Rossum Electro-Music

View:
Options
15/5(ページ1/1)の商品
Cat: 658749 Rel: 11 Sep 17

Modulated ladder filter Eurorack module with Variable Slope, Q Intensity Control & Q Level Compensation
Notes: At the core of the EVOLUTION Variable Character Ladder Filter is Dave Rossum's enhancement of the iconic Moog ladder filter from the original E-mu Systems 2100 LPF module (which, incidentally, Dave counts as his favourite sounding of all of the analog filters he designed).

For EVOLUTION, Dave has designed new capabilities that not only allow you to dial in all of the outstanding qualities of the original 2100, but combine to let you create the sonic characteristics of a wide variety of other filter types.

They include:

- A Genus control that allows continuous voltage control of the number of filter poles (from 3 to 6 poles), essentially allowing real-time variation of Evolution's effective cutoff slope from 18dB/oct to 36dB/oct. LEDs give continuous indication of the current slope.
- A Species control that lets you vary the signal level into the ladder, letting you control the intensity of the filter's characteristic distortion. When in self-oscillation mode, this control modulates the amplitude of Evolution's output.
- Voltage controlled resonance with a variable Q Level Compensation control that controls the balance of the resonant peak and the frequencies below the cutoff frequency (which would otherwise be attenuated as the resonance is increased).
- An extremely accurate and temperature-stable frequency control exponential generator (accurate over 10 octaves), rivalling the specifications of the best analog VCOs.

Taken together, EVOLUTION gives you everything from the platonic ideal of the classic ladder filter to a vast selection of alternative filter characteristics.

And like all Rossum Electro-Music modules, it's solidly built, with machined aluminium knobs and high quality components throughout.
Read more
 1 in stock $319.83
Click for better price!
quote 658749
Cat: 732306 Rel: 09 Sep 19

Stereo thru-zero state-variable VCF - 16HP
Notes: The only module named after a Swedish botanist? Possibly. Relentless synth innovator Dave Rossum pushes the boundaries again with a state-variable stereo filter offering through-zero frequency modulation. Sounds complicated. Sounds good.

Supplier notes:
Following in the tradition of Evolution and Morpheus, LINNAEUS represents yet another Dave Rossum innovation in filter technology.

LINNAEUS is a stereo state-variable filter that provides the unique ability to linearly modulate its resonant frequency through zero into negative frequency, while maintaining stability. With extensive voltage control of nearly every parameter, Linnaeus lets you manipulate the filter's natural response curve in new ways, to create both subtle and dramatic timbral effects. And with a "one-knob-per-parameter" interface, LINNAEUS inspires sonic creativity that invites (and rewards) real-time interaction.

LINNAEUS's cutoff/resonant frequency is exponentially voltage controllable from sub-audio to ultrasonic frequencies, while its resonant gain (Q) is exponentially voltage controllable from 0dB to greater than 60dB.

LINNAEUS's channel output response characteristics are independently and continuously variable from Lowpass, through Bandpass, Highpass and Notch, to Low and High Shelving characteristics. Voltage control of the response characteristics are independently selectable for each of the two channels.

The linear thru-zero modulation is provided by an integrated modulation oscillator and/or an External Linear FM modulation input.

The voltage-controllable modulation oscillator can track the filter's exponential frequency or operate independently. The modulation oscillator's output waveform is continuously variable from Off through Sine, Triangle, and Sawtooth, to Square. The modulation oscillator output is summed with the external linear FM input and applied to the modulation index VCA, which controls the linear thru-zero modulation index from zero to 8X. The modulation index is, of course, also voltage controllable.
Read more
 4 in stock $405.40
Click for better price!
quote 732306
Cat: 658753 Rel: 11 Sep 17

Premium 14-pole stereo digital filter module
Notes: With our MORPHEUS digital filter module, we're finally able to unleash the full power of the 14-pole Z-Plane Filters that Dave invented for the E-mu Morpheus synthesizer.

The MORPHEUS Eurorack module includes over 280 filter configurations, what we call Cubes. Each Cube is composed of up to 8 complex filters that you can picture as being at the corners of a three dimensional cube (hence the name). Morpheus gives you the ability to smoothly interpolate between those 8 filters within the cube's three dimensional space.

Due to processor limitations back in the day, the original Morpheus was capable of real-time morphing in one dimension, but interpolation in the frequency and transform dimensions were set at note-on and remained static for the remainder of the note. But even with that limitation, Morpheus offered sonic capabilities that are unmatched to this day.

With the MORPHEUS filter module, you now have simultaneous real-time CV control of all three dimensions, for dynamic timbral effects unlike anything you've ever heard before. In stereo.
Read more
 2 in stock $468.50
Cat: 658754 Rel: 11 Sep 17

Compact programmable universal CV generator - 12HP
Notes: Satellite is a compact 12HP module that can be loaded with all (or a subset) of the presets and preset sequences from a Rossum Electro-Music Control Forge or other Satellite and then function as a completely stand-alone CV generator. Once the presets and preset sequences are transferred from the other module (via a patch cord connection), Satellite no longer requires any connection to the module.

With one or more Satellites, you can take advantage of all of your Control Forge presets and sequences in multiple cabinets or even different systems.

Multiple Satellites can be programmed from the same Control Forge and synced together via their Gate inputs to create complex polyphonic sequences and modulation contours.

In addition to direct connection with a Control Forge or other Satellite, presets and preset sequences can also be loaded via audio file archives that have been saved from a Control Forge or Satellite. And since those files can be posted online and downloaded, it’s a great way to share and exchange presets.
Read more
 1 in stock $244.95
Cat: 718648 Rel: 20 May 19

Triple oscillator module with various modulation possibilities - 30HP
Notes: The latest brainchild of synth pioneer Dave Rossum, TRIDENT is a 100% analogue, triple oscillator module that opens up a universe of dynamic timbral textures.

At its most basic level, TRIDENT is three precision audio VCOs, each sporting a unique variety of control voltage inputs.

The main or "Carrier" oscillator provides its three waveforms simultaneously. The two Modulation Oscillators each have a single output and a waveform selector. The Modulation Oscillators also have a voltage controlled Symmetry parameter which varies the duty cycle of the triangle wave output from sawtooth to triangle back to time reversed sawtooth, and also varies the sawtooth output to have an upward or downward kink in the middle, as well as controlling pulse width when the pulse waveform is selected.

And while each oscillator can be used independently if desired, it's when they're combined into a synchronous ensemble that the real sonic magic happens.

That magic is what we call "Zing" modulation. Each of the Modulation Oscillators can modulate each of the Carrier outputs in an amount controlled by the Zing parameter. Zing modulation is mathematically akin to ring modulation, but due to the synchronization of the oscillators (when an oscillator's Sync button on), the harmonic sum and difference sidetones of ring modulation transform into complex but purely harmonic overtone spectra, which vary dynamically and dramatically with the frequency and waveshape modulations of the modulation oscillators. Each change in the Modulation Oscillator parameters - Frequency, Symmetry, Waveshape, Zing, and (in the case of Modulation Oscillator 2) Phase - will have a different effect on the timbre of each of the three Carrier waveshape outputs.

When the modulation oscillators are set to track the carrier oscillator, the waveshape will remain constant as the carrier frequency changes. In this case the overtone structure is determined by the settings and CV modulations of the modulation oscillators. If instead the modulation oscillators do not track the carrier, some of the overtone structure will vary relative to the carrier frequency.

What all this means is that whether musicians take advantage of TRIDENT's unique synchronous modulation capabilities (which they, of course, should), or just treat it as three superb, wide-range analogue oscillators, TRIDENT offers a vast variety of dramatic sonic textures.
Read more
 1 in stock $523.07
