Coming soon: Studio Equipment
Studio Equipment vinyl due out soon
We are all fans of synthesizers, their vintage sound, classic and modern at the same time, their ability to mix several timbres. We love the musical journey that transports us while listening to each new presets.
We also like guitar and bass. Standing or sitting, in your studio or on stage, playing on guitar or bass is this tremendous energy, this way in which the intensity of the playing is in total connection with the music you want to create. A sweet ballad, a melodious arpeggio, a hell of a bass line, a stratospheric lead, an awesome riff.
What if we could express all that but with a great synth sound?
The dream came true, and even more!
A modern synth played like a guitar or a bass
Elyra is played with the typical gestures of playing guitar and bass and all the energy that comes from it. You play with your whole body.
There are two strumming aera for strings, one dedicated to back and forth and another dedicated to bass and arpeggios.
Elyra is designed to be played by both right-handed and left-handed people.
You can also play it placed on a table or on your knees like a groove box.
A powerful and unique composition tool
With up to 16 voices polyphony, spread across 16 instruments/layers and with is powerful sequencer, Elyra is more than a groovebox, it is a composition tool.
You can have one instrument with 16 voices or 16 instruments with one voice and everything in between.
Because Elyra is battery powered, you can carry it anywhere with you and play for several hours.
You can play and sequence all your other instruments via MIDI port.
A sound engine is made for this instrument by Kodamo.
At the core of Elyra there is a powerful and beautiful sound engine created for by Kodamo.
It is a virtual analogue engine based on subtractive synthesis with just enough FM synthesis to offer a vast sound territory.
It has many parameters to sculpt and create a unique sound.
Electronics and wood
Elyra is made of electronics and wood.
The electronic parts are designed in France and comply with environmental standards and in particular RoHS.
The body of the instrument is made of wood. It is cut and assembled in France. The wood is only chosen from sustainable or recycled sources.
Elyra is built to last.
Raised touch buttons
All Elyra buttons are touch sensitive pads made up of a slightly raised area allowing the user to feel physical feedback.
This is capacitive sensor technology which offers an extremely fast response time of 2 ms.
There are 5 distinct areas on the main panel:
the fretboard composed of 4 * 12 pads
the strumming area separated into two types, A and B
two assignable sliders
an OLED screen with its wheel and its 8 contextual buttons
Guitar/bass mode
At first you need a double trig to play a note in Guitar or Bass mode: the hand on the fretboard selects the note to be played, and the other hand uses one of the two strumming areas.
Each one of the four strings has its own two strumming areas.
The strumming area A, is made of a long and very thin relief pad. It is ideal for playing back and forth on one or more strings.
The strumming area B, is a double pad surrounded by holes in the main layer, it allows both bass type playing and is ideal for playing arpeggios.
Elyra retains the essential subtleties of guitar playing, when a note has just been played you can also, like in guitar, slide to another note, or do a Pull-off or a Hammer-on without using the strumming area again.
You can use the slider with your thumb to bend the notes.
Elyra can be tuned according to your needs. there are basic tunings, like the first 4 strings of a guitar E, A, D, G, or any open tuning, or like a Ukulele.
You choose the root notes of each string, and the choice is specific to each track in one project.
Specifications
Fretboard: 12*4 capacitive pads (2ms latency)
Sound Engine: Virtual analogue + FM
Polyphony: 16 voices shared by all tracks
Multitimbrality: up to 16 instruments/layers
Presets: 256 factory presets
1024 user presets
16 presets per project
Oscillators: 15 waveforms including sine, triangle, saw, pulse and noise
Pitch envelope
Amp envelope ADSR + delay
FM: envelope modulator (osc 2) + feedback level
Filter: filter type : HPF, LPF
Filter slope: 2 poles -12dB/oct, 4 poles -24d B/Oct
Envelope ADSR
LFO: 2 LFOs, 5 waveform, speed depth, delay, retrig position, sync to BPM
Effects: 3 master effects with individual send by tracks
Effect 1: distortion/overdrive
Effect 2: bitcruch or chorus
Effect 3: stereo delay or reverb
Sequencer: a pattern = up to 256 steps per track, 128 patterns per project
max 999 project by SD card
Power Supply: 5v USB bus power supply
Memory: SD card
Size and Weight
Width: 435 mm - 17 - 1/8 inches
Depth: 170 mm - 6 - 11/16 inches
Height: 40 mm - 1 - 37/64 inches
Weight: 1.2 kg / 2 lbs 12,3 oz
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
It has a bank of 16 user-defined scales that can be easily edited, and automatically saved into memory. qTone saves every change into EEPROM so you can be sure to get back to the last state after power on.
Both channels can work independently with their own scale each, or with a common scale as well. Aside from the Scale, it is possible to set Glide, Offset, and Transpose parameters. The Glide parameter performs a smooth portamento between quantized notes. Offset shifts an input CV up or down, which works as an offset before quantizing, while the Transpose parameter shifts a scale after quantizing by semitones.
The 2 CV inputs are freely routable to any parameter in the CV menu. qTone works with unipolar or bipolar signals, in the range from -5 to +5 volts.
Technical details
6 hp
45 mA +12V
22mA -12V
0 mA 5V
42 mm deep
CV input voltage ranges: +5-5v, 0v+5v
CV output voltage ranges: +5-5v, 0v+5v
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.est. release 31 May 24 $368.22
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
The VCZIII series VCO is a result of the collaboration of Feedback modules and CMS-LAB and is a modern re-creation of those temperamental, organic and beautiful sounding VCOs from 1969 but with enhancements and adaptations to the Eurorack needs of 21st century.
There are two type of VCOs, VCZIII A based on VCO1 with variable shape SINE & SAW waveforms, VCZIII B based on VCO2 & VCO3 with variable TRIANGLE & PULSE waveforms.
Also, each VCO comes in two versions, one with normal fine tune potentiometers and one with precision multiturn potentiometer.
THIS VERSION IS WITH BOURNS MULTITURN FINE TUNE POTENTIOMETER.
Tech specs:
- 12HP width
- 35mm depth behind front panel including the power connector
- standard 10 pin euro power +12V / -12V
- power consumption +12V 50mA , -12V 30mA
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
Dual-channel design
With two independent, voltage-controlled switches in one module, you can maximize your creative possibilities without sacrificing valuable space. Route, sync or share signals with unprecedented simplicity.
Voltage Control
Each channel responds to control voltages, allowing you to dynamically switch between signal paths. This allows for responsive and vivid interaction with your sound, ideal for complex patches and performances.
Compact Efficiency
At just 2HP, this module packs incredible functionality that adds versatile switching options to your Eurorack configuration without losing track.
Intuitive operation
Despite its advanced features, the Dual Voltage Controlled Analogue Switch remains intuitive to use. The clear layout and labeling of the controls make it easy to focus on what's important: your creativity.
Perfect for experimental setups
Whether you're performing live, recording in the studio, or just experimenting with new signal paths, this dual switch opens up new dimensions of sound manipulation. It's the ideal tool to add a new level of dynamic control to your Eurorack system.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
With its slim design of only 2HP, the Slew Limiter fits seamlessly into any Eurorack system without taking up valuable space.
Create smooth transitions between notes or modulate CV signals to create organic, vibrant effects such as portamento/glide, or complex modulated patches.
Adjustable rise and fall times give you complete control over the speed of signal changes, from instant jumps to smooth, slow transitions. Versatile uses: Whether for smoothing control voltages, creating legato effects for monophonic melodies or for creative sound design - this slew limiter is a true all-rounder.
Thanks to its clean layout and simple controls, you can make the settings you want instantly, making it ideal for live performances and studio sessions.
CV control via rise/fall
A unique feature is the ability to control rise and fall times via external CV signals, allowing you to dynamically react to your performance or patch.
Shape Control
The Shape slider allows you to fine-tune transitions over a wide area. Whether it's a slow exponential increase, linear transitions, or a subtle adjustment through the logarithmic characteristic, it's all at the service of the music
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This rugged and spacious bag delivers maximum versatility, with 3 storage layers and 11 pockets. The separate padded layers protect your gear, and are precisely designed to fit the top production tools.
With interior dimensions of 19.1" x 12.6", the TRAKPACK's largest storage layer offers a massive 5" of depth for your sampler, mixer, DJ controller, or vinyl records. It's a perfect fit for the MPC Live 2 or Push 3, and can also fit up to 5 smaller machines like the Digitakt or SP-404.
The 2nd layer is 3" deep, and can hold other large drum machines and synths, and the 3rd layer has a laptop pocket with a soft velvet lining, plus extra space for your cables or iPad.
There are 5 interior pockets for organizing your accessories and FX, plus 5 exterior pockets that can fit headphones, audio interfaces, or even a MIDI controller keyboard. The exterior storage pockets are enhanced with an expandable design that can increase to a depth of 2.5".
With so much storage space available, this could be the only bag you'll need on the road. The premium materials include padded shoulder straps, cushioned back support pads, and a spacious and comfortable handle. There's even a luggage pass-through for attaching to your carry-on, and the straps can be detached and stowed when you're using this feature.
The TRAKPACK is engineered with a rigid structured frame, so the bag can rest in a standing position with total stability, and the waterproof zippers, ballistic nylon material, and shock-resistant rubber padding ensure complete protection for your gear
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
The desktop Super 6 takes everything the Super 6 is famous for and reimagines it in a more compact and super-flexible package. It is VESA compatible for use with widely-available monitor arms/mounts, rack mountable with a 7U footprint, and comes complete with robust retractable feet for a more ergonomic experience in desktop use settings.
In Binaural mode, the Super 6 features a true stereo signal path in which the instrument's twelve voices are twinned to form six stereo 'super' voices. Consequently, the left and right channels - and each of the player's ears - are assigned their own complete synthesizer voice. Parameters for both channels of each super voice may be independently controlled, facilitating the player to create rich and unique stereo images.
The Super 6 is a love-letter to the classic analogue synthesizer, brought firmly into the present with cutting-edge technology under the hood and a no-compromise approach to sound character, build quality and interface design. The rich sound that UDO has been championed for, paired with a robust, compact and inviting form factor with smooth, solid and responsive controls throughout, it cries out to be played.
Compact, flexible and ergonomic
Offering the flexible and immediate control, gorgeous analogue sound and unrivalled build quality of the Super 6, but in a more compact package. The Super 6 Desktop is a fully-featured Super 6 analogue-hybrid 12 voice synthesizer, housed in a newly designed all-metal chassis. The Super 6 Desktop also includes ergonomic features such as VESA mount compliance, optional rack ears (7U) and robust flip up feet, as well as a huge 24-voice Super 6 polychain option.
Binaural analogue signal path
In Binaural mode, the Super 6 features a true stereo signal path in which the instrument's twelve voices are twinned to form six stereo 'super' voices. Consequently, the left and right channels - and each of the player's ears - are assigned their own complete synthesizer voice. Parameters for both channels of each super voice may be independently controlled, facilitating the player to create rich and unique stereo images. The effect ranges from subtle to extreme stereo movement, creating an enhanced sense of spatial positioning relative to "conventional" monaural signal-chains panned at their output.
Massive modulation without menus
Enormous flexibility at the player's fingertips through simple controls and a carefully designed front-panel. Going deeper, there is an intuitive and immediate modulation system based around the performance area switches. For those who want to go further, every panel control can be targeted for modulation, all simultaneously and all with unique amounts.
Analogue voice architecture
Alongside an analogue amplifier section, the Super 6's main filter is an analogue 4-pole, 24 dB per octave, resonant low-pass filter. It is preceded by a voltage controlled high-pass filter that can either be off, fixed, or can also track the low-pass filter cutoff for band-pass operation.
The no-compromise build quality
An instrument is cherished not just for the way it sounds but for the way it feels to play. UDO have worked tirelessly on the physical design to foster an immediate connection with the player. There has also been no expense spared on the build quality, with a rugged metal housing and solid control elements throughout.
Unit Size:(L x W x H) 45 cm x 29 cm x 10cm (w. collapsed back feet).
Net weight 6.2kg
Packaged Dimensions:(L x W x H) 59cm x 48cm x 20cm.
Gross weight: 8.4kg
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
For many musicians and producers who utilize a plethora of tools, instruments and custom sounds in their home or studio setup, recreating this for a live performance is not always straightforward. This is where AstroLab comes in, offering both a robust, minimalist design and workflow-focused technology that lets you integrate all your sounds effortlessly.
A universe of iconic sounds?
AstroLab comes with over 1300 onboard presets brought to life with 10 in-built sound engines, from Virtual Analog to Wavetable and Granular. Instantly access an unparalleled library of sounds as well as the ability to integrate your own - expandable through the Sound Store and companion software.
A performance keyboard you can trust
AstroLab lets you travel from the stage, to the studio, and back, without ever needing to compromise on sound quality and playability. Every aspect of AstroLab has been designed with the live musician in mind.
Produce, rehearse, perform
Focus on performance with AstroLab's simple yet powerful controls. Featuring quick sound selection, 4 multi-purpose macros, customisable FX knobs and innovative play modes to help you stay in key and inspire new ideas.
On-the-go control
Customize and organize sounds on-the-go via AstroLab's mobile app which brings the convenience of mobile technology to your performance workflow. Edit your playlists and explore new sounds with the sound store, all completely independent from your DAW or computer.
Professional software included
Fine-tune, record and curate custom sounds for AstroLab using its counterpart software, Analog Lab Pro, extending the sonic range and power of AstroLab to suit your every need.
Features
61-note semi-weighted keyboard
10 sound engines
Virtual Analog
Samples
Wavetable
FM
Granular
Physical modelling
Vector Synthesis
Harmonic
Phase distortion
Vocoder
Piano-size keys
Over 1300 in-built sounds from Arturia instruments
Up to 10.000 sounds via Arturia software
Navigation wheel & screen for easy browsing
10 Preset Buttons for quick sound access
4 macro controls for quick editing
17 insert FX & dedicated Delay/Reverb
4 dedicated knobs to control FX
Multis/Keyboard Split
MIDI i/o, audio input, and control pedal I/o
USB-C connection and USB-A host
Bluetooth audio and WiFi for wireless control
Arpeggiator, Looper, Chord & Scale modes
I/O on offer:
Stereo Audio input
Four control inputs
Stereo audio outputs
Dedicated headphone out
USB MIDI Host
USB C Connection to host computer
Locking DC power input
Included software
Make use of AstroLab's software ecosystem which enhances ease-of-use when on the road and offers greater control, customisation and an even greater range sounds:
AstroLab Connect (iOS + Android)
Analog Lab Pro
Compatible with V Collection and Pigments (not included)
Box Content
Quickstart
Registration card
USB Cable (C/A)
User Manual
Power Supply
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
The Zoom MS-70CDR+: Your New Modulation Station
The MS-70CDR+ gives musicians 149 spatial effects ranging from lush choruses to crystal-clear delays to atmospheric reverbs. This single stompbox can shape your tone and provide endless depth and textures.
A Deep Dive into Chorus, Delays, Reverbs & More
Chorus - 43 different chorus and modulation effects that add depth and motion to your sound including phasing, flanging, tremolo, vibrato, detuning, and pitch shifting.
Delays - Featuring 29 mono and stereo delays, with delay times of up to 4 seconds. Everything from reverse and multi-tap to pitch-shifted and self-oscillating delays.
Reverbs - 33 sophisticated studio-quality effects. From spring and plate reverbs to giant hall and arena reverbs.
Dynamics / Filters - Round out your sound with 44 dynamics and filters such as EQ's, compression, noise reduction, and special effects.
Expanded Controls
The MS-70CDR+ offers expansive parameters for each effect, allowing you to dive deep into tweaking your tone.
Define Your Sound
Use a singular effect or up to 6 simultaneously to create unique tones. Save your creations in one of the 100 patch slots or use the 80 preset patches as inspiration to get you started.
Next Generation Circuitry
Newly designed analogue circuits provide more fidelity for improved sound quality. The flat phase response provides sharp attacks and clean low end.
Everything's Better in Stereo.
The MS-70CDR+ has stereo input jacks that accept signals from passive and active guitars, as well as line-level devices such as synthesizers. Its dual line-level output jacks enable you to record and perform with the MS-70CDR+'s 58 stereo effects.
Soundscapes Are Key
For musicians looking to add lush layers to their synths or keyboards, the MS-70CDR+ provides high-quality effects that are perfect for adding atmosphere and character to your sound.
Change Patches With MIDI
With USB MIDI, you can connect the MS-70CDR+ to other MIDI gear to remotely trigger patch changes.
Enhanced Navigation
Cross Key Switches
The Cross Key switches allow you to instantly switch between effects and patches with a tap of your foot.
Control Knobs
Adjusting and tweaking parameters for each effect can be done with the four encoder knobs.
Colour Coded LCD Screen
The LCD backlight changes colour to make it easier to distinguish each category of effects while scrolling.
Sturdy Build
The MS-70CDR+ is built around a metal frame designed to withstand the rigors of live performances.
Power Options
The MS-70CDR+ runs on 2 AA batteries, USB power or AC power.
Tune-Up
The onboard chromatic tuner uses the colour backlight to give visual feedback to help you tune quickly and accurately. It supports all standard guitar tunings as well as open & drop tunings.
Handy Guitar Lab
With a growing library of patches and effects, guitarists can continue to expand their sound with the Handy Guitar Lab for MS-70CDR+ app for iOS. *Coming Soon to the App Store.
Technical Specifications
Maximum number of simultaneous effects: 6 effects
User patch memories: 100
Sampling frequency: 44.1 kHz
A/D conversion: 24-bit 128× oversampling
D/A conversion: 24-bit 128× oversampling
Signal processing: 32-bit
Frequency response: 20 Hz - 20 kHz (+0.5 dB/-0.5 dB) (when 10kO load)
Display: 160×128 dot-matrix LCD
Inputs L/R
Standard mono phone jacks
Rated input level: -20 dBu
Input impedance (line): 470 kO
Input S/N: 122 dB
Outputs L/R
Standard mono phone jacks
Maximum output level: +7.2 dBu (when output impedance 10 kO or higher)
Noise floor (residual noise) L/R: -100 dBu
Power
AC adapter: 9V DC 500mA centre negative (ZOOM AD-16 optional)
2 AA batteries (alkaline, lithium or rechargeable NiMH batteries)
Estimated operation time using batteries
These values are approximate. Battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
Alkaline batteries: about 7 hours (about 5 hours using stereo input)
NiMH batteries (1900 mAh): about 6.5 hours (about 5 hours using stereo input)
Lithium batteries: about 14 hours (about 10 hours using stereo input)
USB Port:
USB 2.0 Type-C / Supported cable type: Type-C
Handy Guitar Lab: USB 1.1 Full Speed
Use a USB cable that supports data transfer. USB bus power is supported.
Dimensions: 133 mm (D) × 79 mm (W) × 61 mm (H)
Weight: 368 g (excluding batteries) / 415 g (including batteries)
Note: 0 dBu = 0.775 V
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
Compact design
With a width of only 2HP, this envelope generator fits seamlessly into any Eurorack setup without wasting valuable space.
Customise your sounds with full ADSR control - Attack, Decay, Sustain and Release can be intuitively adjusted to bring your sounds to life
There is also a built-in LED display that gives you real-time visual feedback on the current phase of the envelope. This way, you always have an overview of the dynamic progression of your sounds.
With the ability to choose between three timebase settings (S, M, and L), you can flexibly adjust the envelope time base to suit your musical needs. From fast, crisp pulses to long-drawn-out, atmospheric evolutions, expand your expressive possibilities.
Manual Trigger
A special highlight is the manual trigger button. This allows you to trigger the envelope independently of external signal sources, ideal for spontaneous performances or experimenting with new sound ideas.
Dimensions
2 HP
42 mm deep
Current Draw
15 mA +12V
5 mA -12V
0 mA 5V
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
Space-saving design
With its narrow 2HP width, the Dual Sample and Hold module fits seamlessly into any Eurorack system without compromising on functionality.
Dual operation
Two independent sample and hold channels give you double the creativity. Use them for stereo effects, parallel modulation sources, or complementary CV sequences to add a new dimension to your sounds.
Standardized inputs
A special feature of this module is the normalization of the "in" and "trigger" inputs of the second channel to the first. This means that the second channel will automatically pick up the signals from the first channel if no separate inputs are connected. This intelligent linkage allows you to create complex, interconnected modulations with just one input signal.
Flexibility of use
Whether you want to create random melodies, rhythmic variations, or dynamic soundscapes, this module gives you the flexibility you need. Experiment with different input signals and triggers to achieve surprising and inspiring results.
Intuitive operation
Despite its sophisticated functionality, the Dual Sample and Hold module is intuitive to use. It is therefore suitable for beginners in the world of modular synthesizers as well as for experienced users who want to expand their sound palette.
Dimensions
2 HP
39 mm deep
Current Draw
15 mA +12V
15 mA -12V
0 mA 5V
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
Ultra-compact design
With a width of only 2HP, this module fits seamlessly into any Eurorack setup, maximizing the space available for further creative expansion.
Seven outputs
Equipped with seven outputs, our Single Buffered Multiple allows simultaneous signal distribution to multiple modules. Perfect for complex patches where you want to send a signal to different destinations.
Buffered Outputs
The buffered outputs ensure that signal integrity is maintained even when distributed across multiple modules. Enjoy precise control and stability in your signal chain without sacrificing signal quality.
LED indicator for positive input signals
A special feature is the integrated LED, which lights up as soon as a positive input signal is detected. This visual feedback is not only convenient, but also makes it easier to troubleshoot complex patches and improve the user experience.
Optimal flexibility
Whether you want to route audio signals, control voltages or triggers, our Single Buffered Multiple offers the flexibility you need to meet your creative needs.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
Compact design
With its slim 2HP width, this module fits seamlessly into any Eurorack system without taking up valuable space.
Normalized Second Input
The input of the second channel is normalized, which means that a signal is automatically distributed to both channels if only the first input is used. This simplifies simultaneous signal distribution and increases creative freedom without the need to use multiple patch cords.
Dual operation
Equipped with two channels, our Buffered Multiple offers the freedom to distribute signals as either 2x 1->3 or 1x 1->6 for maximum flexibility. This allows for a wide range of patching options and maximizes the efficiency of your system.
Buffered Outputs
Each output is buffered, which means your signal will be amplified without any loss of quality or voltage drop. This is especially important if you want to send precise control signals (like pitch CV) to multiple targets.
Versatile applications
Whether you want to build complex modulation routings, control multiple synth voices at the same time, or simply distribute a signal across multiple effects modules, this module gives you the flexibility you need.
Dimensions
2 HP
40 mm deep
Current Draw
15 mA +12V
15 mA -12V
0 mA 5V
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
The CubuSynth Engine can work as 2 independent VCOs, or as one complex FM oscillator.
With its internal "Chaos Engine" it creates semi-random voltages, generated by the 2 oscillator cores. This signal is then normalized to the CV inputs for Pulse width modulation and exponential FM.
Each of the 2 VCOs offers a switch to select one of the 4 waveshapes to be used by the wavefolders, and the linear FM input normalisations.
Features:
2 VCO cores (voices)
4 simultaneous wave forms per voice + 4 Modulation Outputs
Wavefolder per voice
Pulse Width modulation
Linear and exponential FM inputs
1 V/oct tracking stable over up to 10 octaves
Chaos generator with external clock input
Complex internal normalized modulations
Dimensions:
24 HP
24 mm deep
Current Draw:
87 mA +12V
74 mA -12V
15 mA 5V
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
The CubuSynth Dual CS-20 VCF is a dual / stereo multimode VCF / Phaser / VCO, inspired by the legendary Korg MS-20, with CV control over frequency and resonance. The resonance can self-oscillate and features a 1V/Oct input, stable over at least 2~3 octaves.
Each of the two filter cores has 2 stages of Low Pass and High Pass filtering, which can be blended.
The Frequency CV can be "attenuverted" (with inverting attenuator on CV input). The resonance CV comes with an attenuator.
Key features
2 individual Filter cores with common Frequency and Resonance controls
CV control over Frequency and Resonance for each Filter core
self-oscillating Resonance with LED feedback circuit (visible on the Front)
1 V/oct input, tracking over 2~3 octaves
Frequency Range: 22 Hz - 20 kHz
Blend between LP / HP Filter modes
Ability to use as 2 pole (12db) stereo HP/LP Filter, 4 pole (24db) mono LP/HP or a Band Pass (12db) Filter
Cross FM Modulation possible
Specifications
Size: 10HP x 3U / 50mm x 129mm
Depth: DIY version: 36 mm
Built version: 24 mm
Max. Current Draw:
+12V: +19mA
-12V: -19mA
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
This product is available for pre-order at Juno, for shipping on the release date. You won’t be charged until the order is despatched.
We'll keep you informed of your order at every stage, and let you know if the release date changes.
If the price of the item drops before it's released, you will pay the lower price, but if it increases, you'll only pay the price you see today.
If you also include in-stock items on your order, they’ll be charged and shipped within 24 hours as usual.
