violet, Grey)
LFO: 5 per Voice (Sine, Triangle, Saw Up, Saw Down, Square, Pulse27%, Pulse13%, S&H, Noise, Random, Step), Tempo syncable, Semitone Lock
Envelopes: 5 per voice, Tempo syncable, Variable trigger sources
Filter Types: 1 Multimode Filter (16 types) and 1 Variable LP-BP/Notch-HP filter, series or parallel routing
Filters: Filter 1 (LP Ldr12, LP Ldr24, LP Fat12, LP Fat24, LP Gate, LP MS20, HP MS20, LP 3-Ler, BP 3-Ler, HP 3-Ler, LP Stn12, BP Stn12, HP Stn12, LP 1 Pole, LP 8 Pole, Vowel), Filter 2 (LP-BP-HP, LP-Notch-HP)
Effects: 9 Insert Effects, 5 Delays, 4 Reverbs.
Effects Types: Chorus, Flanger, Rotary, Phaser, Lo-Fi, Tremolo, EQ, Compressor, Distortion, Delay, Reverb
Arpeggiator: 8 types (Up, Down, Up&Down, Up/Down, Order, Random, Chord, Phrase)
Other: Mod Matrix (32 slots), Macro Controllers (8), Favorites (32), Randomizer (Patch and Module), MPE Compatibility, Warm Mode, Microtuning
Audio Outputs: 2 x 1/4" Balanced (L/Mono, R)
Headphones: 1 x 1/4"
USB: 1 x Type B
MIDI I/O: In/Out
Pedal Inputs: 1 x 1/4" (sustain)
Other Outputs: 5 x 1/8" Outputs (CV, Gate, Mod1, Mod2, Clock)
Power Supply: 12V DC switchable power supply
Height: 2.28" / 5.8cm
Width: 21.81" / 55.4cm
Depth: 9.72" / 24.7cm
Weight: 7.63lbs / 3.46kg
MPN: HSMK

Notes: The Nanobox series kicks off with a tiny wavetable synth. 1010music's Fireball offers eight-voice polyphony, touchscreen control, built-in effects and custom user wavetables. Small but spicy.

Supplier's Notes:
Red Hot Wavetable Synthesis

Bring some heat to your music creation workflow with Nanobox | Fireball, a polyphonic wavetable mini synthesizer with intuitive touchscreen control. Featuring eight voice polyphony, two wavetables and an oscillator, Fireball unlocks a huge array of sounds, from punchy and aggressive leads to atmospheric pads. Touchscreen X/Y control allows you to instantly morph and shape sounds with the swipe of a finger. Choose from hundreds of professionally designed presets and wav files, or quickly create your own patches with deep parameter control via the 2" touchscreen. Integrate fireball seamlessly with your existing tabletop gear or create on-the-go thanks to a compact design that fits in the palm of your hand.

What is included:

Nanobox | Fireball compact polyphonic granular synthesizer with touchscreen control
MicroSD card with presets and wav files
USB power cord
Type B TRS MIDI To MIDI 5 Pin DIN adapter
Quick Start Guide

Technical Specs:

Includes 123 presets and 103 wavetables
Wavetables use 2048 samples per cycle and 256 cycles
Power: USB-C connection 5V, 500mA
3.5mm audio input and output
Maximum input and output level: 2Vrms
DAC and ADC resolution: 24-bit
Internal resolution: 32-bit
Sample rate: Oscillators: 96kHz Rest of Engine: 48kHz
MIDI Input: 3.5mm Type A/B auto sensing
MIDI Output: 3.5mm Type A/B selectable
Clock Input: 4 PPQ
MIDI support: Note On/Off, Mod Wheel, Sustain, Pitch Bend, Mono & poly Aftertouch, assignable CCs, and clock
H x W x D: 1.5" x 3.75" x 3"
Weight: 0.25 lbs.
